Belkin Surf F7D1102 User manual

User Manual

F7D1102 8820-00741 Rev. A00

WIRELESS USB ADAPTER

N150 Micro

TABLE OF CONTENTS

Introduction .............................................. 1

Benefits of a Home Network....................................1

Advantages of a Wireless Network ..............................2

Placement of your Wireless Networking Hardware for Optimal

Performance.................................................3

Overview................................................. 7

Product Features ............................................7

Applications and Advantages...................................8

Product Specifications ........................................9

System Requirements ........................................10

Package Contents ...........................................10

Installing and Setting up the Adapter....................... 11

A. Installation Process for Windows Vista and 7 ..................11

B. Installation Process for Windows XP .........................18

Connecting to a Secure Wi-Fi®Network.........................22

Troubleshooting ......................................... 23

Information.............................................. 30

Thank you for purchasing the Belkin N150 Micro Wireless USB Adapter. Now you can take advantage of this great new

technology and gain the freedom to network your home and office computers wirelessly. This Adapter allows you to connect

a notebook or desktop computer to your network. Please be sure to read through this User Manual completely, and pay

special attention to the section titled, “Placement of your Wireless Networking Hardware for Optimal Performance.”

Benefits of a Home Network

Your Belkin Home Network will allow you to:

 •Shareonehigh-speedInternetconnectionwithallthecomputersinyourhome

 •Shareresources,suchasfiles,andharddrivesamongalltheconnectedcomputersinyourhome

 •Shareasingleprinterwiththeentirefamily

 •Sharedocuments,music,video,anddigitalpictures

 •Store,retrieve,andcopyfilesfromonecomputertoanother

 •Simultaneouslyplaygamesonline,checkInternetemail,andchat

INTRODUCTION

Advantages of a Wireless Network

 •Mobility –you’ll no longer need a dedicated “computer room”—now you can work on a

networked laptop or desktop computer anywhere within your wireless range

 •Easy installation – Belkin Easy Installation Wizards make setup simple

 •Flexibility – set up and access printers, computers, and other networking devices from anywhere in your home

 •Easy expansion – the wide range of Belkin networking products let you expand your

network to include devices such as printers and gaming consoles

 •No cabling required – you can spare the expense and hassle of retrofitting Ethernet cabling throughout the home or office

 •Widespread industry acceptance – choose from a wide range of interoperable networking products

INTRODUCTION

Placement of your Wireless Networking Hardware for Optimal Performance

Your wireless connection will be stronger the closer your computer is to your wireless router (or access point). Typical indoor operating

range for your wireless devices is between 100 and 200 feet. In the same way, your wireless connection and performance will degrade

somewhat as the distance between your wireless router (or access point) and connected devices increases. This may or may not

be noticeable to you. As you move farther from your wireless router (or access point), connection speed may decrease. Factors that

can weaken signals simply by getting in the way of your network’s radio waves are metal appliances or obstructions, and walls.

If you have concerns about your network’s performance that might be related to range or obstruction factors, try

moving the computer to a position between five and 10 feet from the wireless router (or access point) in order to see if

distance is the problem. If difficulties persist even at close range, please contact Belkin Technical Support.

Note: While some of the items listed below can affect network performance, they will not prohibit your wireless network from

functioning; if you are concerned that your network is not operating at its maximum effectiveness, this checklist may help.

INTRODUCTION

1. Placement of your Wireless Router (or Access Point)

Place your wireless router (or access point), the central

connection point of your network, as close as possible

to the center of your wireless network devices.

To achieve the best wireless network coverage for your “wireless

clients,” (i.e., computers enabled by Belkin Adapters or Cards):

 •Ensurethatyourwirelessrouter’s(oraccesspoint’s)

antennas are parallel to each other, and are positioned

vertically (toward the ceiling). If your wireless router (or

access point) itself is positioned vertically, point the

antennas as much as possible in an upward direction.

 •Inmultistoryhomes,placethewirelessrouter(or

access point) on a floor that is as close to the center

of the home as possible. This may mean placing the

wireless router (or access point) on an upper floor.

 •Trynottoplacethewirelessrouter(oraccess

point) near a cordless 2.4GHz phone.

2. Avoid Obstacles and Interference

Avoid placing your wireless router (or access point) near devices

that may emit radio “noise”, such as microwave ovens. Other

objects that can inhibit wireless communication can include:

 •Refrigerators

 •Washersand/ordryers

 •Metalcabinets

 •Largeaquariums

 •Metallic-based,UV-tintedwindows

 •Microwaves

If your wireless signal seems weak in some spots, make sure

that objects such as these are not blocking the signal’s path

between your computers and wireless router (or access point).

INTRODUCTION

3. Cordless Phone Placement

If the performance of your wireless network is impaired after

attending to the above issues, and you have a cordless phone:

 •Trymovingcordlessphonesawayfromthewirelessrouter

(or access point) and your wireless-enabled computers.

 •Unplugandremovethebatteryfromanycordlessphonethat

operates on the 2.4GHz band (check manufacturer’s information).

If this fixes the problem, your phone may be interfering.

 •Ifyourphonesupportschannelselection,changethechannel

on the phone to the farthest channel from your wireless network

as possible. For example, change the phone to channel 1 and

move your wireless router (or access point) to channel 11.

(Your channel selection will vary depending on your region.)

See your phone’s user manual for detailed instructions.

 •Ifnecessary,considerswitchingtoa

900MHz or 5GHz cordless phone.

4. Choose the “Quietest” Channel for your Wireless Network

In locations where homes or offices are close together, such

as apartment buildings or office complexes, there may be

wireless networks nearby that can conflict with yours. Use the

Site Survey capabilities of your Belkin Wireless Networking

Utility to locate any other wireless networks, and move

your wireless router (or access point) and computers to a

channel as far away from other networks as possible.

Experiment with more than one of the available channels in

order to find the clearest connection and avoid interference

from neighboring cordless phones or other wireless devices.

For more Belkin wireless networking products,

use the detailed Site Survey and wireless channel

information included in your User Manual.

INTRODUCTION

5. Secure Connections, VPNs, and AOL

Secure connections typically require a user name and password, and

are used where security is important. Secure connections include:

 •VirtualPrivateNetwork(VPN)connections,often

used to connect remotely to an office network

 •The“BringYourOwnAccess”programfromAmerica

Online(AOL),whichletsyouuseAOLthroughbroadband

providedbyanothercableorDSLservice

 •Mostonlinebankingwebsites

 •Manycommercialwebsitesthatrequireauser

name and password to access your account

Secure connections can be interrupted by a computer’s power

management setting, which causes it to “go to sleep.” The simplest

solution to avoid this is to simply reconnect by re-running the

VPNorAOLsoftware,orbyre-loggingintothesecurewebsite.

A second alternative is to change your computer’s power

management settings so it does not go to sleep; however,

this may not be appropriate for portable computers. To

change your power management setting in Windows,

see the “Power Options” item in the Control Panel.

If you continue to have difficulty with Secure Connections,

VPNs,andAOL,pleasereviewsteps1–4intheprevious

pages to be sure you have addressed these issues.

These guidelines should allow you to cover the maximum possible

area with your wireless router. Should you need to cover an even wider

area,wesuggesttheBelkinWirelessRangeExtender/AccessPoint.

For more information regarding our networking products,

visitourwebsiteatwww.belkin.com/networking

or call Belkin Technical Support.

Product Features

The Adapter complies with the IEEE 802.11g specification

to communicate with other 802.11g-compliant wireless

devices at up to 54Mbps*. The Adapter is also compatible

with 802.11n devices at 150Mbps as well as 802.11b

products at 11Mbps. The Adapter operates on the same

2.4GHzfrequencybandas802.11b/gWi-Fi®products.

 •2.4GHzISM(Industrial,Science,andMedical)bandoperation

 •USB2.0interface,foroperationinvirtuallyany

computer with a USB 2.0 bus-power port

 •WPA,WPA2,64-bitWEP(WiredEquivalent

Privacy), or 128-bit encryption

 •Wirelessaccesstonetworkedresources

 •Datarateofupto150Mbps*(802.11n),54Mbps

(802.11g), or 11Mbps (802.11b)

 •Easyinstallationanduse

 •LEDpowerandnetworklink/activityindicator

OVERVIEW

Applications and Advantages

 •Wirelessroamingwithalaptoparoundthehomeoroffice

Offers the freedom of networking without cables

 •Connectionratesofupto150Mbps*

Provides immediate high-speed wireless connectivity

at home, work, and hotspot locations without

compromisingtheuseofexisting802.11b/gproducts

 •Compatibilitywith802.11b/gproducts

The Adapter is backward-compatible with

existingWi-Fi(IEEE802.11b/g)products

 •Difficult-to-wireenvironments

Enables networking in buildings with solid or finished

walls, or open areas where wiring is difficult to install

 •Frequentlychangingenvironments

Adapts easily in offices or environments that

frequently rearrange or change locations

 •SOHO(SmallOffice/HomeOffice)networkingneeds

Provides the easy and quick, small network

installation SOHO users need

 •MicroEnclosure

The Adapter has been designed to fit neatly into

your computer’s USB port and sit nicely on the side

of the port without blocking any other ports.
