Canon Pixma TS3400 Series User manual
Démarrage
Commencez par lire Sécurité et informations
importantes (addendum).
Getting Started
Read Safety and Important Information
(addendum) rst.
Manipulation de l'imprimante
Connexion à un ordinateur, un smartphone ou une tablette.........................page 4
Installation de l'imprimante..................................................................................................page 1
Installing the Printer...................................................................................................................page 1
Connecting to a Computer, Smartphone or Tablet...............................................page 4
Holding the Printer
1
ENGLISH
Setting Up the Printer
1. Box Contents
•
FINE cartridges
Color Black
•
Power Cord
•
Safety and Important Information
•
Getting Started (this manual)
2. Removing Packing Materials
1 Remove the orange tape on the right and open
the cover.
2 Remove the orange tape on the left.
3 Close the cover.
3. Turning on the Printer
1 Connect the power cord.
Back
2 Press the ON button.
Important
If another screen appears, see "If any of the following screens
appear" on page 3 and follow the instructions.
For Setup, visit the URL
https://ij.start.canon
or scan the code with your mobile device
•
Follow the instructions below if you do not have an internet connection.
2
Setting Up the Printer
4.
Installing the FINE Cartridges
1 Open the cover.
Caution
Do not touch the FINE cartridge holder until it stops moving.
2 Lower the ink cartridge lock lever on the left-
hand side.
3 Remove the Color FINE cartridge from the
package and remove the protective tape.
b
a
Important
• Do not touch the ink on the protective tape. It could stain
your hands or surrounding objects.
• Do not touch the areas shown in the gure.
Otherwise, the printer may not print correctly.
4 Insert the Color FINE cartridge in the FINE
cartridge holder.
Important
Do not bump the FINE cartridge. Doing
so may cause a malfunction.
5 Raise the ink cartridge lock lever.
6 Repeat steps 2 to 5 and install the Black FINE
cartridge on the right-hand side.
7 Close the cover.
3
ENGLISH
8 Check that the following screen appears.
Important
If E > 0 > 4 appears on the screen, see "If any of the following
screens appear" on page 3 and follow the instructions.
Select the connection method that best matches how you
will use the printer.
• To use the printer without connecting to any other
devices
Setup is now complete.
• To use the printer connecting to a computer or
smartphone
Proceed to the next page.
Check the screen, and then follow the corresponding
instructions below.
Install the FINE cartridges.
"4. Installing the FINE Cartridges" on page 2
Protective material remaining.
"2. Removing Packing Materials" on page 1
FINE cartridges are not installed correctly.
"4. Installing the FINE Cartridges" on page 2
For all other cases, refer to the Online Manual.
If any of the following screens appear
Numbers or letters
5-a
4
Setting Up the Printer
Computer Smartphone
Computer and
smartphone
Connecting to a Computer
If you are using multiple computers, perform these steps on each computer.
1 Access the Canon website from your computer.
2 Select Set Up.
3 Enter your printer's model name and click Go.
4 Click Start.
5 Click (B) Connecting to a Computer/Smartphone.
• The following steps are for Windows users.
6 Click Download.
7 Run the downloaded le.
• Follow the on-screen instructions.
• These operations may take some time.
• To connect to a smartphone as well, see "5-b. Connecting to a Smartphone" on page 5.
What device are you connecting?
5-a Connecting to a Computer
5-b
5
ENGLISH
5-b. Connecting to a Smartphone
1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.
• Search for "Canon PRINT" in App Store, or Google Play.
• Access the Canon website to download the app.
2 Open your smartphone's Wi-Fi settings. Check that the network name (SSID) that starts
with "Canon_ij_" appears.
(Example of iOS screen)
The network name (SSID) that starts with "Canon_ij_"
• If "Canon_ij_" appears Proceed to step
3
.
• If "Canon_ij_" does not appear Proceed to step
4
.
3 Tap the network name (SSID) that starts with "Canon_ij_".
4 Open the installed app, and follow the on-screen instructions in the app to add your
printer.
Connecting to a Smartphone
If you are using multiple smartphones, perform these steps on each smartphone.
Once you have added your printer, you can print from your smartphone.
To print photos, see "Loading Paper" on page 6.
6
Loading Paper
1 Open the paper support.
2 Slide the paper guide to the left.
3 Load several sheets of paper against the right
edge with the print side facing up and align the
paper guide to the width of the paper.
a
b
4 Press the Paper Select button, select a paper
size, and then press the OK button.
5 Extend the paper output tray, and open the
output tray extension.
• Look at it from the side to conrm it looks like the
diagram.
If Print Results Are Unsatisfactory
Perform Print Head Alignment if straight lines are crooked or colors are inconsistent, or print results are otherwise not what you
expected.
For details, click Maintenance on the Online Manual and refer to If Printing Is Faint or Uneven > Aligning the Print Head.
Refer to the back cover for how to access the Online Manual.
■Lines Are Misaligned ■Uneven or Streaked Colors
1
FRANÇAIS
Conguration de l'imprimante
1. Contenu de la boîte
•
Cartouches FINE
Couleur Noire
•
Cordon d'alimentation
•
Sécurité et informations importantes
•
Démarrage (ce manuel)
2. Retrait du matériel
d'emballage
1 Retirez la bande orange de droite et ouvrez le
capot.
2 Retirez la bande orange de gauche.
3 Fermez le capot.
3. Mise sous tension de
l'imprimante
1 Branchez le cordon d'alimentation.
Arrière
2 Appuyez sur le bouton MARCHE (ON).
Important
Si un autre écran s'ache, reportez-vous à la section «Si un
des écrans suivants s'ache» à la page 3 et suivez les
instructions.
Pour la conguration,
rendez-vous sur l'URL
https://ij.start.canon
ou numérisez le code avec votre appareil mobile
•Suivez les instructions ci-dessous si vous ne disposez d'aucune connexion à Internet.
2
Conguration de l'imprimante
4.
Installation des cartouches
FINE
1 Ouvrez le capot.
Attention
Ne touchez pas le porte-cartoucheFINE avant son arrêt.
2 Abaissez le levier de verrouillage de cartouche
d'encre sur la gauche.
3 Retirez la cartouche FINE couleur du paquet et
retirez le ruban protecteur.
b
a
Important
• Ne touchez pas l'encre se trouvant sur le ruban protecteur.
Cela pourrait salir vos mains ou les objets environnants.
• Ne touchez pas les zones présentées dans
la gure. Sinon, l'imprimante pourrait ne pas
imprimer correctement.
4 Insérez la cartouche FINE couleur dans le porte-
cartouche FINE.
Important
Ne cognez pas la cartouche FINE.
Cela risquerait d'entraîner un
dysfonctionnement.
5 Relevez le levier de verrouillage de cartouche
d'encre.
6 Répétez les étapes2 à5 et installez la cartouche
FINE noire sur la droite.
7 Fermez le capot.
