ABB M10 Series User manual
Motor control and protection unit
M10x parameter description
2 Motor control and protection unit | M10x parameter discription
The information in this document is subject to change without notice and should not be construed as a commitment by ABB.
ABB assumes no responsibility for any errors that may appear in this document.
In no event shall ABB be liable for direct, indirect, special, incidental, or consequential damages of any nature or kind arising
from the use of this document, nor shall ABB be liable for incidental or consequential damages arising from use of any software
or hardware described in this document.
This document and parts thereof must not be reproduced or copied without ABB’s written permission, and the contents thereof
must not be imparted to a third party nor be used for any unauthorized purpose. The software described in this document is
furnished under a license and may be used, copied, or disclosed only in accordance with the terms of such license.
All rights reserved.
Copyright © 2016 ABB
M10x Parameter description | Motor control and protection unit 3
Table of contents
General
Target group
Use of warning, caution, information and tip icon
Terminology
Related documentation
Related system version
Document revision history
New features available in enchanced products
Document overview
Motor Information
Motor ID
Motor type
System supply voltage(M102 only)
System frequency
Motor power rating
Motor nominal current (N1)
Motor nominal current (N2)
Motor control
Starter ID (M10x-M only)
Starter type
Startup time
Startup time (N2) (M102 only)
Changeover time (M102 only)
Ramp up time (M102 only)
Ramp down time (M102 only)
Earth fault primary
Internal CT primary
Communication failure delay
Failsafe mode
Feedback
Feedback timeout
External CT used
External CT1 primary
External CT2 primary
External CT secondary
COMMS.
Modbus communication
PROFIBUS DP communication
Control authority
Motor control mode
Motor grouping
Function enable, disable
Group start direction
Group ID (M10x-M only)
Group number
Group start delay
Group stop delay
6
6
6
7
8
8
8
9
10
11
11
11
12
12
12
12
13
14
14
15
19
20
20
20
21
21
22
22
22
23
23
23
24
24
25
26
26
28
29
29
30
30
31
31
31
31
31
4 Motor control and protection unit | M10x parameter discription
32
32
34
35
35
36
36
37
37
38
39
40
41
44
46
46
46
46
47
47
48
49
51
52
52
53
53
54
55
55
55
56
56
57
57
58
58
58
59
60
61
61
61
62
62
63
64
64
64
65
65
Digital inputs
Function
Contact type
Operation delay
Operation
Digital outputs
Function
Start/stop delay
Operation principle
Thermal overload protection (TOL)
Function enable, disable
Thermal mode
Trip class (T6)
Trip class (Te)
Ia/In
TOL alarm level
TOL trip level
TOL reset level
Trip reset mode
TOL bypass enable/disable
Cooling coefficient (Mt6)
Ambient temperature
Staff protection
Function enable, disable
Trip level
Trip delay
Trip reset mode
Phase failure protection
Function enable, disable
Alarm level
Trip level
Trip delay
Trip reset mode
Unbalance protection
Function enable, disable
Alarm level
Trip level
Trip delay
Trip reset mode
Underload protection
Function enable, disable
Alarm level
Trip level
Trip delay
Trip reset mode
Noload protection
Function enable, disable
Alarm level
Trip level
Trip delay
Trip reset mode
M10x Parameter description | Motor control and protection unit 5
Earth fault protection
Function enable, disable
Enable earth fault protection during motor startup
Alarm level
Trip level
Trip delay
Trip reset mode
PTC protection (M102 only)
Function enable, disable
PTC alarm level
PTC trip level
PTC trip delay
PTC reset level
PTC short circuit alarm level
PTC trip reset mode
Undervoltage protection (M102 only)
Function enable, disable
Alarm level
Trip level
Trip delay
Reset level
Trip reset mode
Autorestart function (M102 only)
Function enable/disable
Maximum autoreclose time
Maximum power downtime
Staggered start delay
Start limitation protection
Function enable, disable
Time interval
Number of starts
Long start protection
Function enable, disable
Locked rotor level
Locked rotor delay
Phase sequence protection
Maintenance
Running time alam level
Start number alarm level
Diagnosis information (M10x-P) only)
User definable map (M10-M only)
User definable data (M10x-P only)
MD LED
Color
Function
MD21 display option
66
67
67
67
68
68
68
69
70
70
70
71
72
72
72
73
74
74
74
75
75
75
76
78
79
79
79
80
81
81
81
82
83
83
83
84
85
85
85
86
87
88
90
90
90
92
6 Motor control and protection unit | M10x parameter discription
General
Target group
This manual provides information on the internal parameters of M10x for the purpose of understanding, engineering, testing,
system integration or commissioning of the product.
Each chapter consists of brief explanations of the functions, the relevant parameters and the parameter descriptions, along
with ranges. Default values of all parameters are listed in appendix: Factory settings for M10x.
Examples and further explanations are provided for user reference in parameterization.
Use of warning, caution, information and tip icon
This publication includes Warning, Caution, and Information icons where appropriate to point out safety related or other important information. It also
includes Tip icons to point out useful hints to the reader. The corresponding symbols should be interpreted as follows:
The electrical warning icon indicates the presence of a hazard that could result in electrical shock.
The warning icon indicates the presence of a hazard that could result in personal injury.
The caution icon indicates important information or warnings related to the concept discussed in the text. It might indicate the
presence of hazard that could result on corruption of software or damage to equipment/property.
The information icon alerts the reader to pertinent facts and conditions.
The tip icon indicates advice on, for example, how to design your project or how to use a certain function
Although Warning notices are related to personal injury, and Caution notices are associated with equipment or property damage, it should be
understood that the operation of damaged equipment could, under certain operational conditions, result in impaired process performance leading to
personal injury or death. It is, therefore, imperative that you comply fully with all Warning and Caution notices.
M10x Parameter description | Motor control and protection unit 7
Terminology
List of terms, acronyms, abbreviations and definitions used in the document:
Abbreviation Term Description
Alarm Alarm is defined as status transition from any state to abnormal state. Status transition
to abnormal state can be data crossing over the pre-defined alarm limit.
DCS Distributed control system High level distributed control system
Hardware hardwiring A control access term describing that the M10x accepts its commands from the
hardwired inputs when the local control authority is enabled.
PCS Process control system High level process control system
PROFIBUS-DP Fieldbus communication protocol with cyclic data transfer (V0)
Modbus Fieldbus communication protocol
Modbus RTU Fieldbus communication protocol
PROFIBUS-DP/V1 Fieldbus communication protocol, extension of PROFIBUS-DP allowing acyclic data
transfer and multi master (V1)
PTC Positive temperature coefficient PTC thermistors are semiconductor elements with a very high positive temperature
coefficient.
RCU Remote control unit Local control unit with pushbutton and indicator to operate a device (eg, motor) from
field level.
Remote fieldbus A control access term describing that the M10x accepts its commands from the fieldbus
inputs when the remote control authority is enabled.
RS485 Communication interface standard from EIA (Electronics Industries Association, USA),
operating on voltages between 0V and +5V. RS-485 is more noise resistant than RS-
232C, handles data transmission over longer distances, and can drive more receivers.
STP Shielded twisted pair A type of cable commonly used for signal transmission.
TOL Thermal overload Protection against overheated caused by overload
Trip A consequence of an alarm activated or an external trip command from another device
to stop the motor or trip the circuit breaker.
MCC Motor control center Common term for a switchgear used for motor control and protection.
SOE Sequence of events A record of events with time stamp.
8 Motor control and protection unit | M10x parameter discription
Related documentation
1TNC 911112 M10x User Guide
1TNC 911507 M10x-P PROFIBUS Protocol Implementation
1TNC 911505 M10x-M Modbus Protocol Implementation
1TNC 911104 MCUSetup User Guide
Related System Version
The content of this document is related to M10x products with the following hardware and firmware version release:
HW FW
M10x-M 24VDC 2.0 3.3
M10x-M 110VAC 1.0 3.3
M10x-M 240VAC 1.0 3.3
M10x-P 24VDC 3.2 5.2
M10x-P 110VAC 1.0 5.2
M10x-P 240VAC 5.2 5.2
MD21 1.0 2.1
MD31 1.0 1.1
Until further notice, this document is also applicable for future firmware versions.
The described functions are designed but may not be fully implemented in all details. Please refer to the release notes regarding
possible restrictions.
Document revision history
Revision Description of change Date
M0201 Initial Edition 10/2003
M0202 Change Earth Fault Setting; Revise the
Terminology of Control Authority; Revise DI
Function Description
04/2008
M0203 Template Changed as per BU Guideline 10/2010
M0204 Released for M10x products with new hardware,
suitable for both M10x-M and M10x-P
01/2013
M0205 Add feedback timeout and DO function 07/2013
M0206 Add in Phase sequence protection and more DO
functions, main switch supervision function. 09/2016
M10x Parameter description | Motor control and protection unit 9
New features available in enhanced products
In comparison with previous firmware and hardware revisions:
General features
1One single type of integrated CT ranging from 0.24~63A replaces all 6 types of CTs in previous products.
2Products with options for 110VAC or 240VAC power supply and DI types are available in addition to 24VDC option.
3Additional SOE function in M102 provides event recorder data up to 256 events with time stamp.
4Products in the same categories are made with the same features and functionalities and are only different in power supply and
communication interface from each type. For example, M101's range of products has identical functionalities regardless of different types
of power supply and interfaces, such as M101-M 24VDC, M101-P 240VAC, etc.
Physical dimension
1Main unit dimension remains the same as previous revision. MDx panel is slightly larger in width and length (both 3mm extra) while cutout
dimension remains the same.
Control features
1Contactor feeder and contactor feeder/RCU are added into starter types.
2Two separate start types are available for two-speed starters. NR_2N is for two-speed motor with separate windings while NR_2N
Dahlander is for Dahlander connection motor.
3Control logic in NR_softstarter and REV_softstarter are modified slightly.
4Control authority feature in M10x-M has been revised to be identical to M10x-P.
Digital inputs and outputs
1All DIs in M10x are configurable and also selectable with NO or NC.
2E-stop, Limit 1, Limit 2, External trip input control definition has been revised.
3More features are added to DOs.
Protection
1Long start protection is available to provide stall protection during motor startup.
2Options are provided to enable or disable TOL protection during motor startup.
3PTC short circuit protection and PTC open circuit protection are available.
Communication
1Additional communication speeds are available for MODBUS: 38400 bps and 57600 bps.
Measuring and monitoring
1Additional running data are monitored, such as current phase unbalance, thermistor resistor, time to TOL trip, time to TOL reset, startup
time, DI status.
2Phase-to-phase instead of phase-to-neutral voltage is directly measured.
Maintenance
1More maintenance features are implemented, including providing number of trips, SOE with time stamp, etc.
Operator panel MDx
1MDx is provided as IP54.
2Color and function of LEDs are selectable.
3Messages on MD21 are selectable.
4Two languages are supported, ie, English and Chinese.
5Parameter setting via MD21 is available.
6Parameter setting port on MDx is mini USB connector in lieu of USB connector.
10 Motor control and protection unit | M10x parameter discription
M10x parameterization can be done from a several laptop/workstation with
MCUSetup software, or via operation panel MD21.
The motor related parameters and the protection function are set based on the
motor manufacturer’s data sheet.
M10x parameterization is mainly classified into the following functions:
Motor information
Motor control
COMMS (communication)
Control authority
Motor grouping
Digital inputs
Digital outputs
TOL protection
Stall protection
Phase failure protection
Unbalance protection
Underload protection
Noload protection
Earth fault protection
PTC protection (M102 Only)
Undervoltage protection & sutorestart (M102 only)
Start limitation protection
Long start protection
Maintenance
Diagnosis information (M10x-P only)
User defined map (M10x-M only)
User defined data (M10x-P only)
MD LED
MD Display option (MD21 only)
Functions are further subdivided into parameters, to be set individually. Above
functions and their related parameters are covered in each of the subsequent
chapters.
Document overview
Other manuals for M10 Series
1
Table of contents
Other ABB Controllers manuals
ABB
ABB PSE User manual
ABB
ABB RVC User manual
ABB
ABB ACS 800 Series User manual
ABB
ABB i-bus VC/S 4 1 Series User manual
ABB
ABB RMC-100 User manual
ABB
ABB ACH550-UH HVAC User manual
ABB
ABB AC 800F Installation and operation manual
ABB
ABB IRC5 Compact User manual
ABB
ABB TZIDC-110 How to use
ABB
ABB COMMANDER 310 User manual
ABB
ABB AC500 Series User guide
ABB
ABB i-bus KNX AA/A 2.1.2 User manual
ABB
ABB i-bus KNX FCL/S 1.6.1.1 User manual
ABB
ABB PST30 User manual
ABB
ABB ControlMaster CM10 User manual
ABB
ABB PP10 Instruction Manual
ABB
ABB C505 User manual
ABB
ABB ACS880 Series Owner's manual
ABB
ABB AC 800M User manual
ABB
ABB Relion 670 series User manual
Popular Controllers manuals by other brands
Digiplex
Digiplex DGP-848 Programming guide
YASKAWA
YASKAWA SGM series user manual
Sinope
Sinope Calypso RM3500ZB installation guide
Isimet
Isimet DLA Series Style 2 Installation, Operations, Start-up and Maintenance Instructions
LSIS
LSIS sv-ip5a user manual
Rockwell Automation
Rockwell Automation 1769-L31 installation instructions
Airflow
Airflow Uno hab Installation and operating instructions
Panasonic
Panasonic GM1 Series Reference manual
Emerson
Emerson SW93 owner's manual
AutoAqua
AutoAqua Smart ATO micro SATO-120P manual
Panasonic
Panasonic FP? Positioning Unit RTEX Technical manual
Samson
Samson Type 5824 Mounting and operating instructions
