Brother M-PRINT MW-120 Quick start guide

Before using this printer, be sure to read this User's Guide.

We suggest that you keep this manual in a handy place for future

reference.

Software Guide

Guía del software MW-120

Mobile Printer

Impresora móvil

Antes de usar esta impresora, asegúrese de leer esta “Guía del usuario”.

Aconsejamos mantener este manual a mano para futuras consultas.

{

Microsoft

, Windows

, Windows NT

and Windows Mobile™

are either registered trademarks or trademarks of Microsoft

Corporation in the United States and other countries.

{

Adobe

, Acrobat

, Reader

are either registered trademarks

or trademarks of Adobe Systems Incorporated in the United

States and/or other countries.

{Portion of graphics filter software are based in part on the

work of Group 42,Inc.

{Portion of graphics filter software are based in part on the

work of the Independent JPEG group.

{

All other software and product names mentioned are trade-

marks or registered trademarks of their respective companies.

CONTENTS

1 Operating Environment .................................. 2

2 Printing Data From a Computer Running

Windows .......................................................... 4

Installing the software ............................................... 4

Printing .................................................................... 10

Printing from other applications .............................. 11

Uninstalling the software ......................................... 12

3 Printing Data From a Pocket PC .................. 14

Installing the software ............................................. 15

Printing .................................................................... 18

Printing procedures ................................................. 19

Uninstalling the software ......................................... 35

CONTENTS

This mobile printer can print data from a computer running

Windows®or a PDA running Pocket PC.

Computer running Windows®

In order to use this printer, make sure that your system con-

figuration meets the following requirements.

PC operating environment

*1 Connecting with the PC running Microsoft®Windows®

OS, USB and Serial interfaces are available.

*2 Connecting by Serial interface, optional serial cable is

necessary.

*3 For use with Microsoft®Windows NT®4.0 SP6, Check

our web site and download the driver.

1 Operating Environment

Processor Pentium 266 MHz or higher recom-

mended

Operating

system*1

Serial interface (RS-232C)*2

Microsoft®Windows®98SE, Me,

NT4.0*3, 2000 Professional or XP

Compliant with USB Ver.1.1

Microsoft®Windows®98SE, Me,

2000 Professional or XP

Available Memory 64 MB or larger recommended

Hard disk free

space Minimum 20 MB

To print data from a computer running Windows

→

Refer to page 4.

Operating Environment

Pocket PC (PDA running Pocket PC)

In order to use this printer, make sure that your Pocket PC

meets the following requirements.

Pocket PC operating environment

•When installing the software, a computer running Win-

dows®that can connect to the Pocket PC will be

needed.

*1 “Microsoft®Pocket PC 2003” is “Windows Mobile™”

Software 2003 for Pocket PC.

Processor ARM or MIPS

(Not compatible with SH)

Operating system

Microsoft®Pocket PC

Microsoft®

Pocket PC 2002

Microsoft®

Pocket PC 2003*1

Interface Infrared port compliant with IrDA 1.2

•For information on Pocket PCs whose opera-

tion has already been verified, check our Web

site at http://www.brother.com.

To print data from a Pocket PC →Refer to page 14.

In order to use this printer to print data from a computer run-

ning Windows®, the software must be installed on the com-

puter.

Installing the software

Insert the enclosed CD-ROM into the CD-ROM

drive of the computer running Windows®.

→The installer automatically starts up and the Brother

Mobile Printing Software dialog box appears.

→If the installer does not automatically start up, dou-

ble-click “My Computer”, and then choose the “CD

drive” and double-click the “setup.exe” file.

Select the lan-

guage, and then

click the OK button.

→The Brother Mobile

Software screen

appears.

2 Printing Data From a Computer

Running Windows

yDo not connect this printer to the computer

until you are instructed to do so.

Printing Data From a Computer Running Windows

Click the top button

(Windows).

→A dialog box

appears, allowing

you to select what

to install.

Click the button for

the software that you

wish to install.

Here, click the button for

the Spotsnap software.

→The Driver Setup

dialog box appears.

Software packages that are installed

Software Description

Spotsnap

Software

Spotsnap

Operator Software for editing imported data

Snapper

Software for grabbing images, text or

copied data from the PC screen into

Spotsnap Operator

Templates Samples of pre-formatted layouts

Help On-screen operating guide

Printer

Driver

MPrint

MW-120 Software for printing with this printer

Windows button

Spotsnap software

Follow the instruc-

tions that appear to

finish the installa-

tion.

Next, the printer

driver is installed.

Select USB Cable,

and then click the

OK button.

The installation proce-

dure for the printer

driver differs depending

on the operating sys-

tem being used.

For Windows

98SE,

2000 or Me with USB

→Continue with the procedure on

the next page.

For Windows

XP with USB

→

Go directly to the procedure on page 8.

Printing Data From a Computer Running Windows

For Windows

98 SE, 2000 Professional, or Me

(USB connection)

When the message

“Connect Brother

MW-120, and then

turn it on.” appears,

use the enclosed

USB cable to con-

nect this printer to

the computer run-

ning Windows®, and

then turn on the

printer.

→The printer driver is installed.

Enclosed USB cable

→ Continue with “Printing” on page 10.

For Windows®XP (USB connection)

When the message

“Connect Brother

MW-120, and then

turn it on.” appears,

use the enclosed

USB cable to con-

nect this printer to

the computer run-

ning Windows, and then turn on the printer.

→The Found New Hardware Wizard dialog box

appears.

•If a dialog box allowing you to select a model

appears, make sure that MW-120 is selected,

and then click the Next button.

Enclosed USB cable
