Biomorph Flexo Corner User manual
Flexo Level3 Desk
& Flexo Corner Assembly
Biomorph Inc., 1045 33rd Street South, St Cloud, MN 56301
Tel and Fax 888 302 3375 [email protected]
www.biomorph.com
SX2M-A-LL-S-DS
SX2M-A-LL-B-DS
2
Hardware
Tools
“Questions? Please call 917.328.8955 for support.
IMPORTANT: Any issues at site must be reported to Biomorph immediately at 917.328.8955, by text or phone and wait on site for response. Also, photos of
completed desk(s) must be sent to 917.328.8955 or [email protected] and wait ON SITE for approval. This will avoid potential revisits. Thank you.
Components
4mm Wrench Drill Extension #2 Phillips Bit Hex Bit
Leg
Qty 2
2 Port Control Box
Qty 1
Wire Clips
Qty 62
Cable Cab
Qty 2
45˚ Digital Readout
Switch and 45˚
Switch Bracket
Qty 1
aLH Top Plate
Qty 1
bRH Top Plate
Qty 1
c
Keyboard Mechanism
Qty 1
n
ijm
k
Foot
Qty 2
d
Table Top
Qty 1
or
hTable Top Corner
Qty 1
h1
Adjustable
Crossbar
Qty 1
g
LH Adjustable
Crossbar Section
Qty 1
eRH Adjustable
Crossbar Section
Qty 1
fRH Adjustable
Crossbar Section
for Corner
Qty 2
LH Adjustable
Crossbar Section
for Corner
Qty 2
Adjustable
Crossba
for Corner
Qty 2
g1
e1 f1
M6 Flange Head Nut
Qty. 4
16mm PH Wd Screw
Qty. 18
M6 x 12 Screw
Qty. 24
45mm PH Wd Screw
Qty. 2
D - Glider
Qty. 4
5 x 25mm Wd Screw
Qty. 62
3
Assembly OverviewAssembly Overview
IMPORTANT:
DO NOT BUILD THIS TABLE
UPSIDE DOWN. FRAME MUST BE BUILT RIGHT SIDE UP, IN PLACE, AND TOPS THEN ATTACHED. If this
procedure is not followed then tops will not line up with frame. DO NOT REMOVE PROTECTIVE MATERIAL FROM
TOPS UNTIL FINAL ASSEMBLY.
IMPORTANT:
When moving this desk, do not drag frame as it can cause leg actuators to bind and fail. Always lift o
floor using frame, not tops.
a
a
c
b
d
d
g
g1
e
e1
f
f1
e1 f1 g1 e f g
Replaces
for Corner application only
4
Leg Assembly (continued)
Glide
Qty. 4
M6 x 12 Screw
Qty. 8
a
a
d
d
Note: Longer end of
Foot must face toward
front (user) side.
2
Leg Assembly
M6 x 12 Screw
Qty. 4
1
b
c
a
a
bc
a
5
Leg Assembly (continued)
e
f
e1
f1
M6 x 12 Screw
Qty. 4
3
LH Side RH Side
e
Use these holes. Use these holes.
f
6
Crossbar Assembly (continued)
Use these holes. Use these holes.
e
72” LH Side
60” LH Side
M6 x 12 Screw
Qty. 4
M6 Flange
Head Nut
Qty. 4
4
g
Use these holes. Use these holes.
e
g
84” LH Side
72” RH Side
60” RH Side
84” RH Side
Use these holes. Use these holes.
e
g
g
g
g
f
f
f
g
f
e
7
Crossbar Assembly for Corner (continued)
Use these holes. Use these holes.
e1
Corner” LH Side
M6 x 12 Screw
Qty. 4
M6 Flange
Head Nut
Qty. 4
5
1g
Corner” RH Side
g1
f1
f1
e1
g1
8
Top Assembly
5 x 25mm
Wood Screw
Qty. 12
h
9
Top Assembly Corner
5 x 25mm
Wood Screw
Qty. 12
h1
10
Electrical Components
j
45˚ Digital Readout
Switch and 45˚
Switch Bracket
Qty 1
16mm PH
Wood Screw
Qty. 2
i
2 Port Control Box
Qty 1
45mm PH
Wood Screw
Qty. 2
j
