BIXOLON SLP-DV22 User manual
Setting up the Bixolon Printer
1
Remove Bixolon Printer from Shipping Box.
2
Connect Bixolon Printer to the Power Outlet
3
Bixolon Printer overview
PAUSE BUTTON
POWER SWITCH
FEED BUTTON
COVER LEVEL
4
Open the Paper Cover. Spread the Paper
Holder and insert Paper Roll. Labels should be
Facing Up.
Go to the next step
© 2021 PROCURO, INC.
PIMMTM
Need assistance? Please call (858) 457-8160 or email pimmy@procuro.com 1.
TM
PIMMTM Operations Tablet
PIMMTM
Bixolon SLP-DV220 Printer Setup
© 2021 PROCURO, INC.
PIMMTM
Need assistance? Please call (858) 457-8160 or email pimmy@procuro.com 2.
TM
PIMMTM Operations Tablet
PIMMTM
Bixolon SLP-DV220 Printer Setup
Button and LED Guide
PRINTER STATE BEFORE
OPERATION ACTION OPERATION PROCEDURE PRINTER OPERATION MODE
Power OFF
Apply Power while pressing the
button (Hold the button until the
printer starts self-test printing)
Self-test Printing Mode
PRESS
PRESS
Print Standby Press the button softly and release
immediately
Feed Mode
PRESS
Print Standby Press the button for two seconds and
continue to hold
Stand-alone
Configuration Mode
PRESS
During Printing Press the button for two seconds and
continue to hold
Print Cancel Mode
PRESS
During Printing Press the button softly and release it
immediately
Print Pause Mode
© 2021 PROCURO, INC.
PIMMTM
Need assistance? Please call (858) 457-8160 or email pimmy@procuro.com 3.
TM
PIMMTM Operations Tablet
PIMMTM
Bixolon SLP-DV220 Printer Setup
Button and LED Guide (cont.)
Print standby mode
Error mode.
Paper Jam (gap/black mark is
not recognized)
BLINK
Error mode.
Printer head overheating
BLINK
Error mode.
Paper cover open
BLINK
Error mode.
No paper
Error mode.
Media calibration
failure
Error mode.
Auto-Cutter error
Mode switching notification.
BLINK Wait for input.
Print is paused temporarily
Wait for button input
BLINK
Wait for input.
Cover close mode.
Wait for button input
BLINK
Wait for input.
Print cancel mode
Wait for button input
BLINK
BLINK
BLINK
1
Select icon on your iPad home screen
2
PRECAUTIONS:
1. To connect the printer with your iPad via Bluetooth, the iPad and printer must be within 100 meters (330
feet) of one another. The connection is broken if the distance between devices exceeds 100 meters (330
feet).
2. The maximum separating distance may be shortened if transmission obstacles, such as cement walls,
are present.
3. If a device (such as a microwave oven, wireless LAN, ets.) that uses the same frequency is present, trans-
mission may be interrupted. Separate the printer and iPad from such interrupting devices by a distance of
at least 5 meters (16 feet).
Select “Bluetooth”
© 2021 PROCURO, INC.
PIMMTM
Need assistance? Please call (858) 457-8160 or email pimmy@procuro.com 4.
TM
PIMMTM Operations Tablet
PIMMTM
Bixolon SLP-DV220 Printer Setup
Bluetooth Connection
3
Select SLP-DX220B Printer to connect
4
Enter PIN - 0000. Click “Pair”
5
Bluetooth communication is available!
0000
© 2021 PROCURO, INC.
PIMMTM
Need assistance? Please call (858) 457-8160 or email pimmy@procuro.com 5.
TM
PIMMTM Operations Tablet
PIMMTM
Bixolon SLP-DV220 Printer Setup
Bluetooth Connection (Cont.)
© 2021 PROCURO, INC.
PIMMTM
Need assistance? Please call (858) 457-8160 or email pimmy@procuro.com 6.
TM
PIMMTM Operations Tablet
PIMMTM
Bixolon SLP-DV220 Printer Setup
1
Select SMS App from your iPad home screen Login to your SMS Account:
SPID: wendys
2
3
Click OK to allow Bluetooth Select Food Prep Module
4
5
Click Allow to accept Notifications In the bottom left corner, click Label Printer
selection button
6
Enable BlueTooth Printer in SMS
9
Select LABELS to print. Click “Select All”
button, then “Print Selected”.
10
Review your labels in the Print Review and
click Print.
7
Select Bixolon Printer Your Bixolon Printer is ready!
8
© 2021 PROCURO, INC.
PIMMTM
Need assistance? Please call (858) 457-8160 or email pimmy@procuro.com 7.
TM
PIMMTM Operations Tablet
PIMMTM
Bixolon SLP-DV220 Printer Setup
Enable BlueTooth Printer in SMS (cont.)
BIXOLON SLPDX220 MAINTENANCE
Printing quality might be degraded by dust, foreign substance, adhesive substance, or other pollution materials
stuck in the printer head or inside the printer.
When dirty, clean the print head as follows:
CAUTION:
Make sure to turn the printer power off prior to cleaning.
As the print head gets very hot during printing, if intending to clean the print head, turn the printer
power off and wait approximately 2~3 minute before commencement.
When cleaning the print head, take care not to touch the heated portion of the print head.
Printer Head is susceptible to damage from static electricity, etc.
Take care not to allow the print head to become scratched and/or damaged in any way.
1
Open the Paper Cover and then use the
cleaning pen to clean the head in the direction
from the center of the head to the edges.
2
After cleaning the head, do not use the printer
until the alcohol used for cleaning
evaporates completely (1~2 min) and the
printer has completely dried.
Perform the cleaning process each time the paper roll is replaced to
prevent print quality deterioration.
© 2021 PROCURO, INC.
PIMMTM
Need assistance? Please call (858) 457-8160 or email pimmy@procuro.com 8.
TM
PIMMTM Operations Tablet
PIMMTM
Bixolon SLP-DV220 Printer Setup
