ACTiSYS IR100MP User manual

No External Power, No Battery

IR100MP is the only IrDA® printer adapter without

external power or battery requirement on the market

Common Advantage of ACTiSYS IrDA®

Intelligent Parallel and Serial Adapters

Most efficient and IrDA® compliant protocol stack built

in, compatible with wide range of IrDA enabled devices

and Operating Systems

IR100MP enables the most reliable and efficient IR

wireless data transfer and quick and easy wireless

printing

Compatible with Palm O.S.-, Windows CE-, Symbian-

based PDA,, IrDA-enabled cellphone, smart phone,

industrial data terminal, notebook PC, and consumer

devices

IR Print Application Software For PDA

Available separately and as free demo, OEM driver

is also available

ACTiPrintCE:

The premier mobile printing solution for WindowsCE-

based Pocket PC. It prints Pocket Word and rich text

(RTF) documents with full formatting, color and

images, Emails, and plain text (TXT) files. It prints to

a wide variety of infrared (or IR adapter-enabled)

parallel and serial printers

ACTiPrintPalm:

The easy to use mobile printing solution for Palm

O.S.-based handheld devices. It prints Memo, Email,

Contact, Calendar, Todo, to most Infrared (or IrDA

adapter-enabled) parallel and serial printers

ACTiSYS

ACT

ACT-

-IR100MP

IR100MP

IrDA

IrDA®

® IR Adapter for Printer

IR Adapter for Printer

IrReadyTM certified by

Infrared Data Association® (IrDA)

IrDA® PROTOCOL:

Compliant with IrDA® standard, including

IrPHYTM, IrLAPTM, IrLMPTM and IrLPTTM,

supporting data rates 9.6K, 19.2K, 38.4K,

57.6K and 115.2K bps

COMMUNICACTION RANGE:

Up to 100 cm

CONNECTOR:

Standard CEN36 connector

POWER SOURCE:

No External Power or Battery Needed

DIMENSIONS/WEIGHT:

80mm x 55mm x 25mm(L x W x H)

3.15in x 2.17in x 0.98in (L x W x H)

7.0 Oz ( 198.6 g)

Cable length : 120 cm (3.9 ft)

Compatible With the Following

Device Models:

Notebook:

All IrDA® notebook PC running

appropriate IrDA application software

Printer:

HP, Canon, Epson, Brother, Okidata,

Xerox, other parallel printers

(Please check website for latest printer

models.)

Software and O.S. :

Microsoft Windows 95,98,2000,ME,XP

IR print software:

PalmO.S.

ACTiPrintPalm, PalmPrint, PrintBoy

InStepPrint, Irprint

WindowsCE:

ACTiPrintCE, PocketPrint

Cellphone:

Nokia 9110, Nokia 900il, Nokia 9000,

Nokia 9250, Nokia 9290, others

PDA and Samrt Phone:

All WindowsCE PocketPC, Casio, HP

Compaq, NEC

Palm O.S. :

Palm, Handspring, HandERA, Sony

Educational Computer:

Alpha Smart and others

ACTiSYS

ACT

ACT-

-IR100MP

IR100MP

Specification

ACTiSYS Corporation

921 Corporate Way, Fremont,

CA94539, USA

Tel: +1-510-490-8024

Fax: +1-510-623-7268

E-mail:irda-info@actisys.com

http://www.actisys.com

OEM, VAR, Distributor and Dealer Inquiries are Welcome

OEM, VAR, Distributor and Dealer Inquiries are Welcome.
