D-Link DUB-E100 User manual

Version 4.1 | 04/05/2012

iD-Link DUB-E100 User Manual

Table of Contents

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any

person or organization of such revisions or changes. Information in this document may become obsolete as our services and

websites develop and change. Please refer to the www.mydlink.com website for the most current information.

Trademarks

D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United

States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of

their respective companies.

from D-Link Corporation.

Manual Overview

iiD-Link DUB-E100 User Manual

Table of Contents

Package Contents ..........................................................................................................................................................................................................1

System Requirements ..................................................................................................................................................................................................1

Introduction ....................................................................................................................................................................................................................2

Features .............................................................................................................................................................................................................................2

Hardware Overview ......................................................................................................................................................................................................3

Software Installation ....................................................................................................................................................................................................4

Windows 7 ................................................................................................................................................................................................................4

Windows Vista .........................................................................................................................................................................................................6

Windows XP .............................................................................................................................................................................................................7

Mac OS X ................................................................................................................................................................................................................10

Linux 2.6.14 ...........................................................................................................................................................................................................13

Connecting the Adapter to a Network ...............................................................................................................................................................14

Completing the Installation ....................................................................................................................................................................................15

Troubleshooting ......................................................................................................................................................................................16

Technical Specications .........................................................................................................................................................................18

Table of Contents

1D-Link DUB-E100 User Manual

Section 1 - Product Overview

• DUB-E100 USB 2.0 10/100 Fast Ethernet Adapter

• DUB-E100 Drivers and Manual on CD-ROM

• Quick Installation Guide

If any of the above items are missing or damaged, please contact your reseller.

Package Contents

System Requirements

Computer with the following:

• Microsoft Windows® 7/Vista®/XP/2000, Linux, or Mac OS X 10.4/10.5

• Pentium 2.0 GHz or higher with a minimum of 32 MB RAM

• Available USB port

• CD-ROM drive

2D-Link DUB-E100 User Manual

Section 1 - Product Overview

Introduction

Thank you for choosing the D-Link DUB-E100 USB 2.0 10/100 Fast Ethernet Adapter. The DUB-E100 USB 2.0 10/100 Mbps Fast

Ethernet Adapter is specically designed to plug into an available Universal Serial Bus (USB) port on a desktop or laptop PC

running Microsoft Windows 7/Vista/XP/2000, Mac OS X, or Linux. Based on USB 2.0, the DUB-E100 extends the transfer speed

of earlier USB Fast Ethernet adapters to true 10/100 Mbps connectivity. Power for the DUB-E100 is provided directly by the USB

bus, eliminating the need for an external power adapter. It also supports USB energy-saving suspend and resume functions

to minimize power consumption, which is especially useful for laptop/notebook users.

Features

Designed for versatility and performance, the DUB-E100 USB 2.0 10/100 Fast Ethernet Adapter provides the following:

• Compliant with USB 2.0 and USB 1.1 specications

• True 10/100 Mbps network connectivity

• Compliance with IEEE 802.3u Fast Ethernet standards and IEEE 802.3 Ethernet standards

• Plug-and-Play installation

• Auto 10/100 Mbps speed detection

• Supports half and full-duplex at 10 Mbps, half and full-duplex at 100 Mbps

• One built-in RJ-45 connector

• Auto-negotiation to the highest available speed

• Two LED indicators: Link, TX/RX

• Driver support:

• Microsoft Windows 7 (x86, x64)

• Microsoft Windows Vista (x86, x64)

• Microsoft Windows XP (x86/x64 Edition)

• Linux (kernel 2.6.14 & above)

• Macintosh OS X (10.4, 10.5)

• Microsoft Windows 2000

3D-Link DUB-E100 User Manual

Section 1 - Product Overview

Hardware Overview

COMPONENT DESCRIPTION

Ethernet Port Plug an Ethernet cable from a switch, hub, or router into this port.

USB Connector Plug this connector into a USB port on your PC.

Ethernet Port

USB Connector

4D-Link DUB-E100 User Manual

Section 2 - Installation

Software Installation

Insert the DUB-E100 CD into your computer’s DVD or CD drive, then proceed to the appropriate installation section on the

following pages for your operating system.

Note: If the user interface does not start up, please go to the Autorun folder in your PC’s CD drive and open Autorun manually.

After you put the CD into the CD drive, the DUB-E100 user interface menu

screen will appear. Click on Install to begin the DUB-E100 driver installation.

The InstallShield Wizard will then pop up and run automatically.

Note: The DUB-E100 user interface may dier in appearance for dierent

regions.

Windows 7

5D-Link DUB-E100 User Manual

Section 2 - Installation

When the InstallShield Wizard is completed, plug the DUB-E100 into your PC

and the driver software installation will be completed automatically.

When the Windows 7 driver installation is complete, please then proceed to

Connecting the Adapter to a Network on page 14.

6D-Link DUB-E100 User Manual

Section 2 - Installation

Windows Vista

After you put the CD into the CD drive, the DUB-E100 user interface menu

screen will appear. Click on Install to begin the DUB-E100 driver installation.

The InstallShield Wizard will then pop up.

Note: The DUB-E100 user interface may dier in appearance for dierent

regions.

Plug the DUB-E100 into your PC and the driver software installation will be

completed automatically.

When the Windows Vista driver installation is complete, you can connect

the DUB-E100 to a USB port on your computer. Please then proceed to

Connecting the Adapter to a Network on page 14.

7D-Link DUB-E100 User Manual

Section 2 - Installation

After you put the CD into the CD drive, the DUB-E100 user interface menu

screen will appear. Click on Install to begin the DUB-E100 driver installation.

The InstallShield Wizard will then pop up.

Note: The DUB-E100 user interface may dier in appearance for dierent

regions.

Windows XP

Plug the DUB-E100 into your PC.
