Canon MF735C Series User manual

Getting Started

Quick Operation P.29

Quick Setup NEXT PAGE

Please read "Important Safety Instructions" before operating this product. After you finish

reading this guide, store it in a safe place for future reference.

The information in this document is subject to change without notice.

You can access canon.com/oip-manual

to read the User's Guide that describes all functions of this machine.

Getting Started

Introducción

  



Bắt đầu

Langkah Permulaan

Getting Started

Please read "Important Safety Instructions" before operating

this product.

P.34

After you nish reading this guide, store it in a safe place for

future reference.

The information in this document is subject to change

without notice.

Introducción

Lea las "Instrucciones de seguridad importantes" antes de usar

este producto.

pág.42

Cuando termine de leer esta guía, guárdela en un lugar

seguro para futuras consultas.

La información de este documento puede ser modicada sin

previo aviso.



  



50

   

 

    

 

Bắt đầu

Vui lòng đọc "Các Chỉ dẫn An toàn Quan trọng" trước khi vận

hành sản phẩm này.

Tr.58

Sau khi đọc xong cuốn hướng dẫn này, vui lòng lưu trữ sách

ở nơi an toàn để tham khảo trong tương lai.

Thông tin trong tài liệu này có thể được thay đổi mà không

cần thông báo.

Langkah Permulaan

Sila baca "Arahan Keselamatan Penting" sebelum

mengendalikan produk ini.

P.66

Selepas anda habis membaca panduan ini, simpan dalam

tempat yang selamat untuk rujukan masa akan datang.

Maklumat dalam dokumen ini tertakluk pada perubahan

tanpa notis.

You can access

canon.com/oip-manual to read the User's Guide that

describes all functions of this machine.

Puede acceder a

canon.com/oip-manual para leer la Guía de usuario donde

se describen todas las funciones de este equipo.

 

 





Bạn có thể truy cập vào

canon.com/oip-manual để đọc Hướng dẫn người dùng

trong đó có mô tả tất cả chức năng của máy này.

Anda boleh mengakses

canon.com/oip-manual untuk membaca Panduan Pengguna

yang menerangkan semua fungsi mesin ini.

× 4

Starter toner cartridges are included.

Items Included with the

Machine

Quick Setup

Before starting the installation

• Remove all of the tape.

• Do not remove the cap that covers the USB port.

Cap

Installation Requirements

Provide a space of 100 mm or more around the

machine.

Handset

(optional)

394 mm 469 mm 249 mm

471 mm 73 mm

Cassette feeding

module (optional)

460 mm 276 mm130 mm

Installation of the Machine

Installing the Machine

Quick Setup

Up to here

Installation of the Machine

Quick Setup

Attach the handset (optional).

Quick Setup

Install the cassette feeding

module (optional).

Installation of the Machine

Quick Setup

Next, proceed to configure the machine.

Quick Setup

Configuring the Method of

Connecting to a Computer

About Application Library

Application Library is an application

that allows you to use useful functions

for routine jobs or other convenient

functions in a one-touch operation

without necessity of making functional

settings every time. You can access each

registered function by simply pressing

the appropriate button displayed in

the Home screen. For the respective

function, see the description displayed in

the Setup Guide.

• Configure the initial settings, according to the

screen.

2. Set the language and country/region.

3. Set the time zone and current date/time.

4. Configure the settings to prevent unauthorized

access.

• For the purpose of confirmation, enter the

same PIN twice.

5. Perform color correction.

Before starting the configuration

• The machine cannot be connected to

both wired and wireless LANs at the

same time.

• If the machine is connected to an

unsecured network, your personal

information might be leaked to a third

party. Please be aware and careful of this.

• The machine does not come with a

router. Please have one ready, if necessary.

• Even in an environment without wireless

LAN router, you can use Access Point

Mode to make a wireless connection to

the machine directly from your mobile

device (Direct Connection).

User's Guide

Specifying the connection method

• To connect via wireless LAN : <Yes>

• To connect via wired LAN or USB : <No>

To connect via wireless LAN

1. Make sure that the computer is connected to a

router properly.

Configuring the Machine

Configuring the Initial Settings of

the Machine

Configure the settings in the following order.

Quick Setup

2. Check the network settings on the computer.

3. Take note of the SSID and network key.

• Check the label on the router. User's Guide

• The setting operation is easier if the router is

provided with a WPS mark. User's Guide

4. Set the access point and network key

according to the screen below.

1. Press <OK>.

2. Press <SSID Settings>.

3. Press <Select Access Point>.

4. Select the access point (SSID), and press

<Next>.

5. Enter a WEP key (network key), and press

<Apply>.

6. Press <Yes>.

• The IP address will be automatically

configured in a few minutes.

• "Connected." is displayed.

5. Install the driver and software.

"Installing the software" on P.10

Now you are finished with the

configuration of the initial settings.

Proceed to configuring the fax

settings. P.11

To connect via wired LAN

The machine does not come with a LAN cable.

Please have one ready, if necessary.

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

3. Connect the LAN cable.

• After connecting the cable, wait a few minutes

(until the IP address is set automatically).

• If a static IP address has been set on the

computer, set the machine's IP address

manually.

4. Install the driver and software.

"Installing the software" on P.10

Now you are finished with the

configuration of the initial settings.

Proceed to configuring the fax

settings. P.11

For details

"Setting Up Using the Setup Guide" in the User's Guide

Quick Setup

To connect via USB

Do not connect the USB cable before installing

the driver. If you did, disconnect the USB cable

from the computer, close the dialog box, and then

perform the following procedure from step 1.

1. Install the driver and software.

"Installing the software" on P.10

• When the screen to connect the USB cable to

the machine is displayed, remove the cap that

covers the USB port.

Now you are finished with the

configuration of the initial settings.

Proceed to configuring the fax

settings. P.11

Installing the software

• The procedure described here is only applicable

when your computer runs on the Windows OS.

For more details on the software installation

procedure, see the driver's manual.

• For the installation when your computer runs on

the Mac OS, see the driver's manual.

• Your machine may not come with the driver for

the Mac OS, depending on the time of purchase.

New drivers are uploaded to the Canon website,

and you can download and use the latest one.

If the screen is not displayed properly, re-insert

the DVD-ROM or search for "D:\MInst.exe"

on the Windows platform (This description

assumes that "D:" is the DVD-ROM drive

name).

Using the scanner conveniently

Configuring the network settings with "Send

Function Setting Tool" allows you to directly

send scanned originals with e-mail or I-Fax

or store them in a shared folder or on the FTP

server.

In the screen displayed in step 2, select [Start

Software Programs] [Send Function Setting

Tool] to start the Send Function Setting Tool.

Configuring the Machine

Quick Setup
