ActionTec GT701R User manual

Solutions for the Digital Life™

User Manual

Ver 1.0

DSL Modem

Model #: GT701R

Table of Contents

1 Introduction 1

Package Contents 1

Minimum System Requirements 1

Features 2

Technical Support 5

2 Setting Up the Modem 9

Attention! 9

Connecting a Computer to the Modem 10

Installing Phone Filters 28

Setting Up the DSL Connection 33

3 Using Qwest DSL 45

Connecting to the Internet 45

Disconnecting from the Internet 45

4 Basic Setup 47

Basic Setup 47

Changing the User Name and Password 49

5 Setting Up Static IP Address 51

Configuring for a Single Static IP Address 51

Configuring for a Block of Static IP Addresses 56

6 Advanced Settings 61

Accessing Advanced Setup 61

WAN IP Address 62

LAN IP Address 68

DHCP Server 68

Services Blocking 70

Website Blocking 71

Remote Management/Telnet 72

Port Forwarding 73

DMZ Hosting 74

Firewall 74

Dynamic Routing 75

NAT (Network Address Translation) 75

Static Routing 76

Telnet Timeout Setting 76

Status 77

Actiontec DSL Modem User Manual

iii

Table of Contents

7 Using Utilities 83

Web Activity Log 83

DSL Settings 84

Restore Default Settings 85

Upgrade Firmware 85

OAM Ping Test 86

8 Setting Up a Network 87

Ethernet 87

USB 93

9 Troubleshooting 101

A Reference 105

Locating Computer Information 105

Locating Windows Operating System Files 106

B Static IP Address on the Computer 109

Windows 98 SE 109

Windows Me 112

Windows 2000 115

Windows XP 119

C Computer Security 125

Comparing DSL Service with a Dial-Up Modem 125

Modem Security 126

Computer Security 126

Electronic Security 127

D Specifications 129

General 129

LED Indicators 130

Environmental 130

E Glossary 131

F Firewall Security Level Services Table 135

High Security Level 135

Medium Security Level 136

Low Security Level 136

Basic Security Level 137

Service Acronym Definitions 137

G Non-Windows System Setup 139

Classic 139

OS X 141

Connecting to the ISP 142

Actiontec DSL Modem User Manual

iii

Table of Contents

H Additional Technical Support Options 145

Self Help 145

Basic Setup Support: Getting Online 145

Advanced Feature Support 146

Networking (LAN) Support 146

Notices 149

Regulatory Compliance Notices 149

Modifications 149

Limited Warranty 151

Actiontec DSL Modem User Manual

This page left intentionally blank.

Introduction

Thank you for purchasing the Actiontec 54 Mbps DSL Modem. The Modem is the

simplest way to connect computers to a high-speed broadband connection. This

easy-to-use product is perfect for the office or small business. If you want to take

your computing to the next level, the Actiontec 54 Mbps DSL Modem is sure to be

one of the keys to your success.

Package Contents

s Actiontec 54 Mbps DSL Modem

s Power adapter

s Phone filters

s DSL cable

s Ethernet cable

s USB cable

s Installation CD-ROM

s Quick start guides

Minimum System Requirements

s Active DSL service

s Computer with an 10 Mbps or 10/100 Mbps Ethernet connection, or USB

connection

Actiontec DSL Modem User Manual

Chapter 1 Introduction

s Microsoft Windows 98 Second Edition (SE), Windows Millennium Edition

(Me), Windows NT 4.0, Windows 2000, Windows XP, Mac OS 7.1+, Mac OS

8.0+, Mac OS 9.0+, or Mac OS X+

☞ Note: USB LAN port is not supported with Microsoft Windows

95, Windows NT 4.0, and Mac OS.

s Internet Explorer 5.0 or higher (6.x recommended) or Netscape Navigator

4.0 or higher (4.7 recommended)

s TCP/IP network protocol installed on each computer

Features

This section contains a quick description of the Modem’s lights, ports, etc.

The Modem has several indicator lights (LEDs) on its front panel and a series of

ports on its rear panel.

Front Panel

The front panel of the Modem features five lights: Power, DSL, Internet, Ethernet,

USB, and Wireless.

Power

DSL

Internet

Ethernet

USB

Power

DSL

Internet

Ethernet

USB

Actiontec DSL Modem User Manual

Chapter 1 Introduction

Power Light

The Power Light displays the Modem’s current status. If the Power Light glows

steadily green, the Modem is receiving power and fully operational. When the

Power Light is rapidly flashing, the Modem is initializing. If the Power Light is

not illuminated when the power cord is plugged in, the Modem has suffered a

critical error and technical support should be contacted.

DSL Light

The DSL light illuminates when the Modem is connected to a DSL line.

Internet Light

When the Internet Light glows steadily, the Modem is connected to the DSL

provider. When it flashes, the Modem’s built-in DSL modem is training for

DSL service.

Ethernet Light

The Ethernet light illuminates when the Modem is connected via its Ethernet Port.

USB Light

The USB light illuminates when the Modem is connected via its USB port.

Actiontec DSL Modem User Manual

Chapter 1 Introduction

Rear Panel

The rear panel of the Modem contains five ports (Line, Phone, USB, Ethernet, and

Power), as well as a Reset switch.

Power

USB

Ethernet

Line

Reset

Phone

Line Port

Used to connect the Modem to a DSL (Digital Subscriber Line) connection.

Phone Port

Used to connect a telephone to the Modem.

USB Port

Used to connect a computer to the Modem via USB cable.

Ethernet Port

Used to connect computers to the Modem via Ethernet cable. The Ethernet port

is a 10/100 Mbps auto-sensing port, and either a straight-through or crossover

Ethernet cable can be used when connecting to the port.

Reset Switch

Depressing the reset switch for one or two seconds will power cycle (similar

to unplugging and then plugging in the Modem’s power cord) the Modem. To

restore the Modem’s factory default settings, depress and hold the Reset Switch

for approximately 10 seconds. The reset process will start about 10 seconds after

releasing the Reset Switch.

Actiontec DSL Modem User Manual

Chapter 1 Introduction

Power Port

Used to connect the Power Cord to the Modem.

N Warning: Do not unplug the power cord from the Modem dur-

ing the reset process. Doing so may result in permanent damage

to the Modem.

Technical Support

Self Help

To obtain answers to DSL configuration questions, visit the Qwest DSL Actiontec

support page at this address:

http://www.qwest.com/dsl/customerservice/Actiontecgt701-wg.html

A help page is also available on the main page of the Actiontec DSL Modem Web

interface. Enter

192.168.0.1

in the browser’s address text box, and when the first screen appears, click HELP.

Basic Setup Support

If unable to access the Internet, look at the Internet light on the front of the

DSL Modem. If the light is solid green, call the ISP immediately. If it is not solid

green, call Qwest at 1-800-247-7285.
