Canon PIXMA MX512 User manual

<< Previous Next >>

Installing Your Multifunction

to Your Network for the First Time

PIXMA MX512

Windows OS

<< Previous Next >>

Installing Your Multifunction

to Your Network for the First Time

PIXMA MX512

Windows OS

Preparing to Connect My Multifunction to My Network 3

Network Requirements 3

Notes on Wireless Connection 4

Installing the Drivers & Software 5

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Network Requirements

Before connecting the machine to the network, make sure that configuration of the computer and access point or router is

complete, and that the computer is connected to the network.

Wireless Connection

Before connecting the machine to the network, the computer needs to be connected to the network. Make sure that

configuration of the computer and access point or router is complete.

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Notes on Network Connection

•The configuration, router functions, setup procedures and security settings of

the network device vary depending on your system environment. For details,

refer to your device's instruction manual or contact its manufacturer.

•In an office setup, consult your network administrator

•If you connect to a network that is not protected with security measures, there

is a risk of disclosing data such as your personal information to a third party.

•Place the machine and computer on the same network segment.

An "Ad-hoc connection," which establishes a direct

connection to the computer over a wireless connection

without using an access point, is not supported.

Software Installation

To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk. The

installation process takes about 20 minutes. (The installation time varies depending on the computer environment or the number of application

software to be installed.)

Installing the Drivers & Software

IMPORTANT

•Log on as the administrator (or a member of the Administrators group).

•Quit all running applications before installation.

•Do not switch users during the installation process.

•Internet connection may be required during the installation. Connection fees may apply. Consult the internet service provider.

•It may be necessary to restart your computer during the installation process. Follow the on-screen instructions and do not remove the

Setup CD-ROM during restarting. The installation resumes once your computer has restarted.

•If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting to access

the network. If such a warning message appears, set the security software to always allow access.

<< Previous Next >>

Installing the PIXMA MX512 on Your Wireless Network

If you are installing your printer on your network for the first time, a step-by-step walk through of the wireless setup is built in to the installation

routine of the software that shipped with your PIXMA.

Simply insert the Setup CD-ROM that came with your printer into your CD-ROM drive and proceed through the easy to follow instructions. You’ll

be printing wirelessly in no time. Be sure to select Wireless Connection on the Connection Method Selection screen.

Installing the Drivers & Software

<< Previous Next >>

Installing the Drivers & Software

<< Previous

Installing the PIXMA MX512 on Your Wireless Network

If you can’t find your CD-ROM, you may download the MX510 series Mini Master Setup, which includes the same step-by-step installation as the

CD-ROM, by following the instructions below:

1. Click here to access the MX512 Drivers & Software page.

2. Select the operating system and version of your computer (see example below).

3. Expand the ‘Drivers’ section, if necessary, by clicking the red triangle.

4. Click on ‘MX510 series Mini Master Setup’ .

5. After reading the details and disclaimer,click ‘I Agree – Begin Download’ and save the file to your computer.

6. Once the download is complete, double-click the file from its download location to begin the installation.
