Cooper Lighting Sure-Lites CC3 User manual

(1)Provision for one meter only. (2)Consult your Cooper Lighting Representative. (3)Not available w/CC6. (4)NC=Nickel Cadmium Battery. (5)CC5SD is

damp location standard. (6)CC4NC, CC5NC not available in SD.

ELECTRICAL RATINGS

Rated Wattage to 87 1/2% of rated D.C. Voltage Lamp Information

Model DC Voltage 1 1/2 hours 2 hours 3 hours 4 hours Type Wattage Number

CC3 6 10.8 7.2 - - Incandescent 5.4 29-121

CC3 NC 6 16 - - - Incandescent 5.4 29-121

CC4 6 18 15 10 8 Incandescent 9 29-84

CC4 NC 6 18 Incandescent 9 29-84

CC5 6 27 24 18 14 Incandescent 9 29-84

CC5 NC 6 24 Incandescent 9 29-84

CC6 6 32 - - - Incandescent 9 29-84

SURE-LITES

6 3/8"

(162mm)

4 3/4"

(121mm)

17 1/2"

(445mm)

13"

(330mm)

Energy Data

Input Current (Max.):

Model No. 120V 277V 347V

CC3 .12A .05A .01A

CC4 .12A .05A .01A

CC5 .13A .06A .06A

CC6 .13A .06A .06A

Model

Number

CC3

CC3NC(4)

CC4

CC4NC(4), (6)

CC5

CC5NC(4), (6)

CC6

Options

(add as sufﬁx)

MRT=MR16 Heads (5W

Standard CC3,

CC3NC; 9W

Standard CC4, CC5,

and CC6)

SQ=Square Head (5.4W

Standard)

A=Ammeter(1)

SD=Self-Diagnostics(3), (5), (6)

V=Voltmeter(1)

TDM=Time Delay Monitor

Alternate Lamps(2)

Other Options(2)

Accessories

(Order separately)

WG1 =Wire Guard

WG2 =Wire Guard (use

for heads adjusted at

45° or greater)

VS1=Polycarbonate

Vandal Shield

VS1WP=Polycarbonate

Vandal Shield

Weather

Resistant

CSK120=Cord Set 120V

Housing

Finish

(Must be

speciﬁed)

WH=White

BK=Black

Voltage

Blank=

120/277

347=120/347 VAC

EMERGENCY LIGHTS Commercial

616

COOPER LIGHTING - SURE-LITES®

COOPER LIGHTING

DESCRIPTION

The CC Series Contractor’s Choice

Emergency Lighting Unit is the ideal

choice when a simple installation and

a reasonable cost are required. Its

contemporary round corner styling,

designer white ﬁnish, and consistent

family appearance enables it to blend

with any decor. The components are

injection molded from tough

polycarbonate materials which resist

discoloration due to age and ultraviolet

radiation.

• Dual-voltage input

120/277VAC, 60Hz, isolation

transformer

• Injection-molded, color-

stable, high-impact UL-94-5V

rated polycarbonate housing

and mounting plate (Housing

is tethered to mounting

plate)

• Designer-white textured

ﬁnish

• Two PAR36 type lamps in

fully adjustable high-impact

polycarbonate lampholders

• Sealed lead calcium

maintenance free battery

• Cutouts provided for surface

conduit on top

• Universal J-box mounting

pattern, keyhole slots

• Remote Capability

CC5, CC6

• Line-Latching, Solid-State

Voltage Limited Charger,

Solid-State Switching, Low-

Voltage Disconnect,

Brownout Circuit,

Overload/Short Circuit

Protection, Test switch/power

Indicator light

• UL 924 Listed, UL Damp

Location Listed (CC5SD

Only), Life Safety NFPA 101,

CSA Certiﬁed, NEC/OSHA,

most state and local codes

CC3

CC4

CC5

CC6

Contractor’s Choice

EMERGENCY LIGHT

ORDERING INFORMATION

SAMPLE NUMBER: CC5WHSD

DIMENSIONS
