Canon Printing Using a Direct Camera/Printer Connection Guide Direct... Instruction Manual

Direct Print User Guide

Printing Using a Direct Camera/Printer Connection

Guide d’utilisation de l’impression directe

Imprimer au moyen d’une connexion directe appareil photo/imprimante

Guía del usuario de impresión directa

Impresión mediante una conexión directa entre una cámara y una impresora

zDepending on your camera model, some printing instructions may also be included

in the Camera User Guide. However, you must read this guide as well for complete

printing instructions.

zSelon le modèle d’appareil photo, certaines instructions d’impression peuvent aussi

se trouver dans le Guide d’utilisation de l’appareil photo. Vous devez cependant lire

également le présent guide pour disposer de l’ensemble des instructions

d’impression.

zDependiendo de su modelo de cámara, algunas instrucciones de impresión también

pueden aparecer en la Guía de usuario de la cámara. Sin embargo, deberá leer

también esta guía para tener unas instrucciones de impresión completas.

ESPAÑOL

FRANÇAIS

ENGLISH

Direct Print User Guide

Printing Using a Direct Camera/Printer Connection

Depending on your camera model, some printing instructions may also be included in

the Camera User Guide. However, you must read this guide as well for complete

printing instructions.

The following printers can be connected to your camera. Printing operations may vary

depending on your printer model. After you have connected the camera to the printer,

check the icon that appears in the upper left corner of the camera’s LCD monitor and

refer to the relevant pages accordingly.

* When connecting a Non-Canon PictBridge Compliant camera, please refer to the camera’s user guide.

** CP-100/CP-10: Direct Interface Cable DIF-100 (Supplied with the printer)

Confirm Your Printer Model

zFor camera and printer connection instructions, please refer to page 5.

Printer

Canon Printer Non-Canon

PictBridge

Compliant

Printers

CP Printer Bubble Jet Printer

PictBridge

Compliant*

Canon

Direct Print

Compatible

PictBridge

Compliant*

Canon

Direct Print

Compatible

Cable

USB Interface Cable

IFC-300PCU**

(Supplied with the camera)

USB Interface

Cable

IFC-300PCU

(Supplied with the

camera)

See your

Bubble Jet

printer’s user

guide.

USB Interface

Cable

IFC-300PCU

(Supplied with the

camera)

LCD

Monitor

Display

PictBridge Compliance

This camera complies with the industry standard “PictBridge”*. This allows you to also

connect your camera to non-Canon PictBridge compliant printers and print images

with simple operations using the camera buttons.

* PictBridge: PictBridge is a new industry standard for direct printing that allows you to print images

without using a computer by directly connecting digital cameras and digital camcorders (hereafter

“camera”) to a printer, regardless of the devices’ brand and model.

Printing Selected Images with DPOF Settings

This option allows you to select images for printing and print settings, such as the

number of copies, with the camera (DPOF* print settings). This is very

convenient when you want to print several images at once or have them printed

at a photo lab.

* Digital Print Order Format

Please see the Camera User Guide for details on how to select DPOF print settings.

This guide explains how to print images that have already been selected.

Canon Direct

Printing with

CP Printers

p. 6 – 12

PictBridge

Printing with

Bubble Jet

Printers

p. 13 – 21

Canon Direct

Printing with

Bubble Jet

Printers

p. 22

PictBridge

Printing with

Non-Canon

Printers

p. 23

Table of Contents

Read This First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Camera/Printer Connection . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Canon Direct Printing with CP Printers . . . . . . . . . . . . . .6

PictBridge Printing with Bubble Jet Printers . . . . . . . . .13

Canon Direct Printing with Bubble Jet Printers. . . . . . .22

PictBridge Printing with Non-Canon Printers . . . . . . . .23

Settings that Can Be Set with the Camera . . . . . . . . . . . . . .24

Trademark Acknowledgements

zCanon, PowerShot and Bubble Jet are trademarks of Canon, Inc.

zOther names and products not mentioned above may be registered trademarks or

trademarks of their respective companies.

Disclaimer

zNo part of this guide may be reproduced, transmitted, transcribed, stored in a

retrieval system, or translated into any language in any form, by any means, without

the prior written permission of Canon.

zCanon reserves the right to change the specifications of the hardware described

herein at any time without prior notice.

zWhile every effort has been made to ensure that the information contained in this

guide is accurate and complete, no liability can be accepted for any errors or

omissions.

zCanon makes no warranties for damages resulting from corrupted or lost data due

to a mistaken operation or malfunction of the camera, the software, the memory

cards, personal computers, peripheral devices, or use of non-Canon memory

cards.

Read This First

Preparing the Camera and the Printer

* Some camera models do not come with a compact power adapter.

Connecting the Camera to the Printer

Please refer to page 5 to correctly connect your camera.

zFor details regarding the printer connection settings, refer to the user guide that

came with it.

Printing

Use the camera controls to select settings and start printing. Some printers may be

equipped with an operation panel, but printing cannot be performed from the panel.

Printing operations may vary depending on your printer model. Please refer to the

reference pages in the Confirm Your Printer Model section (p. 2).

Printing Procedures

Camera When printing, the use of the compact power adapter* (separately sold

and/or included with the camera) is recommended. If a battery pack or

batteries are used, be sure to use a fully charged battery pack or new

batteries. For details, see the Camera User Guide.

Printer Please refer to the user guide that came with your printer and make the

necessary preparations (paper, ink cassette, cartridge, etc.).

For the latest information regarding connections between Canon printers and

cameras, please refer to the following URL:

http://web.canon.jp/Imaging/BeBit-e.html

Camera/Printer Connection

Connect the camera to the printer using the following procedures. (Please refer to your

printer user guide for details about the printer connection.)

zOnce the camera and printer are ready for printing, the , or icon appears

on the camera’s LCD monitor.

zPrinting procedures differ according to the icon that appears on the LCD monitor

(p. 2).

Before You Connect the Camera

zPrepare the printer. (Refer to the printer’s user guide.)

zConfirm which connection cable should be used (see page 2).

Connect the camera to the printer.

Turn the printer’s power on.

Set the camera to Playback mode and turn the power on.

Some camera models power up when the printer’s power is turned on.

, or appears on the upper left corner of the LCD

monitor. You can now print.

zThe following operations are not available during a camera/printer connection.

• Movie playback.

• Language settings that use the SET button and the MENU button.

Disconnecting the Camera and the Printer

1. Detach the cable from the printer.

2. Turn the camera’s power off.

3. Detach the cable from the camera.

• When you detach the cable, hold the plug and do not pull by the cable.

Camera: Connect the cable to the DIGITAL terminal.

Printer: Refer to the printer's user guide.

To Printer

This illustration shows the PowerShot S400DIGITAL ELPH/

DIGITAL IXUS 400 as an example.

DIGITAL terminal

Canon Direc

Printing with CP Printer

Printing

Make sure that displays in the

upper left corner of the LCD monitor.

Display the images you wish to print

and press the SET button.

The print order screen appears.

Select print settings as required.

Select [Print] and press the SET button.

You cannot print movies or images recorded in the RAW format.

Cancel Printing

zTo cancel printing between images printed, press the SET button. Once the

current print is finished, a confirmation dialog appears. Select [OK] and press

the SET button.

Printing Errors

zAn error message appears if an error occurs for some reason during the

printing process. Select [Stop] or [Resume] and press the SET button.

The [Resume] option may not appear with some types of errors. In that case,

select [Stop].

Print Order Screen

Setting the Print Style (p. 7)

Selecting the Number of Copies (p. 7)

Setting the Printing Area (Trimming) (p. 8)

Canon Direct Printing with CP Printers

Selecting the Number of Copies

Setting the Print Style

You can select from among the following print styles.

* This option can be selected when printing on card size paper.

Selecting Print Settings

In the print order screen, select [Copies] and specify the

number of copies.

You can specify from 1 to 99 prints.

Image Standard Prints one image per page.

Multiple* Prints eight copies of the same image on one page.

Borders Borderless Prints right to the edges of the page.

Bordered Prints with a border.

Date On Adds the date to the print.

Off Prints without the date.

In the print order screen, select [Style] and press the SET

button.

Select [Image], [Borders], or [Date].

Select settings as needed.

Canon Direct Printing with CP Printers

Setting the Printing Area (Trimming)

You can specify which portion of an image gets printed.

Please set the Print Style (Image, Paper, Borders and Date) first before setting the

trimming settings. If the print style is changed after having made trimming settings, you

must select the settings again.

Press the MENU button to end the

setting selection process.

With borderless or multiple prints, the top, bottom and

sides of the image may be cropped slightly. If you

have not specified a trimming setting, a frame will

appear around the area of the image that will be

printed, allowing you to check the portion that will be

cropped.

zWhen printing multiple prints, the borders and the date cannot be set. (Images

are printed without any date or borders)

zPractically all of the image area displayed on the LCD monitor is printed on

bordered prints.

With the PowerShot A60, the printing area settings differ. Please refer to the

Specifying the Printing Area (PowerShot A60) section in the Camera User Guide.

In the print order screen, select

[Trimming] and press the SET button.

The trimming frame will appear at the center of the

image. If a trimming setting has already been selected

for the image, the frame will appear around the

previously selected portion.

The trimming setting screen differs depending on the camera model. Check which

of the following screens appear before selecting settings.

Print Area Frame

Steps 2a and 3a

Trimming Frame

Steps 2b and 3b

This manual suits for next models

Table of contents

Languages:

Other Canon Printer manuals

Canon

Canon PIXMA MG5600 Series User manual

Canon

Canon iR6570 series Operating and maintenance manual

Canon

Canon imageprograf IPF785 User manual

Canon

Canon MX490 Series Setup guide

Canon

Canon MG5100 series User manual

Canon

Canon iPF500 - imagePROGRAF Color Inkjet Printer User manual

Canon

Canon imageRUNNER ADVANCE DX C478iZ Installation guide

Canon

Canon Pixma TS7700i Series User manual

Canon

Canon IRC2100 User manual

Canon

Canon PIXMA mini260 User manual

Canon

Canon PIXMA iP6000D User manual

Canon

Canon W8200 Installation and maintenance instructions

Canon

Canon imageRUNNER 1750iF User manual

Canon

Canon imageRUNNER 2320 User manual

Canon

Canon imageCLASS MF5950dw Service manual

Canon

Canon wordtank M600 User manual

Canon

Canon PIXMA TS9020 Setup guide

Canon

Canon i455 Series Manual

Canon

Canon Laser Shot LBP5000 User manual

Canon

Canon iPF6100 - imagePROGRAF Color Inkjet Printer User manual

Canon

Canon MX537 User manual

Canon

Canon LBP-2510 User manual

Canon

Canon SELPHY CP1500 Assembly instructions

Canon

Canon Image Prograf PRO-2000 User manual

Popular Printer manuals by other brands

Lexmark

Lexmark 1400 Series Manual

Evolis

Evolis Elypso user guide

Kyocera

Kyocera FS-9530DN specification

Samsung

Samsung BIXOLON SRP-350plusF user manual

Dell

Dell Color Laser Printer 2130cn user guide

Tektronix

Tektronix Phaser 840 user guide

Epson

Epson ET-7750 Programming guide

Eltron

Eltron P210 Guide manual

Ricoh

Ricoh MD-P1 Service manual

Epson

Epson SC-F7100 series user guide

Epson

Epson Stylus C40UX Service manual

IRA3D

IRA3D POETRY4 Original instructions

Ricoh

Ricoh Aficio AP400 operating instructions

BIXOLON

BIXOLON SRP-352plusV user manual

Epson

Epson Stylus Photo PX700W Basic operation guide

Ricoh

Ricoh SP204SF user guide

Star Micronics

Star Micronics futurePRNT TSP100 Hardware manual

Epson

Epson TM-TM88V-i Technical reference guide
