AEG LAVATHERM 59840 User manual

LAVATHERM 59840

User manual Condenser Dryer with

Heat Pump

Dear Customer

Thank you for choosing one of our high-quality products.

With this appliance you will experience the perfect combination of functional

design and cutting edge technology.

Convince yourself that our appliances are engineered to deliver the best

performance and control - indeed we are setting the highest standards of

excellence.

In addition to this you find environmental and energy saving aspects as an integral

part of our products.

To ensure optimal and regular performance of your appliance please read this

instruction manual carefully. It will enable you to navigate all processes perfectly

and most efficiently. To refer to this manual any time you need to, we recommend

you to keep it in a safe place. And please pass it to any futureowner of the appliance.

We wish you much joy with your new appliance.

The following symbols are used in this user manual:

Important information concerning your personal safety and information on how

to avoid damaging the appliance.

General information and tips

Environmental information

Contents

Operating Instructions 5

Important safety information 5

Product description 8

Control panel 9

What is shown in the display 9

Before first use 10

Sorting and preparing laundry 11

Programme chart 12

Daily use 15

Switching machine on / switching light on 15

Opening loading door / loading laundry 15

Selecting the programme 15

Setting dryness level 16

Setting the pre-drainage spin speed 16

Setting long anti-crease function 17

Buzzer 17

Time 17

Setting delay timer 18

Setting child lock 18

Starting the programme 19

Changing programme 19

Putting in extra items or taking items out before end of programme 19

Drying cycle complete / removing laundry 20

Care and cleaning 21

Cleaning fluff filter 21

Cleaning the door seal 23

Emptying the condensate tank 23

Cleaning heat exchanger filter 24

Cleaning the drum 26

Clean operating screen and housing 27

What to do if ... 28

Troubleshooting by yourself 28

Contents 3

125989520-01-14012008

Changing the bulb for interior lighting 29

Machine settings 31

Technical data 32

Consumption values 33

Hints for test institutes 33

Installation 34

Transporting the appliance 34

Appliance positioning 34

Removing transport safety packaging 35

Electrical connection 36

Permanent connection 37

Changing door stop 37

Special accessories 38

Environment 40

Packaging material 40

Old appliance 40

Environmental tips 41

Guarantee/Service 42

Guarantee/Customer Service 42

GREAT BRITAIN & IRELAND 42

European Guarantee 44

Service 45

www.electrolux.com 45

Subject to change without notice

4Contents

Operating Instructions

Important safety information

In the interest of your safety and to ensure the correct use, before installing

and first using the appliance, read this user manual carefully, including its

hints and warnings. To avoid unnecessary mistakes and accidents, it is im-

portant to ensure that all people using the appliance are thoroughly familiar

with its operation and safety features. Save these instructions and make

sure that they remain with the appliance if it is moved or sold, so that ev-

eryone using it through its life will be properly informed on appliance use

and safety.

General safety

• It is dangerous to alter the specifications or attempt to modify this product in

any way.

• This appliance is not intended for use by persons (including children) with re-

duced physical, sensory or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the appliance by a per-

son responsible for their safety.

• Make sure that small pets do not climb into the drum. To avoid this, please check

into the drum before using.

• Any objects such as coins, safety pins, nails, screws, stones or any other hard,

sharp material can cause extensive damage and must not be placed into the

machine.

• In order to avoid danger of fires caused by excessive drying, do not use appliance

to dry the following items: Cushions, quilts and the like (these items accumulate

heat).

• Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber

backed articles and clothes or pillows fitted with foam rubber pads should not

be dried in the tumble dryer.

• Always unplug the appliance after use, clean and maintenance.

• Under no circumstances should you attempt to repair the machine yourself.

Repairs carried out by inexperienced persons may cause injury or serious mal-

functioning. Contact your local Service Centre. Always insist on genuine spare

parts.

Important safety information 5

• Items that have been soiled with substances such as cooking oil acetone, petrol,

kerosene, spot removers, turpentine, waxes and wax removers should be washed

in hot water with an extra amount of detergent before being dried in the tumble

dryer.

•Danger of explosion: Never tumble dry items that have been in contact with

inflammable solvents (petrol, methylated spirits, dry cleaning fluid and the like).

As these substance are volatile, they could cause an explosion. Only tumble dry

items washed with water.

•Risk of fire: items that have been spotted or soaked with vegetable or cooking

oil constitute a fire hazard and should not be placed in the tumble dryer.

• If you have washed your laundry with stain remover you must execute an extra

rinse cycle before loading your tumble dryer.

• Please make sure that no gas lighters or matches have accidentally been left in

pockets of garments to be loaded into appliance

WARNING!

Never stop a tumble dry before the end of the drying cycle unless all items

are quickly removed and spread out so that the heat is dissipated. Risk of

fire!

•Risk of electric shock! Do not spray down the appliance with jets of water.

Installation

• This appliance is heavy. Care should be taken when moving it.

• When unpacking the appliance, check that it is not damaged. If in doubt, do not

use it and contact the Service Centre.

• All packing and transit bolts must be removed before use. Serious damage can

occur to the product and to property if this is not adhered to. See relevant section

in the user manual.

• The final part of a tumble dryer cycle occurs without heat ( cool down cycle ) to

ensure that the items are left at a temperature that ensures that items will not

be damaged.

• Any electrical work required to install this appliance should be carried out by a

qualified electrician or competent person.

• Care must be taken to ensure that the appliance does not stand on the electrical

supply cable.

• If the machine is situated on a carpeted floor, please adjust the feet in order to

allow air to circulate freely.

6Important safety information

• After having installed the appliance, check that it is not pressing or standing on

its electrical supply cable.

• If the tumble dryer is placed on top of a washing machine, it is compulsory to

use the stacking kit (optional accessory).

Use

• This appliance is designed for domestic use. It must not be used for purposes

other than those for which it was designed.

• Only wash fabrics which are designed to be machine dried. Follow the instruc-

tions on each garment label.

• Do not dry unwashed items in the tumble dryer.

• Do not overload the appliance. See the relevant section in the user manual.

• Clothes which are dripping wet should not be placed in the dryer.

• Garments which have been in contact with volatile petroleum products should

not be machine dried. If volatile cleaning fluids are used, care should be taken

to ensure that the fluid is removed from the garment before placing in the

machine.

• Never pull the power supply cable to remove the plug from the socket; always

take hold of the plug itself.

• Never use the tumble dryer if the power supply cable, the control panel, the

working surface or the base are damaged so that the inside of the tumble dryer

is accessible.

• Fabric softeners, or similar products should be used as specified by the fabric

softener instructions.

•Caution -hot surface : Do not touch the door light cover surface when the

light is switched on.

Child safety

• This machine is not intended for use by young children or infirm persons without

supervision.

• Children should be supervised to ensure that they do not play with the appliance.

• The packaging components (e.g. plastic film, polystyrene) can be dangerous to

children - danger of suffocation! Keep them out of children’s reach.

• Keep all detergents in a safe place out of children’s reach.

• Make sure that children or pets do not climb into the drum.

1) Only dryers equipped with internal drum light.

Important safety information 7

Product description

1Control panel

2Drawer with condensed water container

3Lamp for inside light

4Fine strainer (lint filter)

5Large mesh filter (lint filter)

6Micro-fine filter (lint filter)

7Rating plate

8Loading door (reversible)

9Base door upstream of fluff filter and heat exchanger

10 Button for opening door in plinth

11 Air slots

12 Screwed feet (with height adjustment)

8Product description

Control panel

123

456

1Programme knob and OFF switch

2Function buttons

3START PAUSE button

4DELAY START button

5Status led

6Display

What is shown in the display

1356

4 2

Control panel 9

1time to end / error message

2cycle phase status

3options

4warnings

5spin speed selection

6dryness selection

Before first use

WARNING!

If the appliance was not transported in an upright position, leave it to stand for 12

hours before connecting it to the electricity supply and using it for the first time,

so that the oil can flow back to the compressor. Otherwise the compressor could

be damaged.

In order to remove any residues which may have been produced during production,

wipe the dryer drum with a damp cloth or carry out a brief drying cycle (30 MIN)

with damp cloths in the machine.

10 Before first use
