Compaq Presario 8000 - Desktop PC User manual

Filename: s3adatr Title: Addendum [3-column 1 or 2 pages]

Template: HP-Print2K.dot Author: davidg Last Saved By: AnnSchmidt

Revision #: 18 Page: 1 of 2 Printed: 10/24/02 01:16 PM

Using the ATI

All-In-Wonder Card

Your PC comes with the

ATI All-In-Wonder®Radeon™9000

card. This pre-installed TV tuner,

video capture, and graphics card

comes with the necessary cables

and remote control located in the

ATI kit included with your PC.

Your All-In-Wonder card also

comes with the ATI Multimedia

software, which is pre-installed

on your PC.

Important: The ATI kit includes an

adapter to connect a VGA

monitor to the digital video input

port on your All-In-Wonder card

on the back of the PC. You

cannot connect a standard VGA

monitor without this adapter.

The All-In-Wonder card and the

ATI Multimedia Center software

provide 2- and 3-dimensional

graphic capability with multimedia

features that allow you to:

■ Watch and pause live TV, DVDs,

and videos on your PC.

■ Capture, record, and play back

analog video from your TV,

VCR, and camcorder.

■ Organize video and audio files

into a media library.

■ Play games and music CDs.

When you connect your PC to a

television or to a TV signal source,

the ATI All-In-Wonder card

provides several features you can

operate with the ATI remote

control, such as: TV-On-Demand™,

zoom-in control, scheduled

viewing, channel scanning, an

interactive program guide, and

closed captioning.

Note: Scheduled viewing, closed

captioning, and the interactive

program guide are not available

in all countries/regions.

Please refer to the information in

the Quick Setup Guide (cable

installation) poster that came with

your ATI All-In-Wonder card for

information about how to install

the correct audio and video

cables.

Enabling the

Television Display

After you attach all the required

video and audio cables between

the TV and PC, you need to restart

your PC. If you choose to connect

your PC to a TV, the default

display setting is to have the TV

and monitor display the Windows®

desktop simultaneously. TV Out is

an optional feature.

Filename: s3adatr.doc Title: Addendum [3-column 1 or 2 pages]

Template: HP-Print2K.dot Author: davidg Last Saved By: AnnSchmidt

Revision #: 15 Page: 2 of 2 Printed: 10/23/02 04:12 PM

To enable your TV and PC

displays:

1 Click Start on the taskbar.

2 Click Control Panel.

3 Click Appearance and

Themes, if it is present.

4 Double-click Display.

5 Click the Settings tab, and

then click the Advanced

button.

6 Click the Displays tab, and

then select the TV option.

7 Click OK.

Important: If the TV option is

dimmed, your TV may not

be connected to the PC properly.

For the TV option to appear, you

may need to restart your PC after

you connect the video cables.

Reinstalling

the ATI Software

Your PC is pre-installed with all

the necessary ATI drivers and

software to be able to use the

ATI All-In-Wonder card. If you need

to reinstall the ATI All-In-Wonder

programs, refer to the Application

Recovery information in the printed

documentation that came with

your PC.

Getting Help

The ATI All-In-Wonder card comes

with an online user guide.

This guide describes advanced

features and provides information

about using your TV, VCR, and

other video input sources with your

TV tuner card and remote control.

To view the ATI Online User

Manual, click Start on the

taskbar, choose All Programs,

ATI Multimedia Center, and

then click MMC7.

For instructions on how to set

up your PC with your TV, refer

to the ATI Online User Manual

(ATI Multimedia Center 7.7 User’s

Guide) and the cable installation

poster.

For instructions on how to play

DVDs or audio CDs on your PC,

refer to the printed documentation

that came with your PC.

Note: A DVD-ROM drive is an optional

feature.
