Ameriwood HOME 5998222WCOM User manual

5998222WCOM

Dresser

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B345998222WCOM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

0 29986 59982 7

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.com

to view the

limited warranty valid in the U.S. and Canada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

LeftPanel

35998222010

RightPanel

35998222020

Top

35998222030

Bottom

35998222040

KickPanel

35998222050

4DrawerFronts

35998222061

4DrawerBacks

C1670608331500B

4LeftDrawerSides

C1670346331090L

4RightDrawerSides

C1670346331090R

Brace

35998000100

SolidBack

35998000110

4DrawerBottoms

35998331120

BackPanel

K59320000

CDE

5

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

Thispieceisofpaperboardconstruction.Itisnotmadefrom

wood,butisrequiredfortheassemblyofyourunit.

6

ameriwoodhome.com

PartList

ActualSize

Tube

You

(x12)

#A22510

cam bolt

(x40)

#A11080

7/16" flat screw

(x16)

#A11600

1-1/4" screw

(x12)

#A22570

cam lock

(x8)

#A21660

wood dowel

(x4)

#A53600

angle bracket

(x8)

#A12700

7/8" pan screw

(x18)

#A21110

nail

(x30)

#A12120

7/16" pan screw

7

ameriwoodhome.com

NotActualSize

PartList

Tube

You

(x4)

#A55990

drawer slide

(x8)

#A54223

drawer bracket (x1)

#A84050

safety bracket kit

(x4)

#A50690

handle

leftcabinet

member

rightcabinet

member leftdrawer

runner rightdrawer

runner

8

ameriwoodhome.com

STEP1

Tube

You

(x4)

#A22510

*rawedgesareshaded

(x1)

#A84050

Screwfourcamboltsintothetop(C).

Fastenthesafetybrackettothetop(C)withscrew.

9

ameriwoodhome.com

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

*rawedgesareshaded

(x4)

#A22570

(x4)

#A53600

(x2)

#A21660

(x8)

#A12120

Insertfourcamlocksandtwowooddowelsintothebottom(D).

Fastenthekickpanel(E)tothebottom(D)withfouranglebracketsandeightscrews.

10

ameriwoodhome.com

STEP3

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

(x4)

#A22570

(x4)

#A21660

Insertfourcamlocksandtwowooddowelsintothebottom(D).

Fastenthekickpanel(E)tothebottom(D)withfouranglebracketsandeightscrews.
