Abocom P3102-4g User manual
P3102-4g Wireless Broaband
VoIP Gateway Router
Description:
P3102-4g Wireless Broadband VoIP Gateway Router integrates full-featured router/firewall with Analog Terminal
Adapter (ATA) into one small platform and enables server providers to create new toll-quality voice servers to
their customers.
P3102-4g Wireless Broadband VoIP Gateway Router integrates full-featured firewall, router, and VoIP Getaway
with standard-based QoS and traffic prioritization to provide multiple traffic priority queues, which ensure voice
communication and latency/bandwidth sensitive traffic. The priority queuing mechanism enables server providers
to create new services of data, voice, and video(Triple-Play). It’s built-in firewall,. NAT, and NAPT enable business
applications with enhanced network security.
P3102-4g Wireless Broadband VoIP Gateway Router’s industry standards based DSL Forum TR-069
implementation let service providers perform OA&M of router remotely.
Standard-Based Routing:
Comprehensive routing support on features including Network
Address Translation(NAT), Network Address Port Translation
(NAPT), Dynamic Domain Name Server (DDNS) relay, Dynamic
Host Configuration Protocol(DHCP), and Point-to –Point
Protocol over Ethernet (PPPoE).
Toll-Quality Voice; Enable Triple-play
Standard-based VoIP support with QoS and traffic prioritization
to ensure toll-quality voice experience for subscribers. Enable
service providers to provide new services of data, voice, and
video( Triple-play)
Standard-Based Network Management
Support industry standard DSL Forum TR-069 with SSL)Secure
Socket Layer) and enable service providers to perform router
management tasks remotely; these includes configuration
changes performance monitoring, and firmware upgrades.
Router Features:
Routing
zDHCP client for WAN
zStatic IP option
zDHCP server for WAN
zRFC 2516 Point-to-Point Protocol over Ethernet (PPPoE)
zDNS proxy relay ; support 2 DNS entries
zDynamic DNS support
zNetwork Address Translation (NAT)
zNetwork Address Port Translation (NAPT)
zRIP v1/v2 and static route support
zVPN pass through (IPSec-ESP Tunnel mode, L2TP,PPTP)
Management
zDSL Forum TR-069 CPE WAN Management
zDSL Forum TR-064 CPE LAN Management
zWed-based Graphical User Interface
zSNMP v1/v2 support
zUPnP support
zSystem Logging
Voice Features:
VoIP Protocol
zRFC3261 Session Initiation Protocol(SIP)
zRFC2327 Session Description Protocol(SDP)
zRFC2889 Real-Time Transport Protocol (RTP)
zITU-T T.38 Fax over IP
Telephone Interface
z2 RJ-11 FXS ports for analog phone connection
Codecs /Dialing /Tone/ QoS
zITU-T G.711, G.726, G.729 support
zVolume gan control
zStatic and dynamic jitter buffer
zG.168 echo cancellation
zVoice activity detection and comfort noise generation
zSilence Threshold
zConfigurable telephone hook flash timer
zIndependent dialing plan(E.164) support
zIn-band DTMF tone generation (G.711), and out-of-band DTMF(RFC2833)
zToS and Diffserv supprt
Wireless Features
zIEEE802.11b/g Wi-Fi
zSupports up to 54Mbps
zData encryption-64/128- bit WEP/TKIP/AES-CCM/AES-OCB/802.1x, and WPA
zRadio Frequency 2.4GHz band
zModulation Type
¾DSSS –BPSK, QPSK, CCK
¾OFDM -BPSK, QPSK, 16QAM, 64QAM
zTransmit Power-13 to 17 dBm
zReceiver Sensitivity- 68 to 90 dBm
Physical Features:
Physical Interface
zOne RJ-45 Ethernet port for WAN 10/100 Mbps connection
zFour RJ-45 Ethernet ports for LAN 10/100 Mbps connection
zThree RJ-11 FXS ports for phone/fax connection
zPower Jack
zReset button
zExternal antenna
LED Indicators
zPower
zWAN connectivity/activity
zLAN connectivity/activity
zInternet IP connection
zVoIP registration status
zVoice call status
Power
zExternal power supply, Input 120/240 VAC 60Hz 25W, Output 12VDC 1000Ma
Environment
zTemperature: IEC68-2-14
z0 to 40 degrees C (Standard Operating)
z-40 to 70 degrees C(Non-condecsing)
zVibration:IEC 68-2-36, IEC68-2-6
zShock:IEC68-2-29
zDrop: IEC68-2-32
