AE–1800 Instruction Manual

UM–AE1800–1.0

First Edition January, 2008

ALDEN

NAVTEX RECEIVER

MODEL AE–1800

INSTRUCTION MANUAL

AE–1800 Instruction Manual

WARRANTY

MORCOM International, Inc. (MORCOM) warrants the AE–1800 NAVTEX Receiver

and its active antenna ANT–2000 against defects in materials and workmanship for a

period of one year from the date of shipping from the factory, during which time

MORCOM will, at its option, either repair or replace the products that prove to be

defective.

Users shall ship defective products, freight prepaid, back to a specified MORCOM dealer

for warranty service.

The warranty shall not apply to defects caused by:

●Misuse or incorrect usage

●Static discharges/lightning strikes to the antenna or to the receiver or other types of

natural disaster

●RF power from radio transmitters in excess of 30V RMS at the antenna input

●Improper or inadequate maintenance by the user

●Unauthorized service including modification, realignment of the receiver/antenna

●User–supplied software or interfacing

●Operation outside the environmental specifications listed in the manual, or

●Improper installation

The above warranty applies to the original user with a proof of purchase.

Before returning the unit to your MORCOM dealer for warranty service, please obtain

MORCOM’s return authorization.

When shipping the unit to your dealers for service, please be sure to include the

following types of information:

･Serial number

･Software release date and revision (REV.) number

･Power supply voltage

･Installation details, including antenna height and surrounding environment

･Detailed description of trouble

･Valid proof of purchase from authorized MORCOM dealer

MORCOM International, Inc.

3656 Centerview Drive, Unit #1

Chantilly, VA 20151 – U. S. A.

PHONE: (703)263–9305

FAX: (703)263–9308

www.morcom.com

AE–1800 Instruction Manual

IIMPORTANT NOTES

IMPORTANT NOTES

1. RADIO FREQUENCY INTERFERENCE

This equipment has been tested and found to comply with the limits for a

Class A digital device pursuant to Part 15 of FCC Rules. These limits are

designed to provide reasonable protection against harmful interference

when this equipment is operated in a commercial environment.

This equipment generates, uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his/her own expense.

2. PURPOSE OF THIS MANUAL

The purpose of this manual is to help the user operate and maintain the

equipment. The information provided is not to be considered as a contractual

specification.

3. USER’S RESPONSIBILITY

The Alden Model AE–1800 NAVTEX Receiver obtains data transmitted

from Government facilities. MORCOM International Inc. (MORCOM)

makes no claim as to the accuracy, completeness or currency of the data

since the AE–1800 only provides a means of receiving the data. Users are

completely responsible for verifying the correctness and currency of all

data received, and MORCOM shall not be liable to users for any loss,

damage or liability caused directly or indirectly by such use. Users are

solely responsible for action taken or not taken as a result of the reception

or non–reception of data.

MORCOM International, Inc.

3656 Centerview Drive, Unit #1

Chantilly, VA 20151 – U. S. A.

PHONE: (703)263–9305

FAX: (703)263–9308

www.morcom.com

AE–1800 Instruction Manual

WARNINGS

< WARNINGS >

1. INSTALLATION & OPERATING ENVIRONMENT

THE DISPLAY CABINET IS IN THE “PROTECTED” EQUIPMENT

CATEGORY AS DEFINED UNDER IEC 60945(2002), AND IS NOT

WEATHERIZED FOR OUTDOOR INSTALLATION/OPERATION. ANY

DAMAGE CAUSED DIRECTLY OR INDIRECTLY THROUGH WATER

INTRUSION IS NOT COVERED BY THE MANUFACTURER’S OR

DEALER’S WARRANTY.

2. INSTALLATION & OPERATING PROCEDURES

ANY DAMAGE CAUSED BY INSTALLING OR OPERATING THE

EQUIPMENT OUTSIDE THE SPECIFICATIONS DESCRIBED IN THIS

MANUAL IS NOT COVERED BY THE MANUFACTURER’S OR

DEALER’S WARRANTY.

CONTACT YOUR DEALER FOR WARRANTY CONDITIONS.

3. LIABILITY

●OPERATION

NEITHER THE MANUFACTURER NOR ITS DEALER IS RESPONSIBLE

FOR ANY LOSS OF LIFE, PERSONAL INJURY OR DAMAGE TO THE

PROPERTY RESULTING FROM THE USE OF THIS EQUIPMENT OR

FROM BEING, FOR ANY REASON, UNABLE TO EITHER OPERATE

THE EQUIPMENT OR RECEIVE INTENDED NAVTEX MESSAGES.

●MANUAL

REASONABLE PRECAUTIONS HAVE BEEN TAKEN TO PREPARE THIS

MANUAL. HOWEVER, NEITHER THE MANUFACTURER NOR ITS

DEALER ASSUMES ANY RESPONSIBILITY FOR ERRORS OR

OMISSIONS.

AE–1800 Instruction Manual

CAUTIONS

< CAUTIONS >

1: Operational – Memory Retention Period

Do not leave the equipment switched off for more than 10 days

continuously, or all stored messages will be erased, whether

they are protected or not. Important messages you wish to

preserve should be output to an optional printer or to a PC via

an appropriate rear panel interface connector if the unit is to be

kept turned off for extended periods of time.

2: Operational – “Memory–Full” Indication

As soon as the equipment has stored a total of 199

messages, the following caution will show up in the bottom

command/prompts line along with 3 beeps:

MEMORY FULL ! [CLR]TO ACKNLG.

The oldest message will then be erased from memory

automatically after reception of a next new message. As

soon as you notice the above warning, be sure to

acknowledge each unread message by pressing , and if

necessary, press to protect important messages you

wish to retain for permanent storage.

3: Environmental Safety – Equipment Disposal

The display cabinet and the active antenna unit are

considered environmentally safe in their original, assembled

forms. However, if either unit is to be discarded for any reason,

be sure to follow all relevant local ordinances/regulations, and

contact your dealer or the manufacturer (contact information

given below) for assistance or instructions before disposing

of it. Do not destroy the cabinet or the antenna casing.

MORCOM International, Inc.

3656 Centerview Drive, Unit #1

Chantilly, VA 20151 – U. S. A.

PHONE: (703)263–9305

FAX: (703)263–9308

www.morcom.com

AE–1800 Instruction Manual

Index

1. Typical NAVTEX Message Screen.............................................................1-1

1.1. Introduction........................................................................................................1-1

1.2. Indication of Reception and Storage of New NAVTEX Message......................1-6

2. Control Panel Functions .........................................................................2-1

3. Basic Operating Procedure.......................................................................3-1

3.1. Introduction........................................................................................................3-1

3.2. Turning the Equipment On/Off.........................................................................3-1

3.3. Adjusting Screen Brightness ...........................................................................3-2

3.4. Adjusting Keypad Backlighting Level ..............................................................3-2

3.5. Switching First and Second Receivers ..............................................................3-2

3.6. Scrolling NAVTEX Messages.............................................................................3-3

3.7. Stopping Audible and Visual Alarm ..................................................................3-4

3.8. Protecting Messages for Permanent Storage....................................................3-5

3.8.1. Introduction ..............................................................................................3-5

3.8.2. Protecting Procedure ..............................................................................3-5

3.8.3. Removing Protection Tag ......................................................................3-6

4. Customizing Operation via Menu System...................................................4-1

4.1. Introduction........................................................................................................4-1

4.2. Accessing the Menu System ..............................................................................4-1

4.3. Selecting Screen Background Colors ................................................................4-2

4.4. Selecting Message Font Types...........................................................................4-2

4.5. Turning on/off Screen Sleep Mode.....................................................................4-3

4.5.1. Introduction ..............................................................................................4-3

4.5.2. Turning Sleep Mode on ............................................................................4-3

4.5.3. Setting Times to Reduced Brightness Levels ......................................4-4

4.6. Selecting Frequencies for Second Receiver.......................................................4-4

4.7. Turning on/off Keypress Beep ...........................................................................4-5

4.8. Selecting and Rejecting Transmitters...............................................................4-6

4.8.1. Introduction .............................................................................................4-6

4.8.2. Setting Procedure ...................................................................................4-6

4.9. Selecting and Rejecting Message Types............................................................4-8

4.9.1. Introduction.............................................................................................4-8

4.9.2. Setting Procedure..................................................................................4-8

4.10. Searching Memory for Stored Messages......................................................... 4-11

4.11. Selecting Output Messages .............................................................................4-12

AE–1800 Instruction Manual

Index

4.11.1. Introduction ............................................................................................4-12

4.11.2. Outpu t t ing Live NAVTEX Messages ................................................4-13

4.11.3. Outputting All Stored Messages .......................................................4-14

4.11.4. Outputting NAVTEX Messages of Specific Receiver ....................4-15

4.11.5. Outputting NAVTEX Messages of Specific Station ......................4-16

4.11.6. Outputting NAVTEX Messages of Specific Message Type...........4-17

4.11.7. Outputting All Displayed NAVTEX Messages ...............................4-18

4.11.8. Outputting Specific NAVTEX Message...........................................4-19

4.12. Setting Output Ports .......................................................................................4-20

4.12.1. Introduction ..........................................................................................4-20

4.12.2. Enabling / Disabling I / O Ports .............................................................4-20

4.12.3. Selecting Communications Protocols ...........................................4-22

4.12.4. Selecting Bit Formats and Data Transfer Rates ......................4-23

4.13. Performing Self–Diagnostic Tests ..................................................................4-26

4.13.1. Introduction ............................................................................................4-26

4.13.2. Activating Self–Diagnostic Test Function.........................................4-26

4.13.3. Checking Test Results .............................................................................4-27

4.14. Turning on/off Message Alarms.......................................................................4-28

4.15. Resetting the System......................................................................................4-29

5. User–Level Troubleshooting .....................................................................5-1

5.1. Power–Up Problems...........................................................................................5-1

5.2. No Message Reception .......................................................................................5-2

5.3. Message Storage Problems................................................................................5-4

5.4. Poor Reception ...................................................................................................5-5

5.5. Blank Message Screen.......................................................................................5-6

5.6. Uncontrollable Screen Brightness.....................................................................5-6

5.7. No Beep from Keypress .....................................................................................5-6

5.8. No Response from Keypress ..............................................................................5-7

5.9. No Message Alarm Indication ...........................................................................5-7

5.10. No Message Alarm Output ................................................................................5-8

5.11. No External Outputs .........................................................................................5-8

5.12. External Control Problem .................................................................................5-9

6. User–Level Maintenance Instructions ................................................6-1

6.1. Maintenance on the Equipment Cabinet ..........................................................6-1

6.2. Maintenance on Electrical Connections............................................................6-1

6.3. Maintenance on The Active Antenna Unit........................................................6-2

AE–1800 Instruction Manual

Index

6.4. Self–Diagnostic Tests.........................................................................................6-2

6.5. Recommended Spare Parts................................................................................6-3

7. Installation ............................................................................................7-1

7.1. Receiver Cabinet Installation............................................................................7-1

7.1.1. General Precautions ...............................................................................7-1

7.1.2. Mounting the Receiver Cabinet..................................................................7-1

7.2. Antenna Installation..........................................................................................7-3

7.2.1. Installation Site Requirements ..................................................................7-3

7.2.2. Precautions for Cabling ..............................................................................7-3

7.3. Electrical Connections .......................................................................................7-5

7.3.1. Introduction ..............................................................................................7-5

7.3.2. Connector Pin Assignments and Connections ....................................7-7

7.4. INS Port Data and Command Sentences........................................................7-15

7.4.1. Received NAVTEX Sentence Format .................................................7-15

7.4.2. Controlling Receiver Operation via INS (RS–422) Port ...............7-17

7.4.3. Checking Current Settings via INS (RS–422) Port.......................7-18

7.4.4. Alarm Output Sentence Formats.......................................................7-19

7.4.5. Alarm Acknowledgement .....................................................................7-20

7.4.6. Proprietary Sentence (Switching 2nd Receiver Frequency ) ........7-20

8. Summarized Theory of Operation ........................................................8-1

8.1. What is NAVTEX?..............................................................................................8-1

8.2. Operating Frequencies ......................................................................................8-1

8.3. Service Area........................................................................................................8-1

8.4. Error Correction.................................................................................................8-1

8.5. NAVTEX Receiver – General.............................................................................8-2

8.6. The AE–1800 NAVTEX Receiver ......................................................................8-2

8.7. Operating Principle of AE–1800........................................................................8-3

9. Specifications .........................................................................................9-1

10. List of Alarms ......................................................................................10-1

10.1. Message Alarms ...............................................................................................10-1

10.2. Operational Alarms..........................................................................................10-1

11. List of Abbreviations ........................................................................... 11-1

12. User Settings To Be Stored in Non–Volatile Memory ............................12-1

13. List of Components To Be Shipped .........................................................13-1

AE–1800 Instruction Manual

Typical NAVTEX Message Screen

1. Typical NAVTEX Message Screen

1.1. Introduction

The illustration below represents a typical NAVTEX message screen, showing a new

message received on the first (518 kHz) receiver. A similar screen will show up when

the equipment is switched to receive a second receiver (490 kHz or 4209.5 kHz) message.

A brief description of on–screen indications is given below and in the following pages.

Figure 1-1 Typical NAVTEX Message Screen (First Receiver Page)

①Indication of Receiver in Use to Display Current Messages

･1ST RCVR: First receiver, 518 kHz

･2ND RCVR1: Second receiver, 490 kHz or 2ND RCVR2:4209.5 kHz

The two receivers can be switched by pressing or by means of a software

command from an IBS/INS terminal via the rear panel RS–422 connector (INS

port). See paragraph 7.4 for details.

②Message No. and Total No. of Messages Stored

The message number of the currently displayed message along with the total

number of stored messages is indicated in the following format:

Examples:

・12/12: Message #12 (newest message) of 12 messages stored

・1/12: Message #1 (oldest message ) of 12 messages stored

(

continued on next page

)

1ST RCVR MSG (12/12)   STANDBY

JD13 INEW MESSAGEIIALARM!II

011400 UTC JAN

POLISH SAR INFO 003

SOUTHEASTERN BALTIC

FISHING VESSEL OF UNIDENTIFIED REGISTRY

IS ON FIRE AND IS IN DANGER OF SINKING IN

POSITION 55–22.23N 14–40.37E.

ALL SHIPS IN THE VICINITY ARE URGENTLY

REQUESTED TO RUSH TO THE SITE AND OFFER

ASSISTANCE.

NNNN

STORED (CER= 00%)

MORE NEW MSG LEFT !

①②③④

⑤

⑥

⑨

⑩

⑬

⑦

⑧

⑪

⑫

AE–1800 Instruction Manual

Typical NAVTEX Message Screen

1. Typical NAVTEX Message Screen (

continued – 2/6

)

1.1. Introduction (

continued – 2 /5

)

③Message Scrolling Keys

The keys that can be used to manually scroll messages across the current screen

are indicated.

・ : Line–by–line scrolling by pressing /

・: Message–by–message scrolling by pressing



NOTE: When a type–D message (SAR, piracy and armed robbery information) is

received on either the first or second receiver, automatic scrolling will be disabled until

the user acknowledges the

message with



or with a software command from an

IBS/INS terminal via the rear–panel

RS–422

connector. See paragraph 7.4 for details.

④Receiver Operating Status Indication

The current status of receiver operation is indicated here.

・ABORTED: The receiver has failed to lock onto the current transmission,

due, for example, to weak signal level or noise interference.

No message will be displayed or stored.

NOTE: Signal propagation conditions change greatly with time.

You might not be able to receive a signal in the daytime that can

be received at night; this is normal and should not be considered

as a sign of receiver malfunction.

・ACQUIRING: The receiver is currently in the process of locking onto the

start of the current message transmission.

・LOCKED: The receiver has locked onto current NAVTEX transmission,

allowing a message to be received. As soon as the equipmet

starts receiving the message, this indication will be replaced

by RCVNG MSG.

・RCVNG MSG: The receiver is properly receiving a message after locking

onto current transmission. This blinking indication will stay

until the end–of–message code NNNN (⑩) is received.

NOTE: Whether to display or output the message to external

devices depends on the character error rate

(CER, ⑫)

and on

the selection/rejection settings to be made via the procedure in

paragraph 4.8.

・STANDBY: The receiver is idling, waiting for a NAVTEX message

transmission to begin. Most stations transmit messages every

4 hours.

⑤Operating Status Line

The current status of receiver operation, text scroll keys, etc. are indicated here.

Examples:

・1ST RCVR MSG: Message received on the first receiver is currently displayed.

・2ND RCVR MSG: Message received on the second receiver (490 or 4209.5 kHz)

is currently displayed.

・ : Message can be scrolled line by line by pressing /.

・STANDBY: Receiver is idling, waiting for a NAVTEX message

transmission. See ④above for details.

(

continued on next page

)

Table of contents
