Black Box RF200A User manual

1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: [email protected]

CUSTOMER

SUPPORT

INFORMATION

JANUARY 2000

RF200A RF208 RF305

RF201 RF209 RF307

RF202 RF210 RF308

RF203 RF300A RF309

RF204 RF301 RF310

RF205 RF302 RF199A-RKMT

RF207 RF304 RF299A-RKMT

Elite SC and Accessories

ELITE SC AND ACCESSORIES

TRADEMARKS USED IN THIS MANUAL

Plexiglas is a registered trademark of Rohm & Haas Company.

Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

ELITE SC AND ACCESSORIES

Contents

Chapter Page

1. Elite SC ....................................................................................................................................................................3

2. Elite SC with Installed Dual 19" EIA Mounting Kit, 39U......................................................................................7

3. 19" EIA Rackmounting Kit, 5U ............................................................................................................................11

4. Shelves ....................................................................................................................................................................12

5. Sliding Keyboard Trays..........................................................................................................................................14

6. Horizontal Cable Management with Four Cable Rings......................................................................................16

7. Vertical Cable Management with Six Cable Rings ..............................................................................................17

8. Casters and Fan Assemblies ..................................................................................................................................19

ELITE SC AND ACCESSORIES

1. Elite SC

Available Models

The Elite SC is available in two colors: black (RF200A) and beige (RF300A).

Description

The Elite SC is a double-wide cabinet that’s big enough to house your LAN equipment and act as a standalone

data center. The cabinet is constructed with a rugged 14-gauge folded-steel frame, and it holds 700 pounds

(317.5 kg) of equipment. It’s preassembled, so it’s easy to set up and use. Cabinet components include: fully

louvered rear door, one pair of solid lift-off side panels, one 16-position power strip with circuit breaker and

12-ft. (3.7-m) cord, a Plexiglas®front door, two stationary shelves (300-pound capacity each), rubber feet, and

leveling glides. Cabinet dimensions are 72"H x 48"W x 32"D (182.9 x 121.9 x 81.3 cm).

Additional features:

• Top panel has cable-management punch-outs, plus vented slots for extra cooling.

• Extra wide (48") and extra deep (32") for accommodating servers and other large equipment.

• Plexiglas front doors and vented rear doors have three-point latch and lock.

See pages 4 through 6 for diagrams.

ELITE SC AND ACCESSORIES

Figure 1-1. The Elite SC, front view.

ELITE SC AND ACCESSORIES

Figure 1-2. Front view of the Elite SC with the front door removed.

43.750"

OPENING

44.124"

CENTERS

48.000"

66.250"

OPENING

ELITE SC AND ACCESSORIES

Figure 1-3. Right-side view of the Elite SC with the side panel removed.

32.000"

72.000"

27.750"

OPENING

45.875"

TAPPED 10-32 (8)

SIDE PANEL MTG.

ø0.219" (4)

67.000"

OPENING

ELITE SC AND ACCESSORIES

2. Elite SC with Installed Dual 19"

EIA Mounting Kit, 39U

Available Models

The Elite SC with Installed Dual 19" EIA Mounting Kit is available in two colors: black (RF199A-RKMT)

and beige (RF299A-RKMT).

Description

If you haven’t done so already, read Chapter 1 for more information about the Elite SC. This version of the

cabinet also includes 19" EIA mounting rails that fit side by side in the cabinet. Eight mounting rails are

provided, and the rails are adjustable in one-inch horizontal increments. Use the rails for two- or four-point

equipment mounting. The mounting kit also increases the weight capacity of the cabinet from 700 pounds

to 1000 pounds (454 kg). Best of all, when your order the RF199A-RKMT or RF299A-RKMT, we’ll install the

Rackmount Kit in your Elite SC!

NOTE

Please note that the Elite SC with the Dual Mounting Kit does NOT include the two

stationary shelves.

See pages 8 through 10 for diagrams.
