ABB Busch-priOn Series Product manual

0073-1-7388 │Rev. 03 │01.2011

KNX Technical Reference Manual

Busch-priOn®

Pos: 2 /Produkthandbuc h - DIN-A4/Titelblätter /Titelblatt - Busch-priOn @ 9\mod_126924 2014078_15.doc @ 52250 @

Busch-priOn®

innovative and intuitive

Improved control elements. For example, the new 8.9 cm

(3.5”) TFT display as informative component of a flush-type

combination is both stylish and efficient. Its menu can be

individually adapted to every building and at all times

provides an overview of the electrical consumers. From here

the heating can be controlled, the lights dimmed or

comprehensive scenes called up that trigger numerous

preprogrammed actions. Meaningful symbols lead even the

untrained user to his objective in just a few steps. The

division of functions into individual areas such as light,

heating or blinds, assists everyone to find his way around

intuitively. Yet, this is not the end of possibilities for the

Busch-priOn® in classical building technology. The display

can also be used for controlling music.

The combination of pushbutton/rotary control element and

display has a universal operating concept. The definition of

a primary function makes its use particularly easy. The

primary function appears when one approaches the display

(a special proximity sensor is available) or when pressing

the rotary control element. In principle, any switching,

dimming, blinds, scene or sequence function that has been

stored in the unit can be defined as primary function. It is

only when the menu button is pressed that the display

changes to the circuit menu. Up to 8 entries can be

displayed via one symbol. By turning the pushbutton/rotary

control element the user can bring the desired function into

the foreground. An associated text below the focused

symbol is shown (e.g. system settings, room control office,

room control, living room, etc.). By activating the

pushbutton/rotary control element the display changes to the

respective list menu, which can consist of up to 15 different

functions. The user can scroll through these functions by

turning the pushbutton/rotary control element. The function

is selected by pressing the button.

=== Ende der Liste für Textmarke Cover ===

KNX Technical Reference Manual

Busch-priOn®

2 | 0073-1-7388 | KNX Technical Reference Manual

Pos: 4.1 /Produkthandbuc h - DIN-A4/Überschr iften/1. Ebene/S - Z/Sicherheitshinweise @ 9\ mod_1269243781484_15. doc @ 52309 @ 1

Safety instructions

Pos: 4.2 /Spezial/ Neues Layout 2010/Steuer module_Neues_Layout_ 2010/++++++++ ++++ Wechsel von ein- auf zweispa ltig ++++++++++++ @ 9\mod_1268898451593_0.doc @ 52140 @

Pos: 4.3 /Produkthandbuc h - DIN-A4/Busch-pr iOn/Sicherheitshin weise/Sicher heitshinweise @ 9\mod_12692 45364203_15.doc @ 52365 @

Work on the 230 V power supply system must

only be performed by specialist staff.

Disconnect the mains power supply prior to

mounting and/or disassembly!

Failure to observe the installation and

operating instructions may result in fire or

other hazards.

Pos: 4.4 /Produkthandbuc h - DIN-A4/Busch- priOn/Sicherheitshi nweise/Haftungsau sschluss @ 16\mod_1292 413036321_15.doc @ 97864 @

Disclaimer

The content of this printed material has been

checked for compliance with hardware and

software. However, no liability can be assumed

for any deviations that may still occur. Any

necessary corrections will be implemented in

future versions of this manual.

Please advise us of any suggestions

concerning the manual's improvement you may

have.

Pos: 4.5 /Spezial/ Neues Layout 2010/Steuer module_Neues_Layout_ 2010/++++++++ ++++ Spaltenumbruch ++ ++++++++++ @ 9\mod_12688987614 21_0.doc @ 52154 @

KNX Technical Reference Manual | 0073-1-7388 | 3

os: 4.6 /Spezial/ Neues Layout 2010/Steuer module_Neues_Layout_ 2010/++++++++ ++Wechsel zwei- auf einspal tig ++++++++++++ @ 9\mod_12 68898591406_0.doc @ 52144 @

Pos: 6.1 /Produkthandbuc h - DIN-A4/Überschr iften/1. Ebene/M - R/Maßzei chnungen @ 9\mod_12692 43888140_15.doc @ 52313 @ 1

Dimensional drawings

Pos: 6.2 /Spezial/ Neues Layout 2010/Steuer module_Neues_Layout_ 2010/++++++++ ++++ Wechsel von ein- auf zweispa ltig ++++++++++++ @ 9\mod_1268898451593_0.doc @ 52140 @

Pos: 6.3 /Produkthandbuc h - DIN-A4/Busch-pr iOn/Maßzeichnungen/ Maßzeichnungen_Be st_Nr_ABB @ 15\mod_1289220 462033_15.doc @ 96904 @

Flush-type 8,9 cm (3,5") display with control element,

Busch-priOn®

Flush-type control element, Busch-priOn®

6340-xxx-101-500

Flush-type movement detector Busch-priOn®

6345-xxx-101-500

107

Support frame for Busch-priOn® 6346/12-101-500

Flush-type rotary control element,

6341-xxx-101-500

Pos:6.4 /Spezial/NeuesLayout 2010/Steuermodule_Neues_Layout_2010/++++++++++++Wechselzwei- auf einspaltig++++++++++++ @ 9\mod_126889859140 6_0.doc @ 52144 @

Pos: 7 /Spezial/Neues Lay out 2010/Steuermodul e_Neues_Layout_201 0/+++++++++ +++ Seitenumbruch ++++++ ++++++ @ 9\mod_1268898668093_0. doc @ 52149 @

KNX Technical Reference Manual

Busch-priOn®

4 | 0073-1-7388 | KNX Technical Reference Manual

Pos: 8.1 /Produkthandbuc h - DIN-A4/Überschr iften/1. Ebene/M - R/Rah menlose Vielfalt @ 9\mod_ 1269243889687_15.doc @ 52318 @ 1

Frame-free variety

Pos: 8.2 /Produkthandbuc h - DIN-A4/Busch-pr iOn/Rahmenlose Vielfa lt/Rahmenlose Vielf alt @ 9\mod_1269245480843 _15.doc @ 52373 @

It is not merely individuality which characterises Busch-priOn® during programming of the individual buttons:

Also the assembly arrangement of the Busch-priOn®combinations are highly flexible. For Busch-priOn is not bound to

frames -- instead, up to 3 individual elements are fixed to a support frame and, at the end, provided with end strips above

and below. There are four choices of finish for the control elements: studio white, glass white, glass black and stainless

steel. Most of the end strips are also available in these colour versions. For the display (style sheets), there are three

choices: black, blue and silver.

Modular design

End strips

These not only have a beautiful shape -- they optionally

contain a temperature sensor for room temperature

control, an infrared interface for the remote control and

a proximity sensor for activating the display or LED of

the control elements when somebody approaches. This

IR / proximity sensor version is only available in glass

black and not in the other colours. Additional

information about controlling the room temperature with

Busch-priOn® is contained in the brochure on heating,

ventilation and air conditioning.

Pos: 9 /Spezial/Neues Lay out 2010/Steuermodul e_Neues_Layout_201 0/+++++++++ +++ Seitenumbruch ++++++ ++++++ @ 9\mod_1268898668093_0. doc @ 52149 @

KNX Technical Reference Manual | 0073-1-7388 | 5

Pos: 10.1 /Produkthandb uch - DIN-A4/Überschr iften/1. Ebene/G - L/ Kombinationen nach Wunsc h @ 9\mod_1269243898187_1 5.doc @ 52323 @ 1

Combinations as desired

Pos: 10.2 /Produkthandb uch - DIN-A4/Busc h-priOn/Kombinationen nac h Wunsch/Kombinatio nen nach Wunsch_Best_Nr_A BB @ 11\mod_127962987 3579_15.doc @ 84942 @

The control elements and end strips can be freely combined for Busch-priOn®with regard to colour and function. Up to 3-

gang combinations are possible, whereby a single bus coupler will suffice.

Support frameArticle number

1-gang 2-gang 3-gang

Top end strip, IR / proximity sensor 6350-825-101-500 ●●●

Top end strip with display, IR / proximity sensor RTC 6351-825-101-500 ●●●

Top end strip, standard 6348-101-500 ●●●

1-gang control element 6340-101-500 ●●●

3-gang control element 6342-101-500 ●●●

Rotary control element 6341-101-500 ●●●

Movement detector 6345-101-500 ●●●

8.9 cm display including control element 6344-101-500 - ●●

Bottom end strip, temperature 6352-101-500 ●●●

Bottom end strip, standard 6349-101-500 ●●●

Bus coupler 6120/12-500 ●- -

Power bus coupler and additional power supply, MDRC 6120/13-500 +

CP-D 2472.5 ●●●

Flush-type switch actuator 6354-500 - ●●

Flush-type dimming actuator, 1-gang 6355-500 - ●●

Flush-type blind / 2-gang actuator 6356-500 - ●●

Pos: 11 /Spezial/Neues Lay out 2010/Steuermodu le_Neues_Layout_20 10/++++++++++ ++ Seitenumbruch ++++++ ++++++ @ 9\mod_1268898668093_0. doc @ 52149 @

KNX Technical Reference Manual

Busch-priOn®

6 | 0073-1-7388 | KNX Technical Reference Manual

Pos: 12.1 /Produkthandb uch - DIN-A4/Übersc hriften/1. Ebene/G - L/ Kein gewöhnliches KNX-Bedi enelement @ 9\mod_1269 243899796_15.doc @ 52328 @ 1

Not just any KNX control element

Pos: 12.2 /Produkthandb uch - DIN-A4/Busc h-priOn/Kein gewöhnlic hes KNX-Bedienelement/ Kein gewöhnliches KNX- Bedienelement - Text @ 9\mod_1269426042218_15. doc @ 52740 @

Each of the buttons of the Busch-priOn® can be programmed individually, as is usually the case with KNX. The applications

range from switching, dimming and blinds on through to scenes. Logic functions are also possible. The use of the display

makes additional functions available. Weekly timers, messages and multimedia applications can be integrated here, for

example. Also additional applications can be implemented with the assigning of internal group addresses. The user menu

can be configured in 19 languages.

Pos: 12.3 /Produkthandb uch - DIN-A4/Busc h-priOn/Kein gewöhnlic hes KNX-Bedienelement/ Kein gewöhnliches KNX-B edienelement - Tab elle - Applikationen @ 15\ mod_1289221025466_15. doc @ 96936 @

Applications

Application Control element Rotary control

element

8,9 cm (3,5") TFT display

with control element

Movement

detector

Page number

Switching, rocker total ●- - - Page 21

Switching, rocker left/right ●- ●- Page 21

Dimming, rocker total ●- - - Page 21

Dimming, rocker left/right ●●●- Page 22

Blind, rocker total ●- - - Page 22

Blind, rocker left/right ●●●- Page 22

Value sender, rocker total ●- - - Page 23

Value sender, rocker left/right ●●●- Page 23

Value sender, 2 objects, rocker left/right ●- - - Page 24

Value dimming sensor, rocker total ●- ●- Page 24

Light scene extension unit with memory

function

●- ●- Page 25

Level switch, rocker total ●- - - Page 25

Level switch, rocker left/right ●- - - Page 26

Multiple actuation, rocker left/right ●- - - Page 26

Short/long operation, rocker left/right ●- - - Page 28

Setting RTC operation mode ●- ●- Page 28

Media control, CD player - - ●- Page 29

Media control, radio - - ●- Page 30

Media control, video player - - ●- Page 31

Short-time timer - - ●- Page 31

Weekly timer - - ●- Page 32

Alarm clock - - ●- Page 33

Messages - - ●- Page 34

Title text - - ●- Page 34

Unit blockage - - ●- Page 35

RTC settings - - ●1- Page 35

Sequence actuator settings - - ●- Page 35

Venetian blind application ●●●2- Page 36

Switch actuator application ●●●- Page 36

Movement detector - - - ●Page 37

LED functionality ●●●- Page 39

Alarm function ●●- - Page 39

Storage function Light scenes ●●●- Page 39

1 Only in connection with a bottom end strip "temperature sensor" or another external sensor. Busch- priOn®has 1 internal room thermostat.

2 Only in connection with flush-type blind / 2-gang actuator 6356.

Pos: 12.4 /Spezial/ Neues Layout 2010/Steuer module_Neues_Layout _2010/++++++ ++++++ Seitenumbruch ++++ ++++++++ @ 9\mod_12688986680 93_0.doc @ 52149 @

KNX Technical Reference Manual | 0073-1-7388 | 7

Pos: 12.5 /Produkthandb uch - DIN-A4/Busc h-priOn/Kein gewöhnlic hes KNX-Bedienelement/ Kein gewöhnliches KNX-Be dienelement - Tab elle - Allg. Funktionen @ 15\m od_1289904254518_15.d oc @ 97280 @

General functions

Function Large-area control

element

Rotary control

element

8,9 cm (3,5") TFT display

with control element

Movement

detector

Page number

Delay ●●●●Page 40

Staircase lighting ●●●●Page 41

Light scene actuator settings ●●●●Page 42

Sequence ●●●●Page 42

Preset ●●●●Page 43

Cyclic telegram ●●●●Page 43

Flahing ●●●●Page 44

Logic ●●●●Page 44

Gate ●●●●Page 45

Min/Max value transducer ●●●●Page 46

Threshold value / hysteresis ●●●●Page 47

PWM inverter ●●●●Page 47

Priority ●●●●Page 47

Pos: 12.6 /Produkthandb uch - DIN-A4/Busc h-priOn/Kein gewöhnlic hes KNX-Bedienelement/ Kein gewöhnliches KNX-Be dienelement - Abbildun g 1/2fach @ 15\mod_12892 23461875_15.doc @ 96952 @

Busch-priOn®

Rotary control element

Glass black

Busch-priOn®

3-gang control element

Glass black

Busch-priOn®

1-gang control element

Glass black

Busch-priOn®

2-gang combination

Glass black

Busch-priOn®Watchdog 180 flush-mounted,

glass black

Busch-priOn®is ideally combinable with

the carat®switch series. These switches

distinguish themselves through their

uniformly designed surfaces.

Pos: 13 /Spezial/Neues Lay out 2010/Steuermodu le_Neues_Layout_20 10/++++++++++ ++ Seitenumbruch ++++++ ++++++ @ 9\mod_1268898668093_0. doc @ 52149 @

KNX Technical Reference Manual

Busch-priOn®

8 | 0073-1-7388 | KNX Technical Reference Manual

Pos: 14.1 /Produkthandb uch - DIN-A4/Überschr iften/1. Ebene/A - F/Der richtige Ankoppler @ 9\ mod_1269243900921_15. doc @ 52333 @ 1

The right bus coupler

Pos: 14.2 /Spezial/ Neues Layout 2010/Steuer module_Neues_Layout _2010/++++++ ++++++ Wechsel von ein- auf zweispa ltig ++++++++++ ++ @ 9\mod_1268898451593 _0.doc @ 52140 @

Pos: 14.3 /Produkthandbuch - DIN-A4/Busch-priOn/Der richtige Ankoppler/Der ric htigeAnkoppler - Tabelle+Text _Best_Nr_ABB@ 16\ mod_1291294382201_15.doc @ 97635 @

Maximum number of Busch-priOn®devices per TP line

Number of

display

combinations per

line

Total number of

combinations 1

Total number of TP-

Power bus couplers

6120/13 per line

0 0 + 60 60

1 1 + 59 60

2 2 + 58 60

3 3 + 57 60

4 4 + 56 60

5 5 + 55 60

6 6 + 54 60

7 7 + 53 60

8 8 + 52 60

9 9 + 51 60

10 10 + 45 55

11 11 + 37 48

12 12 + 30 42

13 13 + 22 35

14 14 + 15 29

15 15 + 7 22

16 16 + 0 16

1 Composed of display combinations plus 1- to 3-gang combinations without

display with end strips

Only one bus coupler is mounted behind every Busch-

priOn®combination. One standard bus coupler is adequate

for one 1-gang support frame. With the use of the 2-gang

carrier frame the more powerful power bus coupler must be

used.

The twisted pair version requires an external power pack for

this purpose. The table to the left describes the

corresponding device combinations.

Pos:14.4 /Spezial/NeuesLayout 2010/Steuermodule_Neues_Layout_2010/++++++++++++W echselzwei- aufeinspaltig ++++++++++++@ 9\mod_126889859140 6_0.doc @ 52144 @

Pos: 14.5 /Produkthandb uch - DIN-A4/Busc h-priOn/Der richti ge Ankoppler/Der richti ge Ankoppler - Abbildung_ABB _ABB-STOTZ @ 16\mod_129 1294546873_15.doc @ 97651 @

Standard bus coupler, TP

STN1 STN2 STN32

Power coupler, TP

Power supply KNX

STN1

STN2

STN64

24 V DC power supply

For the number of device

combinations see the table

above

Pos: 15 /Spezial/Neues Lay out 2010/Steuermodu le_Neues_Layout_20 10/++++++++++ ++ Seitenumbruch ++++++ ++++++ @ 9\mod_1268898668093_0. doc @ 52149 @

KNX Technical Reference Manual | 0073-1-7388 | 9

Pos: 16.1 /Produkthandb uch - DIN-A4/Überschr iften/1. Ebene/A - F/Einfache Montage @ 9\mod_12692 43901843_15.doc @ 52338 @ 1

Easy to mount

Pos: 16.2 /Produkthandb uch - DIN-A4/Busc h-priOn/Einfache Montage/ Einfache Montage - Te xt@ 10\ mod_1272614580478 _15.doc @ 53803 @

The carrier frame serves to hold and make contact with the individual control elements, the 8.9 cm (3,5”) TFT display, the

end strips and the flush-type bus coupler. The position of the control elements can be selected freely for multiple

combinations. A special strip must be mounted on top as well as below. Its material can be different to that of the module.

The support frame is mounted by screwing it to the flush-type bus coupler and, for multiple combinations, also to the wall.

Thanks to the anti-fingerprint surface, the stainless steel Busch-priOn® is easy to keep clean and maintains its sophisticated

surface finish even when it is in use. Glass surfaces and end strips match the carat® series.

Pos: 16.3 /Produkthandb uch - DIN-A4/Busc h-priOn/Einfache Montage/ Einfache Montage - Abbi ldung 3fach @ 9\mod_126924 5658421_15.doc @ 52398 @

Busch-priOn®

Glass black

Busch-priOn®

Studio white

Busch-priOn®

Stainless steel

Busch-priOn®

Glass white

Pos: 17 /Spezial/Neues Lay out 2010/Steuermodu le_Neues_Layout_20 10/++++++++++ ++ Seitenumbruch ++++++ ++++++ @ 9\mod_1268898668093_0. doc @ 52149 @

KNX Technical Reference Manual

Busch-priOn®

10 | 0073-1-7388 | KNX Technical Reference Manual

Pos: 18.1 /Produkthandb uch - DIN-A4/Überschri ften/1. Ebene/M - R/Raumtempera turregler @ 13\mod_1286 268674432_15.doc @ 91479 @ 11

Room thermostat

Pos: 18.2 /Produkthandbuc h- DI N-A4/Überschriften/2. Ebene/P - R/Raumte mperaturregler-Di splay @13\ mod_1286269387786_15.doc @ 91504 @ 2

Room thermostat with display

Pos: 18.3 /Produkthandb uch - DIN-A4/Überschr iften/3. Ebene/Sta ndardansicht @ 13\mod_12 86269449786_15.doc @ 91512 @ 2222

Standard view

Pos: 18.4 /Spezial/ Neues Layout 2010/Steuer module_Neues_Layout _2010/++++++ ++++++ Wechsel von ein- auf zweispa ltig ++++++++++ ++ @ 9\mod_1268898451593_0. doc @ 52140 @ 3

Pos: 18.5 /Produkthandb uch - DIN-A4/Busch-tr iton/Raumtemperaturr egler/Standardansi cht @ 13\mod_1286269136131_1 5.doc @ 91487 @ 2

Operating state Operating mode

Actual or setpoint temperature

The display of the room thermostat shows either the current

room temperature or the setpoint for the temperature,

depending on the parameterization.

The current operating state is shown in the left area of the

display and the current operating mode in the right area.

Pos:18.6 /Spezial/NeuesLayout 2010/Steuermodule_Neues_Layout_2010/++++++++++++W echselzwei- aufeinspaltig ++++++++++++@ 9\mod_126889859140 6_0.doc @ 52144 @

Pos: 18.7 /Produkthandb uch - DIN-A4/Überschr iften/3. Ebene/Sol lwerte @ 13\mod_128626949 2130_15.doc @ 91520 @ 22

Set values

Pos: 18.8 /Spezial/ Neues Layout 2010/Steuer module_Neues_Layout _2010/++++++ ++++++ Wechsel von ein- auf zweispa ltig ++++++++++ ++ @ 9\mod_1268898451593_0. doc @ 52140 @ 3

Pos: 18.9 /Produkthandb uch - DIN-A4/Busc h-triton/Raumtemperatur regler/Sollwert e @ 13\mod_1286269283224_ 15.doc @ 91495 @

Heating setpoint Cooling setpoint

{Temperature - {Temperature +

zNext setpoint zPrevious setpoint

{Comfort/Standby {FanCoil-Steps

zOn/Off

{Short press zLong press

In the setting level, which is accessed by pressing the

additional key once, the setpoints for heating and/or cooling

can be adjusted.

The corresponding setpoints are located to the right of each

respective symbol for heating or cooling.

The value brightly highlighted can be changed.

The adjustment is made with the upper rocker of the control

element. A short press of the left side lowers the setpoint, a

short press of the right side raises the setpoint. With a long

press of the button the selection jumps to the next setpoint.

This one can now also be adjusted with a short press of the

button.

After an adjustable time, the display returns to the standard

view.

Pos: 18.10 /Spezial/ Neues Layout 2010/Steuer module_Neues_Layou t_2010/++++++++++++ Wechselzwei- auf einspaltig ++++++++++++ @ 9\mod_1268898591406_0.doc @ 52144 @ 2

Pos: 18.11 /Spezia l/Neues Layout 201 0/Steuermodule_ Neues_Layout_2010/ +++++++++++ + Seitenumbruch ++ ++++++++++ @ 9\mod_1 268898668093_0.doc @ 52149 @
