American Dryer Corp. ADS-464 Administrator Guide

ADC Part No. 112103

ADS-464

Installation/Operator's Manual

010496

011899DX/mt

WARNING: For your safety the

information in this manual must be

followed to minimize the risk of fire or

explosion or to prevent property damage,

personal injury or death.

Do not store or use gasoline or other flammable

vapor and liquids in the vicinity of this or any

other appliance.

For replacement parts, contact the distributor from which the dryer

was purchased or

American Dryer Corporation

88 Currant Road

Fall River MA 02720-4781

Telephone: (508) 678-9000 / Fax: (508) 678-9447

e-mail: [email protected]

AVERTISSEMENT: Assurez-vous de bien

suivre les instructions données dans cette

notice pour réduire au minimum le risque

d’incendie ou d’explosion ou pour éviter tout

dommage matériel, toute blessure ou la mort.

Ne pas entreposer ni utiliser d’essence ni

d’autres vapeurs ou liquides inflammables dans

le voisinage de cet appareil ou de tout autre

appareil.

Retain This Manual In A Safe Place For Future Reference

Replacement parts can be obtained from your distributor or the ADC factory. When ordering replacement parts from the

factory, you can FAX your order toADC at (508) 678-9447 or telephone your orders directly to the ADCPartsDepartmentat

(508) 678-9000. Please specify the dryermodelnumber andserialnumberin addition to thedescription andpartnumber,so

that your order is processed accurately and promptly.

DATE OF PURCHASE MODEL NO.

DISTRIBUTORS NAME

Serial Number(s)

ADS-464

American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is

properly maintained, it will provide many years of safe, efficient, and trouble-free operation.

ONLY qualified technicians should service this equipment.

OBSERVEALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation/operator's manual

included with the dryer.

The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.

FOR YOUR SAFETY

Do not store or use gasoline or

other flammable vapors or liquids

in the vicinity of this or any other

appliance.

POUR VOTRE SÉCURITÉ

Ne pas entreposer ni utiliser d’essence

ni d’autres vapeurs ou liquides

inflammables dans le voisinage de cet

appareil ou de yout autre appareil.

We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make

changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or

discontinue models.

Important

For your convenience, log the following information:

IMPORTANT

YOUMUSTDISCONNECTandLOCKOUTTHEELECTRICSUPPLYandTHESTEAM

SUPPLYBEFOREANYCOVERSorGUARDSAREREMOVEDFROMTHEMACHINE

TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING

OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration)

STANDARDS.

CHILDREN SHOULD NOTBE ALLOWED TO PLAY ON OR NEAR THE DRYERS.

WARNING

CHILDREN SHOULD BESUPERVISED IF NEAR DRYERS IN OPERATION.

DRYERS SHOULD NEVER BE LEFT UNATTENDED WHILE IN OPERATION.

CAUTION

FOR YOUR SAFETY

DO NOTDRY MOP HEADS IN THE DRYER.

DO NOT USE DRYER IN THE PRESENCE OF DRY CLEANING FUMES.

WARNING

UNDER NO CIRCUMSTANCES should the door switch or the heat circuit devices

ever be disabled.

“Caution: Label all wires prior to

disconnection when servicing controls. Wiring

errors can cause improper operation.”

«Attention: Lordesopérationsd’entretien

des commandes étiqueter tous fils avant

de les déconnecter. Toute erreur de

câblage peut étre une source de danger et

de panne.»

WARNING

The dryer must never be operated with any of the back guards, outer tops, or service

panels removed. PERSONAL INJURY or FIRE COULD RESULT.

IMPORTANT

PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or

specified in the installation/operator's manual included with the dryer.

Dryers mustnot be installed or stored in an area where it will be exposed to water or weather.

The wiring diagram for the dryer is located in the front electrical control box area.

DRYER MUSTNEVER BE OPERATED WITHOUT THE LINT FILTER (SCREEN) IN

PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED.

WARNING

Table of Contents

SECTION I

IMPORTANT INFORMATION ........................................................................................................ 3

A. Receiving and Handling ................................................................................................................ 3

B. Safety Precaution ......................................................................................................................... 4

SECTION II

SPECIFICATIONS/DIMENSIONS................................................................................................... 6

A. Specification ............................................................................................................................... 6

B. Dimensions ................................................................................................................................. 7

SECTION III

INSTALLATION PROCEDURES ..................................................................................................... 8

A. Reassembly of Dryer................................................................................................................... 8

B. Location Requirements ...............................................................................................................11

C. Internal Air, Electrical, and Water Connections ........................................................................... 12

D. External Supply Connections ..................................................................................................... 18

E. Electrical Requirements ............................................................................................................. 22

F. Fresh Air Supply Requirements ................................................................................................. 25

G. Steam Information ..................................................................................................................... 26

H. Shut Down Instructions ............................................................................................................. 27

SECTION IV

PRE START-UP................................................................................................................................. 28

A. Preparation for Operation .......................................................................................................... 28

SECTION V

ROUTINE MAINTENANCE........................................................................................................... 29

A. Cleaning ................................................................................................................................... 29

SECTION VI

COMPONENT SYSTEM DESCRIPTIONS................................................................................... 31

A. Tumbler Support and Drive System ........................................................................................... 31

B. Main Air Blower and Heat Reclaimer System............................................................................. 34

C. Compressed Air System............................................................................................................ 36

D. Safety Devices .......................................................................................................................... 39

SECTION VIII

SERVICE/PARTS INFORMATION................................................................................................ 41

A. Service ...................................................................................................................................... 41

B. Parts .......................................................................................................................................... 41

SECTION VIII

WARRANTY INFORMATION ....................................................................................................... 42

A. Returning Warranty Cards ......................................................................................................... 42

B. Warranty................................................................................................................................... 42

C. Returning Warranty Parts .......................................................................................................... 42

SECTION IX

TROUBLESHOOTING.................................................................................................................... 44

Troubleshooting TOC ..................................................................................................................... 44

A. Power Malfunctions .................................................................................................................. 45

B. Tumbler (Basket) Electrical Malfunctions ................................................................................... 56

C. Base Section Electrical Malfunctions .......................................................................................... 64

D. Pendent Control Malfunctions ................................................................................................... 68

E. Temperature Sensing ................................................................................................................. 71

F. Motors ..................................................................................................................................... 74

G. PLC (Programmable Logic Controller) Messages ..................................................................... 76

SECTION I

IMPORTANT INFORMATION

A. RECEIVING and HANDLING

The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or

optional box) as a means of preventing damage in transit. Upon delivery, the dryer and packaging, and wooden

skid should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect further

before delivering carrier leaves.

Dryers damaged in shipment.

1. ALL dryers should be inspected upon receipt and before they are signed for.

2. If there is suspected damage or actual damage, the trucker's receipt should be so noted.

3. If the dryer is damaged beyond repair, it should be refused. Those dryers which were not damaged in a

damaged shipment should be accepted, but the number received and the number refused must be noted on

the receipt.

4. If you determine that the dryer was damaged after the trucker has left your location, you should call the

delivering carrier's freight terminal immediately and file a claim. The freight company considers this

concealed damage. This type of freight claim is very difficult to get paid and becomes extremely difficult

when more than a day or two passes after the freight was delivered. It is your responsibility to file freight

claims. Dryer or parts damaged in transit cannot be claimed under warranty.

5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end.

ADC assumes no responsibility for freight claims or damages.

6. If you need assistance in handling the situation, please contact theADC Traffic Manager at (508) 678-9000.

IMPORTANT:The tumbler section of the dryer must be transported and handled in an upright

position at all times.

B. SAFETY PRECAUTIONS

WARNING:For your safety, the information in this manual must be followed to minimize the risk of

fire or explosion or to prevent property damage, personal injury, or loss of life.

WARNING:The dryer must never be operated with any of the back guards, outer tops, or

service panels removed. PERSONAL INJURY or FIRE COULD RESULT.

1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other

appliance.

2. Dryers must be exhausted to the outdoors.

3. Although ADC produces a very versatile machine, there are some articles that, due to fabric composition or

cleaning method, should not be dried in it.

WARNING:Dry only water-washed fabrics. DO NOT dry articles spotted or washed in dry cleaning

solvents, a combustible detergent or “all purpose” cleaner.

EXPLOSION COULD RESULT.

WARNING:DO NOT dry rags or articles coated or contaminated with gasoline, kerosene, oil, paint

or wax.

EXPLOSION COULD RESULT.

WARNING:DO NOT dry mop heads. Contamination by wax or flammable solvents will create a fire

hazard.

WARNING:DO NOT use heat for drying articles that contain plastic, foam, sponge rubber or similarly

textured rubber materials. Drying in a heated basket (tumbler) may damage plastics or

rubber and also may be a fire hazard.

4. A program should be established for the inspection and cleaning of lint in the burner area, exhaust duct

work, and inside the dryer. The frequency if inspection and cleaning can best be determined from experience

at each location.

WARNING:The collection of lint in the burner area and exhaust duct work can create a potential fire

hazard.

5. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the

NATIONAL ELECTRIC CODE ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the CANADIAN

ELECTRICAL CODES PARTS 1 & 2 CSA C22.1-1990 or LATEST EDITION.

NOTE:Failure to do so will VOID THE WARRANTY.

6. UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switches, heat safety

circuit, or tilt switches ever be disable.

WARNING: PERSONAL INJURY or FIRE COULD RESULT.

7. This dryer is not to be used in the presence of dry cleaning solvents or fumes.

8. Remove articles from the dryer as soon as the dryer cycle has been completed.

WARNING:Articles left in the dryer after the drying and cooling cycles have been completed can

create a fire hazard.

9. READ and FOLLOWALLCAUTIONandDIRECTIONLABELSATTACHED TOTHEDRYER.

WARNING: YOU MUST DISCONNECT and LOCKOUT THE ELECTRICAL SUPPLY and

THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED

FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING,

ADJUSTING, INSTALLATION OR TESTING OF ANY EQUIPMENT per

OSHA (Occupational Safety and Health Administration) STANDARDS.

The lightening flash with an arrow head within an

equilateral triangle, is intended to alert the user to the

presenceofnon-insulated “dangerous voltage”within

the products enclosure that may be sufficient in

magnitude to constitute a risk of electrical shock to

any person.

The Exclamation point “!” within an equilateral triangle

is intended to alert the user to the presence of

important operating and maintenance (servicing)

instructions in the literature accompanying the

appliance.

SECTION II

SPECIFICATIONS/DIMENSIONS

A. SPECIFICATIONS

NOTE:ADC reserves the right to make changes in specifications at any time, without notice or

obligation.

MAXIMUM CAPACITY (DRYWEIGHT)460 lbs. 208.66 kg

Total Weight 10,500 lbs. 4,762.7 kg

Total Shipping Weight 10,800 lbs. 4,898.8 kg

Tilt Height 137-1/4" 348.6 cm

Operating Height 114-1/2" 290.83 cm

Full Tilt Depth 117-1/2" 298.45 cm

Operating Depth 95" 241.3 cm

Width 122" 309.88 cm

Tilt Load (REARTILT )15º

Tilt Unload (FRONTTILT)15º

Loading Height from Floor 65-5/8" 166.69 cm

Tumbler (BASKET) Diameter 69-1/8" 175.58 cm

Tumbler (BASKE T) Depth 80-5/16" 203.99 cm

Tumbler (BASKE T) Volume 175 cu. ft. 4.96 cu. m

Minimum Load Size 250 lbs. 113.4 kg

Maximum Load Size 460 lbs. 208.66 kg

Blower Motor 25 HP 18.64 kw

Tumbler (BASKET) Motors (2MOTORS)(2) 5 HP (2) 3.73 kw

Boiler Horsepower 60 Bhp

Steam Inlet Size Connection 2-1/2" N.P.T. ---

Burner Blower Motor 1-1/2 HP 1.12 kw

Blower Maximum Airflow 13,000 cfm 368 cmm

Maximum Duct Back Pressure 1.25" W.C. 3.1 mbar

Minimum Duct Diamemter 24" 60.96 cm

Compressed Air Pressure Required 80 psi (±10 psi) 551.6 kpa (±68.95 kpa)

Compressed Air Volume Required 20 cf/hr .57 cm/hr

Compressed Connection 3/8" N.P.T. ---

Shaded areas are stated in metric equivalents

Table of contents

Other American Dryer Corp. Dryer manuals

American Dryer Corp.

American Dryer Corp. Milnor M50SL User manual

American Dryer Corp.

American Dryer Corp. ML-25V User manual

American Dryer Corp.

American Dryer Corp. AD-100 User manual

American Dryer Corp.

American Dryer Corp. 20/31 Manual

American Dryer Corp.

American Dryer Corp. ES20 Administrator Guide

American Dryer Corp.

American Dryer Corp. ES76 Administrator Guide

American Dryer Corp.

American Dryer Corp. Phase 7 Gas/Steam AD-464 User manual

American Dryer Corp.

American Dryer Corp. Phase 7 OPL/Fire Suppression System EURO-14 User manual

American Dryer Corp.

American Dryer Corp. AD30 2R Series User manual

American Dryer Corp.

American Dryer Corp. AD-758DV User manual

American Dryer Corp.

American Dryer Corp. AD-540 Manual

American Dryer Corp.

American Dryer Corp. ML-122D User manual

American Dryer Corp.

American Dryer Corp. AD-81 II User manual

American Dryer Corp.

American Dryer Corp. ML-175 User manual

American Dryer Corp.

American Dryer Corp. AD-202 User manual

American Dryer Corp.

American Dryer Corp. ML-190 User manual

American Dryer Corp.

American Dryer Corp. AD-25V Administrator Guide

American Dryer Corp.

American Dryer Corp. AD-235D User manual

American Dryer Corp.

American Dryer Corp. HBG76 Administrator Guide

American Dryer Corp.

American Dryer Corp. ADE-50S User manual

American Dryer Corp.

American Dryer Corp. ML-96HS User manual

American Dryer Corp.

American Dryer Corp. AD-115ES II User manual

American Dryer Corp.

American Dryer Corp. Gas/HSI & Steam ID-120 User manual

American Dryer Corp.

American Dryer Corp. AD-115ES II User manual

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions
