BT DIVERSE 1010 User manual

Diverse handset

for use with

Diverse 1010 /1015

base units

featuring DECT

Digital Enhanced Cordless

Telecommunications

User guide

Carrying clip

Speed dial

Enables quick

dialling of numbers stored

in the memory.

Intercom

Enables internal

communication and call

transfer between handsets.

Power

Lets you switch the

handset on/off and select

the operating mode.

Display

Displays the

status of your

handset.

Phone

Used to make and

answer calls.

Keypad

123

456

789

✱

ABC DEF

GHI JKL MNO

PQRS TUV WXYZ

STO MEM LNR

RCL INT PWR

Store

Lets you store numbers

in the memory and access

other phone functions.

Last number redial

Can redial the last three

numbers you called and

lets you access other

phone functions.

Recall

For use with

switchboards and

BT Select Services.

At a glance

In this guide

At a glance 1

Introducing the

Diverse handset 4

Setting up 6

Registering a new Diverse

handset with the base unit 12

Using the

Diverse handset 15

Using the Diverse

handset with a PBX 26

Operating with

additional base units 30

Maintenance 36

Help 38

Technical information 42

Index 45

Hints and tips boxes

In this user guide, we've included helpful tips

and useful notes. They are shown in a grey box.

Introducing the

Diverse handset

Your Diverse handset is designed

for ease of use and made to the

high standards set by BT

We thank you for making the right choice

and expect that your Diverse handset will

give you many years of quality service.

Please read the instructions carefully

before use and keep this user guide for

future reference. The guide covers the

basic features of the Diverse handset.

For comprehensive instructions, see your

main Diverse 1010 or 1015 user guide.

DECT

By purchasing your Diverse handset, you

now own a product which combines the

advantages of cordless operation with the

performance of a high quality telephone.

It complies with the Digital Enhanced

Cordless Telecommunications (DECT)

standard and offers unparalleled quality

and features.

Setting up Follow these

steps to get your Diverse handset

ready for use

Warning

1Use only approved nickel-cadmium (NiCad)

rechargeable batteries. Never use other

batteries or conventional alkaline batteries.

Using such batteries could lead to a short

circuit or destroy the battery casing.

Recommended batteries should have a power

rating of 600m Ah 1.2V. Batteries available

from the Diverse helpline 0345 908070.

2Do not try to use any power supply except

the one provided, otherwise you may

permanently damage your Diverse. It will also

result in non-compliance with EN41003:1993,

and will invalidate the approval given to this

apparatus.

3There is a slight chance that your phone

could be damaged by an electrical storm.

We recommend that you unplug your Diverse

from the mains power and telephone line

socket during storms.

4If you wear a hearing aid, please note that

the Diverse works by sending radio signals

between the base unit and handset. These

signals can interfere with hearing aids,

causing a humming noise.

5Diverse handset can interfere with other

electrical equipment e.g. answering machines,

TV and radio sets, clock radio/alarms and

computers if placed too close. It is

recommended to place your Diverse handset

at least one metre away from such appliances

to avoid any risk of interference.

6It is possible that the Diverse handset may

be affected by being near bodies of water

(e.g. ponds, lakes, the sea).

3 Charging the handset batteries

for at least 16 hours

Before you use the handset, place it on

the base unit or charging unit (available

separately). The handset can be charged

face up or down. Make sure that the

contacts on the bottom end of the handset

are touching both charging contacts.

When the handset batteries are charging,

the green CHARGING light comes on.

Normal battery charging time.

After charging your Diverse for the first

time, normal charging time for the handset

batteries is about 4-5 hours. Batteries warm

up when being charged; this is normal and

not dangerous.

Under ideal conditions, the handset batteries

should give about 6.5 hours talktime or

60 hours standby on a single charge. However,

new NiCad batteries do not reach their full

capacity until they have been in normal use

for several days.

Battery low warning

flashes and handset beeps to warn

you that the batteries are within 5-10 minutes

of being completely flat.

Setting the TONE or PULSE

mode

Your Diverse handset is preset to TONE

dialling – where you hear a tone beep each

time you dial a number. Tone dialling is

suitable for all modern digital exchanges. If

you cannot make a call with TONE dialling,

you may need to switch to PULSE dialling.

To set PULSE dialling

•Press the STO button then the #button.

•Press the 1button.

•Enter the current system code.

(Factory setting 0000.)

•Press the LNR button.

•Press the buttons 0, 3, 3.

•Press the STO button to set pulse

dialling.

To re-set to TONE dialling

•Press the STO button then the #button.

•Press the 1button.

•Enter the current system code.

(Factory setting 0000.)

•Press the LNR button.

•Press the buttons 0, 3, 7.

•Press the STO button to set tone dialling.

STO

LNR

STO

Registering a

new Diverse

handset with the

base unit

Up to six handsets can be registered

and operated from the Diverse handset

base unit. The system allows you to

make internal intercom calls between

two handsets while a third is making an

external call.

Each additional handset you purchase

must be registered at the base unit.

To register a handset

The handset must be switched OFF.

At the base unit:

•Press and hold down the green paging

button until you hear the tone (after

about 10 seconds).

You now have up to 1 minute to register the

handset, during which the beeps will continue.

To remove a handset registered at the

base unit

•Press the STO button.

•Press the #button.

•Press the 7then 2.

•Enter the system code.

(Factory setting 0000.)

•Display shows all handsets registered

at the base.

•Enter the number of the handset to be

removed. It disappears from the display.

If you enter the wrong number, press it

again to reinstate it.

•Press the STO button to confirm.

PQRS

ABC

STO

If you are experiencing problems, please call

the Diverse Helpline on 0345 908070.

PROTECTED

This setting stops you accidentally

operating the handset’s keypad when

carrying it around. You can still receive

incoming calls but you cannot make

outgoing calls.

•To switch to PROTECTED when the

handset is ON, press and release the

PWR button quickly.

If the handset is beyond radio distance of the

base unit, the symbol flashes. You cannot

make or receive calls until the handset is

brought back within range. The symbol

also flashes for a while after power up until

the handset automatically registers to the base.
