Ameriwood HOME 6454335COM User manual

6454335COM

TallOneDoorCabinet

B346454335COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

LEFTHANDDOOR RIGHTHANDDOOR

DOORISREVERSIBLE

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



PresspartstogethersoCAMBOLTinserts

intoedgehole.

PressCAMBOLTintohole. PressCAMLOCKintohole.

Endhole

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

Arrowtopointtowardsend

holeinedgeofpart.

4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

37232335010

CDE

RightPanel

37232335020

Top

36454335030

Bottom

36454335040

TopRail

36454335070

LeftVerticalMolding

37232335100

Door

36454335090

BackPanel

K645433500

Thispieceispaperboardconstruction.

Itisnotmadefromwood,butis

requiredfortheassemblyofyourunit.

Shelf

36454335050

AdjustableShelf(x2)

36454335060

BottomRail

36454335080

RightVerticalMolding

37232335110

BACK

PNL

6

ameriwoodhome.com

BoardIdentification

Notactualsize

BACK

PNL

7

ameriwoodhome.com

PartList

ActualSize

NotActualSize

(x8)

#A22700

camlock

(x8)

#A22710

cambolt

(x8)

#A21670

wooddowel

(x12)

#A12120

7/16"screw

(x32)

#A21110

nail

(x1)

#A11080

7/16"screw

(x1)

#A35200

strikeplate

(x2)

#A17400

bolt

(x8)

#A80250

shelfsupport 14d

14a

14b

14c

(x1)

#A84050

safetybracket (x2)

#A51715

handle

(x3)

#A60110

hinge

(x4)

#A23030

confirmat

(x12)

#A22920

connector

(x12)

#A22910

connectorbolt

(x1)

#A31000

magnetcatchkit

8b 8c

8

ameriwoodhome.com

STEP1

(x6)

(x8) (x3)

LEFTHANDDOORSETUP

RIGHTHANDDOOR

HINGELOCATIONS

Note:

Beforetighteningscrews,besurethe

slotofthehingeiscenteredwithhole

intheVerticalMolding.

9

ameriwoodhome.com

STEP2

(x4)

Youwillneedtotaptheconnector(4)

withahammertofullyinsert.Besure

theconnectorispositionedasshown

beforetappingintohole.

10

ameriwoodhome.com

STEP3

(x4) (x4)

Youwillneedtotaptheconnector(4)

withahammertofullyinsert.Besure

theconnectorispositionedasshown

beforetappingintohole.
