Canon PIXMA TS5365 User manual

Démarrage

Commencez par lire Sécurité et informations

importantes (addendum).

Conﬁguration en ligne

Des instructions détaillées et des vidéos

sont disponibles sur le site Web de Canon.

Conﬁgurer un ordinateur

Conﬁgurer un smartphone

Getting Started

Read Safety and Important Information

(addendum) ﬁrst.

Online Setup

Detailed instructions and videos are

available on the Canon website.

Setup a Computer

Setup a Smartphone

Accéder

Installation de l'imprimante..................................................................................................page 1

Connexion à un ordinateur, un smartphone ou une tablette.........................page 4

Instructions vidéo

Manipulation de l'imprimante

Installing the Printer...................................................................................................................page 1

Connecting to a Computer, Smartphone or Tablet...............................................page 4

Holding the Printer

Instructional Videos

ENGLISH

Setting Up the Printer

1. Box Contents

•

FINE cartridges

Color Black

•

Power cord

•

Setup CD-ROM for Windows

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

2 Open the scanning unit / cover, remove and

dispose of the orange tape and protective

material inside.

3 Close the scanning unit / cover.

• Open the scanning unit / cover fully and then close it.

Caution

Watch your ﬁngers.

3. Turning on the Printer

1 Connect the power cord.

Back

Important

At this time, do not connect any other cables.

2 Press the ON button.

3 Use the {, }and OK buttons to select a

language.

4 Press the OK button.

Important

Scan the QR code for a video tutorial of the setup procedure.

5 Use the {and }buttons to check the on-

screen content, and then press the OK button.

Setting Up the Printer

Installing the FINE Cartridges

1 Open the scanning unit / cover.

Caution

Do not touch the FINE cartridge holder until it stops moving.

2 Pinch and open the ink cartridge locking cover

on the left-hand side.

3 Remove the Color FINE cartridge from the

container and remove the protective tape.

aColor

Important

• Do not touch the ink on the protective tape. It could stain

your hands or surrounding objects.

• Do not touch the areas shown in the

ﬁgure. Otherwise, the printer may not

print correctly.

4 Set the Color FINE cartridge in the FINE

cartridge holder.

Important

Do not bump the FINE cartridge.

Doing so may cause a malfunction.

5 Push down the ink cartridge locking cover ﬁrmly

until it snaps into place to close it completely.

6 Repeat steps 2 to 5 and install the Black FINE

cartridge as well, on the right-hand side.

7 Close the scanning unit / cover.

• The printer will start initializing.

Caution

Watch your ﬁngers.

ENGLISH

5. Loading Paper

1 Press the OK button.

2 Remove the cassette from the printer and

remove the cassette cover.

Cassette cover

3 Slide apart the paper guides.

• Slide the right paper guide to the right edge. Align

the front paper guide with the Letter or A4 mark.

4 Load paper.

• Load 2 or more sheets of Letter or A4 sized plain

paper with the print side facing down.

• Place the paper against the front paper guide, and

align the right paper guide to the width of the paper.

5 Attach the cassette cover and replace the

cassette.

• Look at it from the side to conﬁrm

it looks like the diagram.

6 Pull out the paper output tray.

7 Press the OK button.

8 Press the OK button.

Important

Scan the QR code for a video tutorial of the setup procedure.

9 Check that the following screen appears.

If you will use the printer without connecting any other

devices, setup is now complete.

6-a

Setting Up the Printer

Computer Smartphone

Computer and

smartphone

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website from a

computer.

2 Select Set Up.

3 Enter your printer's model name and

click Go.

4 Click Start.

5 Click If you have already prepared

your printer, go to Connect.

Note

The following steps are for Windows (except

Windows 10 in S mode) and macOS users. For other

operating systems, continue setup by following the

on-screen instructions instead.

6 Click Download.

7 Run the downloaded ﬁle.

8 Click Start Setup.

9 Follow the on-screen instructions.

• These operations may take some time.

• To connect to a smartphone as well, see "6-b.

Connecting to a Smartphone" on page 5.

Using the Setup CD-ROM for Windows

Double click EasySetup.exe in the CD-ROM, and then continue from step 3. If you do not have an

internet connection, open the win folder in the CD-ROM and double click SETUP.exe. This will install

the printer driver.

What device are you connecting?

6-a.Connecting to a Computer

6-b

ENGLISH

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

• Scan the QR code shown on the right to access the Canon website, and then

download the app.

2 Open the installed app.

3 Follow the on-screen instructions in the app to add your printer.

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Prepare the following before starting.

aEnable the Wi-Fi setting on your smartphone.

bConnect your smartphone to the wireless router (if you have a wireless router).

Refer to your smartphone and wireless router manuals for more details.

6-b. Connecting to a Smartphone

Once you have added your printer, you can print from your smartphone.

To print photos, see "Loading Photo Paper" on page 6.

Loading Photo Paper

1 Open the rear tray cover and extend the paper

support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of photo paper with the

print side facing up and slide the side paper

guide against the edge of the paper stack.

4 Close the feed slot cover.

• Follow the on-screen instructions to set information

for the loaded paper.

Copying

Photo paper can only be loaded in the rear tray.

1 Turn on the printer.

2 Load Letter or A4 sized plain paper.

3 Open the document cover and place the

document face down on the platen. Align the

document with the alignment mark ( ).

4 Close the document cover.

5 Press the OK button.

6 Select Copy settings, and then press the OK

button.

7 Specify print settings using the {, }and OK

buttons.

8 Press the Start button.

FRANÇAIS

Conﬁguration de l'imprimante

1. Contenu de la boîte

•

Cartouches FINE

Couleur Noire

•

Cordon d'alimentation

•

CD-ROM d'installation pour Windows

•

Sécurité et informations importantes

•

Démarrage (ce manuel)

2. Retrait du matériel

d'emballage

1 Enlevez et jetez tout matériel d'emballage et

bande orange.

2 Ouvrez l'unité de numérisation / capot, retirez et

jetez tout bande orange et matériau protecteur

se trouvant à l'intérieur.

3 Fermez l'unité de numérisation / capot.

• Ouvrez complètement l'unité de numérisation / capot,

puis fermez-la.

Attention

Surveillez vos doigts.

3. Mise sous tension de

l'imprimante

1 Branchez le cordon d'alimentation.

Arrière

Important

À ce stade, ne branchez aucun autre câble.

2 Appuyez sur le bouton MARCHE (ON).

3 Utilisez les boutons {, }et OK pour

sélectionner une langue.

4 Appuyez sur le bouton OK.

Important

Numérisez le code QR pour obtenir un didacticiel vidéo de la

procédure de conﬁguration.

5 Utilisez les boutons {et }pour vériﬁer le

contenu à l'écran, puis appuyez sur le bouton OK.

Conﬁguration de l'imprimante

Installation des cartouches

FINE

1 Ouvrez l'unité de numérisation / capot.

Attention

Ne touchez pas le porte-cartouche FINE avant son arrêt.

2 Pincez et ouvrez le couvercle de verrouillage de

cartouche d'encre sur la gauche.

3 Retirez la cartouche FINE couleur du conteneur

et retirez le ruban protecteur.

aCouleur

Important

• Ne touchez pas l'encre se trouvant sur le ruban protecteur. Cela

pourrait salir vos mains ou les objets environnants.

• Ne touchez pas les zones présentées

dans la ﬁgure. Sinon, l'imprimante

pourrait ne pas imprimer correctement.

4 Installez la cartouche FINE couleur dans le

porte-cartouche FINE.

Important

Ne cognez pas la cartouche FINE.

Cela risquerait d'entraîner un

dysfonctionnement.

5 Poussez fermement vers le bas le couvercle

de verrouillage de cartouche d'encre jusqu'au

déclic pour le fermer complètement.

6 Répétez les étapes 2 à 5 et installez également

la cartouche FINE noire sur la droite.

7 Fermez l'unité de numérisation / capot.

• L'imprimante commence à s'initialiser.

Attention

Surveillez vos doigts.
