MODEL HD100AQ
CElabs’ HD100AQ digital receiver and signal distribution hub is a versatile STB for receiving HDTV content. The
HD100AQ decodes both ATSC and QAM signals and can utilize existing RF/coax wiring. For ease of installation,
this digital receiver and signal distribution hub comes with standard component video and HDMI outputs.
© 2006 Cable Electronics, Inc. CEX and CElabs are registered trademarks of Cable Electronics, Inc. All rights
reserved. CE0035-120106
ISupports closed caption functions based on FCC’s requirements
• Digital services (CS1 / 2 / 3 / 4 / 5 / 6, CC_Mute)
• Digital caption size (default / small / large), color (default / red / green / blue / etc.),
style (default / style1 / style2..../ style7), background color (default / red / green / blue / etc.)
and edge options
IUp/down channels (digital only)
ISupport alternate channel tuning functionality along with auto-programming and channel
edit of the favorite channel list
ISupport AV control for the V-chip features, SCTE20/21 closed captioning and RCU control
IMute/unmute audio outputs and freezing of the video output
ILanguage of menu OSDs (English, Mexican Spanish)
IAC-3 decoding and mute control
IControl the data format of SPDIF output (AC3/PCM)
IHandle time zone, daylight saving time to get the current time for the on-timer functionality
IProcess in-band EA (Emergency Alert) for cable
IVideo output resolution is 480p @ 59.9 Hz, 720p @ 59.9 Hz, 1080i @ 29.97 Hz
ISupport menu graphics: menu design is designed for 4:3 and 16:9 TV screen
ISupport “pan & scan” and “letter box” display of wide screen contents
HDTV
DIGITAL
Decodes ATSC
and QAM Signals
HDTV content from local
broadcast and cable
3209 Wood Drive
Garland, Texas 75041
www.celabs.net
IHDMI and component outputs
ITune a specific channel - the module will tune based on a menu selection of terrestrial vs. cable mode
DESCRIPTIONS
Associated standard Comments
NTSC Not supported
ATSC 8VSB from antenna
NTSC Not supported
ATSC 8VSB on Cable
QAM In-the-clear 64/256 QAM
INPUT
RF Antenna Input
RF Cable Input
