ZyXEL Communications N220

Ultra-compact Wireless N-lite USB Adapter

Easily Upgrades Wireless Connection

Benefits

Ultra-compact design for optimal portability

The compact, lightweight design of N220 offers excellent portability.Users can easily plug N220 to a USB

connector on desktop or laptop computers to upgrade the network speed instantly.In addition, the

bundled USB cable makes it convenient for users to adjust the direction of N220.

Latest 802.11n compliance with data transfer rates of up to 150 Mbps*

The N220 brings you faster wireless connection than the existing 802.11g standard.With the data transfer

rate of up to 150 Mbps*, which is three times faster than the 802.11g standard, the N220 offers you the

high-speed connection everywhere under Wi-Fi coverage. It not only provides a high-speed network

capability, but also works with your existing 802.11b/g network.

Soft AP mode creates a wireless network

With the built-in soft AP function, the N220 can help users to create wireless networks instantly. Just plug

N220 into a desktop or laptop computer connecting to a cable or xDSL modem, all other wireless-capable

devices can connect to the Internet through N220.

Support multiple applications with WMM QoS

With WMM QoS certification, the N220 is an excellent solution for you to deliver time-sensitive applications

such as video and voice streaming. It significantly enhances your experience on audio, video and voice

applications by prioritizing data traffic,so you can enjoy and share multimedia contents with your family or

friends without interruption.

■

Ultra-compact design for optimal portability

■

Latest 802.11n compliance with data transfer rates of up to 150 Mbps*

■

Support soft AP mode

■

Support multiple applications with WMM QoS

■

One-touch WPS button for easy wireless security setup

N220

Wireless N-lite

USB Adapter

N220

Wireless N-lite

USB Adapter

For more product information, visit us on the web at www.ZyXEL.com

All other brands, product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.

One-touch WPS button for easy wireless security setup

Establishing a secure wireless network is no longer a hassle.The WPS (Wi-Fi Protected Setup) feature takes just a few seconds to set up a secure wireless

network without complicated procedures. A click on the WPS button is all it needs to set up a secure wireless network easily.

N220

Wireless N-lite USB Adapter

N220

Wireless N-lite USB Adapter

System Specifications

• Compliant with 802.11n standard

• Backwards compatible with 802.11b/g

• Wireless data transfer rate:

- Transmit: 150 Mbps*

- Receive: 150 Mbps*

• Wi-Fi Multimedia (WMM) Support

• Wireless security:

- WEP,WPA (WPA-PSK),WPA2 (WPA2-PSK), 802.1x

- WPS hardware button,WPS software feature

• Soft AP mode support

Hardware Specifications

• Operation voltage: DC 5 V

• 1 WPS button with Link/Act LED

• 1 USB 1.1/2.0 port

• Power consumption:

- Transmit: 300 mA

- Receive: 160 mA

Physical Specifications

• Item weight: 3 g (0.01 lb)

• Item dimensions:

36 (W) x 18 (D) x 6 (H) mm

(1.42 (W) x 0.71 (D) x 0.24 (H) inch)

• Packing weight: 167 g (0.37 lb)

• Packing dimensions:

172 (W) x 140 (D) x 44 (H) mm

(6.77 (W) x 5.51 (D) x 1.73 (H) inch)

Environmental Specifications

• Operating environment:

- Temperature: 0ºC ~ 50ºC/32ºF ~ 122ºF

- Humidity: 20% ~ 90% (non-condensing)

• Storage environment:

- Temperature: -30ºC ~ 70ºC/-22ºF ~ 158ºF

- Humidity: 10% ~ 90% (non-condensing)

Certifications

• FCC/CE/IC/NCC/C-Tick

• Wi-Fi 11b/g/n,WMM,WPS

• WHQL for Windows XP/Vista/7

OS Support

• Microsoft Windows 2000, XP, Vista and 7

(32 bit/64 bit)

• MAC OS X v10.3, v10.4, and v10.5

Package Contents

• Wireless USB Adapter

• Support CD

• Quick start guide

• USB extension cable

• Warranty card

* The theoretical maximum data transfer rate is 150 Mbps.The actual

data transfer rate may vary depending on the network

environment.

Specifications

Application Diagram

Internet

xDSL/Cable

Modem

N220

Wireless N-lite

USB Adapter

N220

Wireless N-lite

USB Adapter

NBG-419N

Wireless N Router
