Beko DTGC8000W User manual

DTGC8000W

DTGC8011W

DTGC8001W

DTGC8000B

DTGC8011B

Dryer

User Manual

2960311520_EN/210717.1555

TABLE OF CONTENTS

4 Preparation 15

4.1 Laundry suitable for drying in the dryer15

4.2 Laundry not suitable for drying in the

dryer..........................................................................15

4.3 Preparing laundry for drying...................15

4.4 Things to be done for energy saving ..15

4.5 Correct load capacity..................................15

5 Operating the product 17

5.1 Control Panel..................................................17

5.2 Symbols............................................................17

5.3 Preparation of drying machine...............17

5.4 Programme selection and consumption

tablee ...................................................................... 18

5.5 Auxiliary functions..................................... 19

5.6 Warning indicators.....................................20

5.7 Starting the program.................................20

5.8 Child Lock .......................................................20

5.9 Changing the program after it is

started .....................................................................21

5.10 Cancelling the program...........................21

5.11 End of program ...........................................21

6 Maintenance and cleaning 22

6.1 Lint Filter / Loading Door Inner Surface22

6.2 Cleaning the sensors ................................ 23

6.3 Draining the water tank........................... 23

6.4 For the condenser;..................................... 23

15 / EN

Dryer / User Manual

4Preparaton

4.1 Laundry suitable for drying

in the dryer

Always obey the instructions given on the

garment tags. Dry only the laundry having a

label stating that they are suitable for drying

in a dryer and make sure that you select the

appropriate programme.

Do not dry with

dryer

At high

temperature

At medium

temperature

At low

temperature

4.2 Laundry not suitable for

drying in the dryer

CDelicate embroidered fabrics,

woollen, silk garments, delicate

and valuable fabrics, airtight

items and tulle curtains are not

suitable for machine drying.

4.3 Preparing laundry for

drying

• Laundry may be tangled with each other

after washing. Separate the laundry

items before placing them into the dryer.

• Dry garments having metal accessories

such as zippers, inside out.

• Fasten the zippers, hooks and buckles

and button sheets.

4.4 Things to be done for

energy saving

• Spin your laundry at the highest speed

possible when washing them. Thus, the

drying time is shortened and energy

consumption is reduced.

• Sort out the laundry depending on their

type and thickness. Dry the same type

of laundry together. For example thin

kitchen towels and tableclothes dries

earlier than thick bathroom towels.

• Follow the instructions in the user

manual for programme selection.

• Do not open the loading door of the

machine during drying unless necessary.

If you must open the loading door, do not

keep it open for a long time.

• Do not add wet laundry while the dryer is

in operation

• For models with a condenser unit: clean

the condenser once in a month or after

every 30 operations regularly. .

• For models with heat pump unit: clean

the filter drawer periodically when there

is a visible accumulation of fluff or when

the filter drawer cleaning indicator «

» lights up.

• For models with flue unit: comply with

the flue connection instructions and

clean the flue.

• During the drying process, air the

room well where your tumble dryer is

operating.

4.5 Correct load capacity

Follow the instructions in the “Programme

selection and consumption table”. Do not

load more than the capacity values stated in

the table.

16 / EN Dryer / User Manual

Preparation

Following weights are given as examples.

Laundry Approximate

weights (g)*

Cotton quilt covers

(double) 1500

Cotton quilt covers

(single) 1000

Bed sheets (double) 500

Bed sheets (single) 350

Large tablecloths 700

Small tablecloths 250

Tea napkins 100

Bath towels 700

Hand towels 350

Blouses 150

Cotton shirts 300

Shirts 250

Cotton dresses 500

Dresses 350

Jeans 700

Handkerchiefs (10

pieces) 100

T-Shirts 125

*Dry laundry weight before washing.

17 / EN

Dryer / User Manual

5 Operatng the product

5.1 Control Panel

1. On/Off/Program selection button

2. Start/Pause button

3. End Time button

4. Audio warning level button

5.2 Symbols

Volume up

Filter

cleaning

Tank

full

Child-proof

lock

Mute

Condenser

cleaning

warning symbol

End/anti-

creasing

On/O Timer

Delay

Dryness

Level

Cupboard

Dry

Iron Dry

5.3 Preparation of drying

machine

• Plug the drying machine.

• Open the loading door.

• Place the laundry to the drying machine

without jamming them.

• Push and close the loading door.

AEnsure that no laundry is jammed

to the loading door.

Select the desired program using the On/

Off/Program selection knob, the machine will

turn on.

CSelecting a program using the

On/Off/Program selection

button does not mean that the

program started. Press the Start

/ Stand-by button to start the

program.

18 / EN Dryer / User Manual

Operating the product

Programmes Programme Description

Capacity (kg)

Spin speed

in washing

machine (rpm)

Drying Time

(minutes)

Cotton Iron Dry

You may dry your cotton laundry to be ironed in

this programme to have them slightly damp for

ease ofironing. (Shirt, T-shirt, tablecloth, etc.)

8 1000 107

Cotton Cupboard Dry

You may dry all your cotton laundry in this

programme.(T-shirt, pants, pyjamas, baby

clothes, underwear,linen, etc.) You can put your

laundry in the wardrobe without ironing.

8 /4 1000 142/80

Cotton Cupboard Dry

Plus

You may use this programme for extra dryness

in thick laundry such as pants, tracksuit.

You can put your laundry in the wardrobe

without ironing.

8 1000 145

Cotton Extra Dry

You may dry your thick cotton laundry in this

programme such as towels, bathrobe, etc. You

can put your laundry in the wardrobe without

ironing.

8 1000 150

Synthetic Iron Dry

You may dry your synthetic laundry to be ironed

in this programme to have them slightly damp

for ease of ironing. (Shirt, T-shirt, tablecloth,

etc.)

4 800 40

Synthetic Cupboard

Dry

You may dry all your synthetic laundry in

this programme (Shirt, T-shirt, underwear,

tablecloth, etc.) You can put your laundry in the

wardrobe without ironing.

4 800 53

Sport

You may dry your sports clothes that

are appropriate for tumble drying in this

programme.

4 1000 92

Freshen up

It just provides airing for 10 minutes without any

hot air. You can air the cotton and linen laundry

that have been stored for a long time , and

eliminate the odour in them.

- - 10

Time Proggammes

You may select from time programmes between

10 and 30 and 60 minutes to achieve the

desired drying level at low temperature. In this

programme,tumble drier’s operation lasts for

the set time independently from the dryness of

laundry.

- - -

Babyprotect Program used for baby clothing with can be

dried approval on the label. 3 1000 70

Jeans You may dry denim pants, skirts, shirts or jackets

in this programme. 4 1200 80

5.4 Programme selection and consumption tablee

19 / EN

Dryer / User Manual

Operating the product

Gentle Care / Shirts

You may dry your delicate laundry or laundry

with hand wash symbol (silk blouses, thin

underwear, etc.) at low temperature in this

program.

2 600 40

Express Super Short Dries shirts more delicately and thus causes less

wrinkles for easy ironing. 0,5 1200 14

Energy consumption values

Programs Capacity (kg)

Spin speed

in washing

machine

(rpm)

Approximate

amount of

remaining

humidity

Energy

consumption

value kWh

Cotton cupboard dry* 8 /4 1000 60% 4,75 / 2,53

Cotton Iron dry 8 1000 60% 3.8

Synthetic cupboard

dry 4 800 40% 1.8

Power consumption of the off-mode for the standart cotton programme at full load, PO (W) 0,5

Power consumption of the left-on mode for the standart cotton programme at full load, PL (W) 1,0

“Cotton cupboard dry programme” used at full and partial load is the standard drying

programme to which the information in the label and the fiche relates, that this programme

is suitable for drying normal wet cotton laundry and that it is the most efficient programme in

terms of energy consumption for cotton.

* : Energy Label standard program (EN 61121:2012)

All the values on the chart are identified according to EN 61121:2012 standard. Consumption

values may vary from the values in the chart depending on laundry type, wringing speed,

ambient conditions and voltage levels.

5.5 Auxiliary functions

Audible warning

Drying machine makes an audible warning

when the program is completed. If you don’t

want it to make an audible warning, press the

“Buzzer” button. When you press the Buzzer

button, a light will illuminate and no audible

warning will be made when the program

ends.

CYou can select this function

before or after the program

starts.

End time

If you prefer to dry your laundry at a later

time, you can delay start time of the program

up to 3 hours, 6 hours or 9 hours using the

Delay function.

Open the loading door and place the laundry.

Select the drying program.

Press the End Time selection button and

set the delay time you wish. When the End

Time button is pressed once, 3 hours delay is

selected and the delay indicator will light up.

If you press the same button again, 6 hours

delay will be selected and when you press for

the third time, 9 hours delay will be selected.

If you press the End Time button once again,

the delay will be cancelled.

After the End Time selection is made, start

delayed running for the program selected

pressing the “Start/Stand-by” button.

20 / EN Dryer / User Manual

Operating the product

CYou can add or remove laundry

within end time. At the end of

the Time Delay countdown, the

Time Delay warning indicator

turns off and drying begins

Changing the end time

If you want to change the duration during

the countdown:

Cancel the program by turning the On/Off/

Program selection knob. Select the program

you want and repeat the End Time selection

process.

Cancelling the end time function

If you want to cancel the end time

countdown and start the program

immediately:

Cancel the program by turning the On/Off/

Program selection knob. Select the program

you want and press the Start/Stand-by

button.

5.6 Warning indicators

CWarning indicators may vary

depending on the model of your

dryer.

Filter cleaning

When the program is completed, the warning

indicator for filter cleaning turns on.

Water tank

When the program is completed, the warning

indicator to empty the water tank turns on.

If the water tank fills up while the program

continues, the warning indicator starts

flashing and the machine goes into stand-by.

In this case, empty the water tank and start

the program by pressing the Start / Stand-

by button. Warning indicator turns off and

program resumes.

Condenser

Clean the condenser periodically when there

is a visible accumulation of fluff or when the

condenser cleaning indicator « » lights

up, if any.

5.7 Starting the program

Press the Start/Stand-by button to start the

program.

Drying indicator will light up, indicating that

the program has started.

5.8 Child Lock

The drying machine has a child lock which

prevents the program flow from being

interrupted when the buttons are pressed

during a program. When the child lock is

activated, all buttons on the panel except

the On/Off/Program selection knob are

deactivated.

Press the End Time and Buzzer buttons

simultaneously for 3 buttons to activate the

child lock.

The child lock has to be deactivated to be

able to start a new program after the current

program is finished or to be able to interfere

with the program. To deactivate the child

lock, keep the same buttons pressed for 3

seconds.

CWhen the child lock is activated,

the child lock warning indicator

on the screen turns on.

CChild lock deactivates when the

drying machine is turned off and

on by the On/Off/Cancel knob.

When the child lock is active:

When the drying machine runs, or in stand-

by state, the indicator symbols won’t change

upon changing the position of the program

selection knob.

CWhen the drying machine runs

and the child lock is active, it

beeps twice when the program

selection knob is turned. If the

child lock is deactivated without

returning the program selection

knob to its previous position,

program will terminate due

to the change in the program

selection knob position.

21 / EN

Dryer / User Manual

Operating the product

Do not touch the inner surface

of the drum while adding or

removing clothes during a

continuing program. The drum

surface is hot.

5.10 Cancelling the program

If you want to cancel the program and

terminate the drying operation for any

reason after the drying machine starts

running, turn the On/Off/Cancel knob, the

program will be cancelled.

AThe inside of the drying machine

shall be extremely hot when

you cancel the program during

machine operation, so run the

refresh program to allow it to

cool down.

5.11 End of program

When the program ends, the Fibre Filter

Cleaning and Water Tank warning symbols on

the program observation indicator turn on.

Loading door may be opened and the dryer

machine becomes ready for another run.

Bring the On/Off/Program selection knob to

On/Off position to turn the drying machine

off.

CIf the laundry is not removed

after the program is completed,

the wrinkle prevention function

activates for 2 hours to prevent

the laundry inside the machine

to get wrinkled. The program

tumbles the laundry with

10-minute intervals to prevent

them from wrinkling.

5.9 Changing the program

after it is started

You can change the program you selected

to dry your laundry with a different program

after the drying machine starts running

• For instance, select Extra Dry program

by turning the On/Off/Program selection

knob to select Extra Dry instead of Iron

Dry.

• Press the Start/Stand-by button to start

the program.

Adding and removing clothes during

stand-by

If you want to add or remove clothes to/from

the drying machine after the drying program

starts:

• Press the Start/Stand-by button to put

the drying machine in Stand-by state.

The drying operation stops.

• Open the loading door while in Stand-

by state, and close the door after you

remove or add laundry.

• Press the Start/Stand-by button to start

the program.

CAdding laundry after the drying

operation starts may cause the

dried laundry inside the machine

to mix with wet laundry and

leave the laundry damp at the

end of operation.

CAdding or removing laundry

during drying may be

repeated as many times as

you wish. But this operation

continuously interrupts the

drying operation, and thus

increases program duration and

energy consumption. So, it is

recommended to add laundry

before the program starts.

CIf a new program is selected by

turning the program selection

knob while the drying machine is

in stand-by, the running program

terminates.

22 / EN Dryer / User Manual

6Mantenance and cleanng

Service life of the product extends and

frequently faced problems decrease if

cleaned at regular intervals.

BUnplug the product from the

mains during any maintenance

and cleaning works (control

panel, body, etc.).

6.1 Lint Filter / Loading Door

Inner Surface

Lint and fiber released from the laundry to

the air during the drying cycle are collected in

the Lint Filter.

CSuch fiber and lint are generally

formed during wearing and

washing.

AAlways clean the lint filter and

the inner surfaces of the loading

door after each drying process.

CYou can clean the lint filter

housing with a vacuum cleaner.

To clean the lint filter:

1. Open the loading door.

2. Remove the lint filter by pulling it up and

open the lint filter.

3. Clean lint, fiber, and cotton raveling by

hand or with a soft piece of cloth.

4. Close the lint filter and place it back into

its housing.

CA layer can build up on the filter

pores that can cause clogging of

the filter after using the machine

for a while. Wash the lint filter

with warm water to remove the

layer that builds up on the lint

filter surface. Dry the lint filter

completely before reinstalling it.

CClean the entire inner surface of

the loading door and loading door

gasket.

Other manuals for DTGC8000W

This manual suits for next models

Table of contents

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions

Frigidaire

Frigidaire CAQE7077KW0 use & care
