BATHSELECT BST-008-1ORB User manual

Plumbers Tape Tape Measure Adjustable Wrench

Screwdriver

Drill

Hex Wrench

Level

Pencil or Marker

Thread Sealant

*not included

POSSIBLE TOOLS REQUIRED*

BATHSELECT DARK OIL RUBBED BRONZE/MATTE

BLACK SQUARE COLOR CHANGING LED RAIN

SHOWER HEAD INSTALLATION INSTRUCTIONS

Product code: BST-008-1ORB

Please read installation instructions below. All plumbing should be

installed in accordance with applicable building codes and regulations.

Unpack and inspect the items for any shipping damages. If you ﬁnd

damages, do not install.

All products must be installed by a professional and certiﬁed plumber

otherwise warranty may be voided.

PRIOR TO INSTALLATION

Customer Service: 800-500-9895

bathselect.com

Customer Service: 800-500-9895

bathselect.com

Shower Head Installations Instruction

Parts:

Step 3:

Step 1:

F F

Mark the 4 drilling positions then

use the Ø6mm drill to drill holes on the

wall according to the marked hole

position.

Inset the plug(D) into the hole, hold the ﬁx base (C) use the tapping screw (D) through

ﬁx base(C) holes, tighten the tapping screw (D) tighten the top shower ﬁxed bar(E) and

the inlet hose (F) with the ﬁx base (C)

Customer Service: 800-500-9895

bathselect.com

Fixed the top shower with the top shower ﬁxed bar (E) , then connect with the inlet hose

(F) . 2 Inlets for Rainshower are provided in big shower heads so the water disperses

equally throughout the showerhead.

The installation is completed.

Note: The LED lights are powered by water ﬂow, and will be activated once the water is

turned on.

Step 5:

Step 6:

Customer Service: 800-500-9895

bathselect.com

Acid

Care & Cleaning

General Information

1. The product can be cleaned with warm water, a mild soap and a clean soft cloth.

2. Clean progressively and gently.

3. It is not required to use any abrasive cleaning pads, wire wool or cloths to clean the

product.

4. Avoid a vigorous cleaning action, as this could contribute to denaturing and dulling

5. Abrasive or strong cleaning products containing ammonia, bleaches, alcohol, dyes,

acids (hydrochloric, formic, phosphorus, chlorine or acetic) will be not be affected.

All products manufactured and supplied by BathSelect are safe and comply to legislative

requirements. Providing they are installed correctly and receive regular maintenance in

accordance with these instructions your user experience will not be affected

6. If using a spray cleaner, apply the cleaning agent onto a soft cloth, never directly

spray onto the product as the cleaner may enter gaps and openings and cause

damage. Do not allow the cleaner to remain on the product for a period of time. After

cleaning, rinse thoroughly with clean water.
