Lightolier Calculite CS8226 User manual

Comp ete Fixture Cei ing Mount Lamp

CS8226HUCL Clear Reflector, White Housing (2) 26W Quad Tube

120V - 277V 4-Pin

Comp ete Fixture Wa Mount Lamp

CW8226HUCL Clear Reflector, White Housing (2) 26W Quad Tube

120V - 277V 4-Pin

8-3/4" Dia. (222 mm)

11-1/4" Dia. (286 mm)

11-1/2"

(292 mm)

6-1/2"

(165 mm)

CW8226

(959 mm)

37 3/4"

Calculite®Compact Fluorescent Surface Cylinder CS8226

Page 1 of 2 ” Aperture (2) Quad Tube (4-Pin) Ceiling & Wall Mount

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lighto ier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710

We reserve the right to change details of design, materials and finish.

Features

1. Ref ector: 16 ga. Specular Alzak®aluminum, 55° visual cutoff to lamp and

lamp image, wide distribution. Iridescence Free finish.

2. Housing: Seamless, heavy-gauge aluminum. Two part construction provides

ventilation. Returned edge precisely seats reflector. Matte white finish.

3. Ba ast: Mounted on support bracket, can be easily removed for service.

4. Socket Bracket: Die-formed steel. Attaches to reflector for correct optical

alignment.

5. Stem Kit: Cat. No. FA CSA36: Provided with 1/2" dia. stem and 4 1/2" dia.

canopy. Self-aligning swivel provides maximum 40° vertical adjustment.

Installs over 4" octagonal outlet box. Stem can be cut to length on site.

Matte white baked enamel finish.

6. (Optiona ) Turbo Louver: (not shown) Specular clear Alzak®aluminum deep

reflector with removable radial louver assembly combines good efficiency

with a shield aperture, 50° cutoff to lamp.

7. Crossbar: Install over 4" octagonal or rectangular outlet box.

8. Bracket: One piece cast aluminum with integral backplate.

E ectrica

Note: For ballast electrical data and latest lamp/ballast compatibility refer to

“Ba ast” specification sheet for complete electrical data.

UL listed for 90°C supply conductors.

Options and Accessories

Frame & Mounting

Dimming Consult Factory

Fuse (Slow Blow) Add Suffix F

Turbo Louver Add Suffix TB

Options and Accessories (continued)

Ref ector Finishes

Consult Factory

Other Housing Finishes

Consult Factory

Labe s

UL listed for damp locations, I.B.E.W.

Alzak®is a registered trademark of ALCOA.

Spacing Ratio = 1.6

CERTIFIED TEST REPORT NO. LSC6699 (Based on Recessed fixture 8038CLW/8226HT120)

COMPUTED BY LSC PROGRAM **TEST-LITE**

CALCULITE 8 3/4" HORIZONTAL COMPACT FLUORESCENT RECESSED DOWNLIGHT

WITH SPECULAR REFLECTOR

2-26W QUAD TUBE COMPACT FLUORESCENT LAMP. LUMEN RATING = 1800 LMS.

Coefficients Of Utilization

% EFFECTIVE CEILING CAVITY REFLECTANCE

80 70 50 30 10 0

% WALL REFLECTANCE

50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0

1.60.58.57.5957.56.56.55.54.54.53.53.52.52.51.50

2 .55 .53 .51 .54 .52 .51 .53 .51 .49 .51 .50 .48 .50 .48 .47 47

3.51.48.46.50.40.45.49.47.45.40.46.44.46.45.44.43

4 .47 .44 .42 .47 .44 .41 .46 .43 .41 .44 .42 .41 .43 .42 .40 .39

5.44.40.38.43.40.30.42.39.37.41.39.37.40.38.37.36

6.40.37.34.40.36.34.39.36.34.38.36.34.37.35.33.32

7.37.33.31.37.33.31.36.33.30.35.32.30.34.32.30.29

7.34.30.28.33.30.27.33.30.27.32.29.27.32.29.27.26

8.31.27.24.30.27.24.30.27.24.29.26.24.29.26.24.23

9 .28 .24 .22 .20 .24 .22 .27 .24 .22 .27 .24 .21 .26 .23 .21 .21

20% FLOOR CAVITY REFLECTANCE

For 2-18 watt Quad Tube units, multiply CU.’s x 1.0..

ROOM CAVITY RATIO

Tested According To IES Procedures. Test Distance Exceeds Five Times The

Greatest Luminous Opening Of Luminaire.

** EFFICIENCY = 54.2%54.2%

54.2%54.2%

54 . 2% * *

DATE: SEP 6, 1996

PREPARED FOR: LIGHTOLIER

180 150 120

400

800

1200

CANDLEPOWER SUMMARY

ANGLE MEAN CP LUMENS

0850

5872 87

10943

151028 291

20 1077

25 1045 475

30 944

35 923 574

40875

45 649 465

50 237

55 34 57

60 3

651 1

700

75 0 0

80 0

85 0 0

90 0

ZONAL LUMENS AND PERCENTAGES

ZONE LUMENS % LAMP %LUMINAIRE

0-30 853 23.70 43.74

0-40 1427 39.65 73.17

0-60 1949 54.31 99.94

0-90 150 54.19 100.00

40-90 523 14.94 26.03

60-90 0 .01 .01

90-180 0 .00 .00

0-180 1950 54.15 100.00

Calculite®Compact Fluorescent Surface Cylinder CS8226

Page 2 of 2 ” Aperture (2) Quad Tube (4-Pin) Ceiling & Wall Mount

Lighto ier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710

We reserve the right to change details of design, materials and finish.
