Canon PIXMA G7000 Series User manual

Guía de inicio

Lea primero Información de seguridad

e información importante (apéndice).

Conguración en línea

Hay vídeos e instrucciones detalladas en

el sitio web de Canon.

Congurar un ordenador

Congurar un teléfono inteligente

Getting Started

Read Safety and Important Information

(addendum) rst.

Online Setup

Detailed instructions and videos are

available on the Canon website.

Setup a Computer

Setup a Smartphone

Instalación de la impresora ...............................................................................................página 1

Conexión con un ordenador, teléfono inteligente o tableta.......................página 4

Vídeos instructivos

Cómo sujetar la impresora

Installing the Printer...................................................................................................................page 1

Connecting to a Computer, Smartphone or Tablet...............................................page 4

Holding the Printer

Instructional Videos

ENGLISH

Setting Up the Printer Online Setup

1. Box Contents

•

Print heads •

Ink bottles

•

Power cord

•

Modular cable

•

Setup CD-ROM for Windows

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

2 Open the scanning unit / cover, remove and

dispose of the orange tape and protective

material inside.

3. Installing the Print Heads

1 Open the print head locking cover.

2 Take out each print head from the package and

remove the label.

3 Remove the protective tape.

4 Insert the C (color) print head on the left and the

B (black) print head on the right.

5 Close the print head locking cover and press

down until it clicks.

6 Press down both joint buttons completely until

they click.

Check!

Setting Up the Printer

4. Pouring Ink

Important

This product requires careful handling of ink. Ink may splatter

when the ink tanks are lled with ink. If ink gets on your clothes or

belongings, it may not come o.

1 Open the ink tank cover and tank cap on the left

of the printer.

2 Hold the ink bottle upright and gently twist the

bottle cap to remove.

Check!

PGBK

3 Align the nozzle of the ink bottle with the inlet.

4 Slowly stand the ink bottle upside down and

push down to pour the ink.

• If the ink does not pour, gently remove the ink bottle

and try again.

5 Gently remove the ink bottle from the inlet.

• Be careful not to spill the ink.

6 Replace the tank cap securely, and then close

the ink tank cover.

7 Repeat steps 1 through 6 to pour all ink into the

corresponding ink tanks on the right.

Check!

CMY

8 Close the scanning unit / cover.

Caution

Watch your ngers.

5. Turning on the Printer

1 Connect the power cord.

Back

Important

At this time, do not connect any other cables.

2 Open the operation panel and press the ON

button.

ENGLISH

3 When the following screen appears, use the [

and ]buttons to select a language, and then

press the OK button.

Important

If an error appears on the screen, see "If an error message

(support code) appears on the screen" on page 3 and

follow the instructions.

4 If the country or region selection screen

appears, use the [and ]buttons to select

your country or region, and then press the OK

button.

6. Loading Paper

1 When the following screen appears, use the [

and ]buttons to select Yes , and then press the

OK button.

2 Remove the cassette from the printer.

3 Slide apart the paper guides.

• Slide the right paper guide to the right edge. Align

the front paper guide with the Letter or A4 mark.

4 Load paper.

• Load 2 or more sheets of Letter or A4 sized plain

paper with the print side facing down.

• Place the paper against the front paper guide, and

align the right paper guide to the width of the paper.

5 Replace the cassette.

6 Pull out the paper output tray.

7 Follow the on-screen instructions, and then

press the OK button.

• Check that Ready to connect appears on the

printer's screen.

Check the support code, and then follow the

instructions if the displayed code is written below.

• 1890

The protective materials are not removed.

"2. Removing Packing Materials" on page 1

• 1470

The print heads are not installed correctly.

"3. Installing the Print Heads" on page 1

• 1471

No print heads are installed.

"3. Installing the Print Heads" on page 1

• 1642

There may be insucient ink.

"4. Pouring Ink" on page 2

For all other cases, refer to the Online Manual.

If an error message (support code) appears on

the screen

Support code

Setting Up the Printer

7-a

Computer Smartphone

Computer and

smartphone

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website from a

computer.

2 Select Set Up.

3 Enter your printer's model name and

click Go.

4 Click Start.

5 Click If you have already prepared

your printer, go to Connect.

Note

The following steps are for Windows (except

Windows 10 in S mode) and macOS users. For other

operating systems, continue setup by following the

on-screen instructions instead.

6 Click Download.

7 Run the downloaded le.

8 Click Start Setup.

9 Follow the on-screen instructions.

• These operations may take some time.

• To connect to a smartphone as well, see "7-b.

Connecting to a Smartphone" on page 5.

Using the Setup CD-ROM for Windows

Double click EasySetup.exe in the CD-ROM, and then continue from step 3. If you do not have an

internet connection, open the win folder in the CD-ROM and double click SETUP.exe. This will install

the printer driver.

What device are you connecting?

7-a.Connecting to a Computer

Not connecting to any other devices 7-c

ENGLISH

7-b

1 Install the "Canon PRINT Inkjet/SELPHY"

app on your smartphone.

• Scan the QR code shown on

the right to access the Canon

website, and then download

the app.

2 Open your smartphone's Wi-Fi settings.

Tap the network name (SSID) that starts

with "Canon_ij_".

If "Canon_ij_" does not appear, proceed

to step 3.

(Example of iOS screen)

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Prepare the following before starting.

aEnable the Wi-Fi setting on your smartphone.

bConnect your smartphone to the wireless router (if you have a wireless router).

Refer to your smartphone and wireless router manuals for more details.

Once you have added your printer, you can print from your smartphone.

To print photos, see "Loading Photo Paper" on page 6.

7-b.Connecting to a Smartphone

3 Open the installed app.

4 Follow the on-screen instructions in the

app to add your printer.

7-c Do Not Connect To A Device

1 Press the Stop button.

2 Select Do not connect, and then press the OK button.

3 Select Ye s, and then press the OK button.

Loading Photo Paper

1 Open the rear tray cover and extend the paper

support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of photo paper with the

print side facing up.

4 Align the paper guide to the paper, and then

close the feed slot cover.

• Follow the on-screen instructions to set information

for the loaded paper.

5 When Save the rear tray paper information

appears on the printer's screen, press the OK

button.

6 Select the paper size and type, and press the OK

button.

Transporting Your Printer

Photo paper can only be loaded in the rear tray.

When relocating the printer, make sure of the following. Refer to the Online Manual for details.

Check that both joint buttons are pressed down

completely to avoid ink leaks.

Check that the position of the ink valve lever is closed.

Pack the printer in a plastic bag in case ink leaks.

• Pack the printer in a sturdy box so that it is placed with its

bottom facing down, using sucient protective material

to ensure safe transport.

• Do not tilt the printer. Ink may leak.

• Please handle with care and ensure the box remains at

and NOT turned upside down or on its side, as the printer

may be damaged and ink in the printer may leak.

• When a shipping agent is handling transport of the

printer, have its box marked "THIS SIDE UP" to keep the

printer with its bottom facing down. Mark also with

"FRAGILE" or "HANDLE WITH CARE".

ESPAÑOL

Instalación de la impresora

Conguración en línea

1. Contenido de la caja

•

Cabezales de impresión •

Frascos de tinta

•

Cable de alimentación

•

Cable modular

•

CD-ROM de instalación para

Windows

•

Información de seguridad e

información importante

•

Guía de inicio (este manual)

2. Retirar los materiales de

protección

1 Retire y tire los materiales de protección y la

cinta naranja.

2 Abra la cubierta/unidad de escaneado, retire

y tire la cinta naranja y el material de protección

que hay dentro.

3. Instalar los cabezales de

impresión

1 Abra la cubierta de bloqueo del cabezal de

impresión.

2 Saque cada cabezal de impresión del paquete

y retire la etiqueta.

3 Retire la cinta protectora.

4 Inserte el cabezal de impresión C (color) a la

izquierda y el cabezal de impresión B (negro)

a la derecha.

5 Cierra la cubierta de bloqueo del cabezal de

impresión y presione hacia abajo hasta que

haga clic.

6 Presione hacia abajo los dos botones de unión

completamente hasta que hagan clic.

¡Comprobar!

Instalación de la impresora

4. Verter la tinta

Importante

Este producto un tratamiento cuidadoso de la tinta, ya que puede

salpicar cuando se rellenan de tinta los depósitos de tinta. Es posible

que las manchas de tinta no salgan de la ropa u otras pertenencias.

1 Abra el cubierta del depósito de tinta y la tapa

del depósito a la izquierda de la impresora.

2 Sujete el frasco de tinta hacia arriba y gire

suavemente la tapa del frasco para retirarla.

¡Comprobar!

PGBK

3 Alinee la boquilla del frasco de tinta con la

entrada.

4 Coloque el frasco de tinta boca abajo despacio

y empuje hacia abajo para verter la tinta.

• Si la tinta no se vierte, retire suavemente el frasco de

tinta e inténtelo de nuevo.

5 Retire suavemente el frasco de tinta de la

entrada.

• Tenga cuidado de no derramar la tinta.

6 Reemplace la tapa del depósito de manera

segura y, a continuación, cierre la cubierta del

depósito de tinta.

7 Repita los pasos del 1 al 6 para verter toda la

tinta en los depósitos de tinta correspondientes

de la derecha.

¡Comprobar!

CMY

8 Cierre la cubierta/unidad de escaneado.

Precaución

Tenga cuidado con los dedos.

5. Encender la impresora

1 Conecte el cable de alimentación.

Atrás

Importante

En este momento, no conecte ningún otro cable.

2 Abra el panel de control y pulse el botón

ACTIVADO (ON).

Other manuals for PIXMA G7000 Series

Table of contents

Languages:

Other Canon Printer manuals

Canon

Canon PIXMA GM4000 Series User manual

Canon

Canon PIXMA Pro9000 Mark II Series User manual

Canon

Canon G2010 Series Setup guide

Canon

Canon LBP-3200 User manual

Canon

Canon PIXMA TS6100 series User manual

Canon

Canon PIXMA TS8160 User manual

Canon

Canon imageRUNNER ADVANCE C9075S PRO Technical manual

Canon

Canon MP-C635 User manual

Canon

Canon TS9120 User manual

Canon

Canon PIXMA MP520 User manual

Canon

Canon MAXIFY GX3070 Instruction Manual

Canon

Canon PIXMA iP2000 Series Instruction Manual

Canon

Canon BJC-2100 Series User manual

Canon

Canon imageCLASS MF414dw User manual

Canon

Canon PIXMA G400 Series User manual

Canon

Canon GX5500 Series Setup guide

Canon

Canon iPF500 - imagePROGRAF Color Inkjet Printer User manual

Canon

Canon PIXMA iP4820 Series User manual

Canon

Canon Pixma iP110 series User manual

Canon

Canon PIXMA TS5365 User manual

Canon

Canon imageRUNNER ADVANCE 400iF Safety guide

Canon

Canon selphy cp1200 User manual

Canon

Canon I450 - i 450 Color Inkjet Printer User manual

Canon

Canon imagePROGRAF iPF8300S User manual

Popular Printer manuals by other brands

Lexmark

Lexmark 1400 Series Manual

Evolis

Evolis Elypso user guide

Kyocera

Kyocera FS-9530DN specification

Samsung

Samsung BIXOLON SRP-350plusF user manual

Dell

Dell Color Laser Printer 2130cn user guide

Tektronix

Tektronix Phaser 840 user guide

Epson

Epson ET-7750 Programming guide

Eltron

Eltron P210 Guide manual

Ricoh

Ricoh MD-P1 Service manual

Epson

Epson SC-F7100 series user guide

Epson

Epson Stylus C40UX Service manual

IRA3D

IRA3D POETRY4 Original instructions

Ricoh

Ricoh Aficio AP400 operating instructions

BIXOLON

BIXOLON SRP-352plusV user manual

Epson

Epson Stylus Photo PX700W Basic operation guide

Ricoh

Ricoh SP204SF user guide

Star Micronics

Star Micronics futurePRNT TSP100 Hardware manual

Epson

Epson TM-TM88V-i Technical reference guide
