Installing the Cisco Content Engine 510 and 565

Documentation Survey

Is Cisco documentation helpful? Click here to give us your feedback.

Introduction

The Content Engine 510 and 565 (see Figure 1) are Internet content delivery devices that offer content

caching, hosting, content replication, video streaming, and other content-based services. The

Content Engine is positioned on the WAN edge between your small business site or enterprise network

and the Internet.

Figure 1 Content Engine 510 and 565—Front View

This document explains how to install a Content Engine in an equipment rack. It also provides general

instructions for installing a Content Engine on a table or workbench.

Before you begin the installation, read the Regulatory Compliance and Safety Information for the Cisco

Content Networking Product Series document and the Site Preparation and Safety Guide that shipped

with your chassis.

Warning

Read the installation instructions before you connect the system to its power source.

83284

Installing the Cisco Content Engine 510 and 565

78-14731-02

Contents

This document contains the following sections:

•If You Need More Information, page 2

•Warning Definition, page 3

•Description, page 7

•Installation Prerequisites, page 9

•Safety Guidelines, page 10

•Operating Specifications, page 12

•Installing a Content Engine 510 or 565 Unit, page 14

•Connecting Cables, page 19

•Connecting Power and Booting the System, page 19

•Checking the LEDs, page 20

•Accessing the ACNS Software on the Content Engine, page 22

•Removing or Replacing a Content Engine, page 23

•Cisco One-Year Limited Hardware Warranty Terms, page 24

•Obtaining Documentation, page 25

•Obtaining Technical Assistance, page 26

•Obtaining Additional Publications and Information, page 27

If You Need More Information

For additional information on the Cisco Content Engine 510 and 565 hardware, refer to the following

documentation:

•Cisco Content Engine 510 and 565 Hardware Installation Guide

•Installing Field-Replaceable Units in the Cisco Content Engine 510 and 565

For additional information on the Cisco ACNS software, refer to the following documentation:

•For Cisco ACNS software Release 5.0:

–

Release Notes for Cisco ACNS Software, Release 5.0

–

Cisco ACNS Software Deployment and Configuration Guide, Release 5.0

–

Cisco ACNS Software Caching Configuration Guide, Release 5.0

–

Cisco ACNS Software Command Reference, Release 5.0

–

SmartFilter for Cisco Content Engine User’s Guide, Version 3.1

•For Cisco ACNS software, Release 5.1:

–

Release Notes for Cisco ACNS Software, Release 5.1

–

Cisco ACNS Software Deployment and Configuration Guide, Release 5.1

Installing the Cisco Content Engine 510 and 565

78-14731-02

Warning Definition

–

Cisco ACNS Software Caching and Streaming Configuration Guide, Release 5.1

–

Cisco ACNS Software Command Reference, Release 5.1

•For information about configuring the Websense software, go to the following web site:

http://www.websense.com

•For information about configuring the SmartFilter software, go to the following web site:

http://www.securecomputing.com

Warning Definition

Warning

IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you

work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar

with standard practices for preventing accidents. Use the statement number provided at the end of

each warning to locate its translation in the translated safety warnings that accompanied this

device.

Statement 1071

SAVE THESE INSTRUCTIONS

Waarschuwing

BELANGRIJKE VEILIGHEIDSINSTRUCTIES

Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan

veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij

elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van de standaard

praktijken om ongelukken te voorkomen. Gebruik het nummer van de verklaring onderaan de

waarschuwing als u een vertaling van de waarschuwing die bij het apparaat wordt geleverd, wilt

raadplegen.

BEWAAR DEZE INSTRUCTIES

Varoitus

TÄRKEITÄ TURVALLISUUSOHJEITA

Tämä varoitusmerkki merkitsee vaaraa. Tilanne voi aiheuttaa ruumiillisia vammoja. Ennen kuin

käsittelet laitteistoa, huomioi sähköpiirien käsittelemiseen liittyvät riskit ja tutustu

onnettomuuksien yleisiin ehkäisytapoihin. Turvallisuusvaroitusten käännökset löytyvät laitteen

mukana toimitettujen käännettyjen turvallisuusvaroitusten joukosta varoitusten lopussa näkyvien

lausuntonumeroiden avulla.

SÄILYTÄ NÄMÄ OHJEET

Installing the Cisco Content Engine 510 and 565

78-14731-02

Warning Definition

Attention

IMPORTANTES INFORMATIONS DE SÉCURITÉ

Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant

entraîner des blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez

conscient des dangers liés aux circuits électriques et familiarisez-vous avec les procédures

couramment utilisées pour éviter les accidents. Pour prendre connaissance des traductions des

avertissements figurant dans les consignes de sécurité traduites qui accompagnent cet appareil,

référez-vous au numéro de l'instruction situé à la fin de chaque avertissement.

CONSERVEZ CES INFORMATIONS

Warnung

WICHTIGE SICHERHEITSHINWEISE

Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen

kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und

den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder

Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten

Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.

BEWAHREN SIE DIESE HINWEISE GUT AUF.

Avvertenza

IMPORTANTI ISTRUZIONI SULLA SICUREZZA

Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle

persone. Prima di intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli

relativi ai circuiti elettrici e conoscere le procedure standard per la prevenzione di incidenti.

Utilizzare il numero di istruzione presente alla fine di ciascuna avvertenza per individuare le

traduzioni delle avvertenze riportate in questo documento.

CONSERVARE QUESTE ISTRUZIONI

Advarsel

VIKTIGE SIKKERHETSINSTRUKSJONER

Dette advarselssymbolet betyr fare. Du er i en situasjon som kan føre til skade på person. Før du

begynner å arbeide med noe av utstyret, må du være oppmerksom på farene forbundet med

elektriske kretser, og kjenne til standardprosedyrer for å forhindre ulykker. Bruk nummeret i slutten

av hver advarsel for å finne oversettelsen i de oversatte sikkerhetsadvarslene som fulgte med denne

enheten.

TA VARE PÅ DISSE INSTRUKSJONENE

Aviso

INSTRUÇÕES IMPORTANTES DE SEGURANÇA

Este símbolo de aviso significa perigo. Você está em uma situação que poderá ser causadora de

lesões corporais. Antes de iniciar a utilização de qualquer equipamento, tenha conhecimento dos

perigos envolvidos no manuseio de circuitos elétricos e familiarize-se com as práticas habituais de

prevenção de acidentes. Utilize o número da instrução fornecido ao final de cada aviso para

localizar sua tradução nos avisos de segurança traduzidos que acompanham este dispositivo.

GUARDE ESTAS INSTRUÇÕES

Installing the Cisco Content Engine 510 and 565

78-14731-02

Warning Definition

¡Advertencia!

INSTRUCCIONES IMPORTANTES DE SEGURIDAD

Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de manipular

cualquier equipo, considere los riesgos de la corriente eléctrica y familiarícese con los

procedimientos estándar de prevención de accidentes. Al final de cada advertencia encontrará el

número que le ayudará a encontrar el texto traducido en el apartado de traducciones que acompaña

a este dispositivo.

GUARDE ESTAS INSTRUCCIONES

Varning!

VIKTIGA SÄKERHETSANVISNINGAR

Denna varningssignal signalerar fara. Du befinner dig i en situation som kan leda till personskada.

Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och

känna till vanliga förfaranden för att förebygga olyckor. Använd det nummer som finns i slutet av

varje varning för att hitta dess översättning i de översatta säkerhetsvarningar som medföljer denna

anordning.

SPARA DESSA ANVISNINGAR

Installing the Cisco Content Engine 510 and 565

78-14731-02

Warning Definition

Installing the Cisco Content Engine 510 and 565

78-14731-02

Description

This document describes the following Content Engine models:

The Content Engine 510 and 565 are configured for AC-input power and have a single AC-input power

supply.

Your Content Engine comes with an integrated dual-port Ethernet controller. This controller provides an

interface for connecting to 10-Mbps, 100-Mbps, or 1000-Mbps networks.

The Content Engine has two 10BASE-T/100BASE-TX/1000BASE-TX Ethernet ports with RJ-45

receptacles. Both Ethernet ports support autodetect speed mode and full-duplex operation, which

enables simultaneous transmission and reception of data on the Ethernet LAN.

In addition, the Content Engine 565 is configured with one Ultra320 low voltage differential (LVD)

Small Computer System Interface (SCSI) connector for attaching the Cisco Storage Array. The SCSI

adapter card is installed in PCI slot 2.

Figure 2 calls out the locations of the slots, ports, and receptacles on the Content Engine back panel.

Model Product Number

Content Engine 510 CE-510A-80GB-K9

CE-510A-160GB-K9

Content Engine 565 CE-565A-72GB-K9

CE-565A-144GB-K9

Installing the Cisco Content Engine 510 and 565

78-14731-02

Description

Figure 2 Content Engine 510 and 565 Back Panel

Models can be configured with either a Fibre Channel card or an MPEG A/V decoder card. These cards

are user-replaceable and are installed in Peripheral Component Interconnect (PCI) slot 1 (labeled 2 in

Figure 2).

Figure 3 shows the Content Engine with a Fibre Channel card installed, and Figure 4 shows the

Content Engine with an MPEG A/V decoder card installed.

Figure 3 Content Engine 510 and 565 Back Panel—Fibre Channel Card Installed

Figure 4 Content Engine 510 and 565 Back Panel—MPEG A/V Decoder Card Installed

1AC power receptacle 2PCI slot 1; Fibre Channel or MPEG A/V

decoder ports

3Serial port 4Ethernet 2 receptacle

5Ethernet 1 receptacle 6Onboard video port (not supported)

7Mouse port (not supported) 8Keyboard port (not supported)

9PCI slot 2; SCSI adapter and port (CE-565

only)

83108

1 2

4 378 569

8328583286

Installing the Cisco Content Engine 510 and 565

78-14731-02

Installation Prerequisites

Consider the following prerequisites before installing your Content Engine.

Tools and Parts Required

A sliding rail rack-mount kit and cable management assembly are included in your shipping container

accessory box. The rack-mount kit is suitable for mounting Content Engine 510 and 565 units in 19-inch

(48.26-cm) 4-post equipment racks.

Note A 2-post rack-mounting option contains angle brackets for attaching the chassis to a 2-post rack.

You need the following tools for the installation:

•Flat-blade screwdriver

•Phillips screwdriver

Figure 5 shows the parts that you need to install the Content Engine in an equipment rack. If any parts

are missing or damaged, contact your place of purchase.

Figure 5 Rack Installation Kit

83198

Installing the Cisco Content Engine 510 and 565

78-14731-02

Safety Guidelines

Note The right and left slide rails are identical.

Safety Guidelines

To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment, observe the

following precautions.

Warning

Never defeat the ground conductor or operate the equipment in the absence of a suitably installed

ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are

uncertain that suitable grounding is available.

Warning

The safety cover is an integral part of the product. Do not operate the unit without the safety cover

installed. Operating the unit without the cover in place will invalidate the safety approvals and pose

a risk of fire and electrical hazards.

Warning

Blank faceplates and cover panels serve three important functions: they prevent exposure to

hazardous voltages and currents inside the chassis; they contain electromagnetic interference (EMI)

that might disrupt other equipment; and they direct the flow of cooling air through the chassis. Do not

operate the system unless all cards, faceplates, front covers, and rear covers are in place.

Warning

Only trained and qualified personnel should be allowed to install, replace, or service this equipment.

Warning

This unit is intended for installation in restricted access areas. A restricted access area is where

access can only be gained by service personnel through the use of a special tool, lock and key, or

other means of security, and is controlled by the authority responsible for the location.

Warning

Class 1 laser product.

1Slide rail assemblies (2) 2M3.5 screws with lock washers (3)

3M4 screws (6) 4M6 screws (10)

5Clip nuts (10) 6Cage nuts (10)

7Cage nut insertion tool (1)

This manual suits for next models

Table of contents

Other Cisco Network Hardware manuals

Cisco

Cisco GS7000 User manual

Cisco

Cisco Edge Concentrator MGX 8220 Reference manual

Cisco

Cisco AIR-BR1410A-A-K9 - Aironet 1410 Wireless... User manual

Cisco

Cisco ONS 15454 SDH E1-75 User manual

Cisco

Cisco Performance Routing Engine 5 Manual

Cisco

Cisco 3600 Series Operating and safety instructions

Cisco

Cisco SA520-K9 - SA 500 Series Security Appliances User manual

Cisco

Cisco ONS 15454 Instruction Manual

Cisco

Cisco DOC 785983 User manual

Cisco

Cisco ONS 15600 User manual

Cisco

Cisco PIX Series Manual

Cisco

Cisco RSP4+ Bootflash Memory Upgrade to 16MB... Operator's manual

Cisco

Cisco C7200-I - Input/Output Controller - Control... User manual

Cisco

Cisco ONS 15454 User manual

Cisco

Cisco Meraki Catalyst 9300/X/L-M Series User manual

Cisco

Cisco 5400 Instruction Manual

Cisco

Cisco ONS 15454 DWDM User manual

Cisco

Cisco NCS 4201 Manual

Cisco

Cisco Catalyst X6148 User manual

Cisco

Cisco CVPN3002-K9 - Fast Ethernet VPN Gateway User manual

Cisco

Cisco CPS-MSP-1RU-K9 User manual

Cisco

Cisco MERAKI MR57 User manual

Cisco

Cisco CX-TRIP2 Operator's manual

Cisco

Cisco Firepower 1010 Series Manual

Popular Network Hardware manuals by other brands

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL product manual

B&B Electronics

B&B Electronics ZXT9-IO-222R2 product manual

Yudor

Yudor YDS-16 user manual

D-Link

D-Link ShareCenter DNS-320L datasheet

Samsung

Samsung ES1642dc Hardware user manual

Honeywell Home

Honeywell Home LTEM-PV Installation and setup guide

evertz

evertz 7700 Series manual

D-Link

D-Link ShareCenter DNS-343 Quick installation guide

Asante

Asante AsanteBridge 1012 user guide

FireBrick

FireBrick FB2700 user manual

Audiovox Electronics

Audiovox Electronics ARWH2T user manual

ADC

ADC DSX-1 Operational Procedures Guide

NetComm

NetComm NF2 user guide

Alcatel-Lucent

Alcatel-Lucent 5620 user guide

Dell EMC

Dell EMC XC6420 Series Solution guide

Lanner

Lanner NCA-1020A user manual

Allied Telesis

Allied Telesis AT-TN121-A Specifications

Arista

Arista CCA-ETM-Q12 quick start guide
