Xerox Phaser 5500 series Instruction Manual

Phaser® 5500 Laser Printer

2-43

2-Sided Printing

This topic includes:

■"Automatic 2-Sided Printing" on page 2-43

■"Binding Preferences" on page 2-44

Automatic 2-Sided Printing

Guidelines

■A duplex unit must be installed on your printer to perform automatic 2-sided printing. The

Phaser 5500B and 5500N configurations may be upgraded to include this feature.

■The paper size must be at least 89 x 127 mm (3.5 x 5 in.) when printing from Tray 1. All

sizes that fit Trays 2-6 may be printed 2-sided.

■The paper must have a weight of 60–163 g/m2(16–43 lb. Bond).

■Manual duplexing is supported. For more information on supported paper, go to

Reference/Printing/Supported Papers on the User Documentation CD-ROM.

Note

You can find additional information on 2-sided printing at www.xerox.com/office/

5500infosmart.

2-Sided Printing

Phaser® 5500 Laser Printer

2-44

Binding Preferences

Use the printer driver to select Portrait or Landscape orientation for the images on the page.

When you print 2-sided jobs, select the binding preference which determines how the pages

turn.

To perform automatic 2-sided printing:

1. Insert paper into the tray. For more information, go to Reference/Printing/Basic Printing

on the User Documentation CD-ROM.

2. In the printer driver:

■Select either Portrait or Landscape orientation.

■Select 2-sided printing, including binding, as described in the table below.

3. Click OK to accept the printer driver settings, then click OK to print.

Portrait

Bind on Side Edge

Flip on Long Edge

Portrait

Bind on Top Edge

Flip on Short Edge

Landscape

Bind on Side Edge

Flip on Short Edge

Landscape

Bind on Top Edge

Flip on Long Edge

Setting the Printer Driver for 2-Sided Printing

Operating System Steps

Windows 98 or

Windows Me

1. Select File, then select Print.

2. Click Properties.

3. On the Setup tab, then select Print on 1 Side or Print on 2 Sides.

4. Select or deselect Bind On Top Edge.

Windows 2000,

Windows XP, or

Windows Server 2003

1. Select File, then select Print.

2. Click Properties.

3. On the Layout tab in Print On Both Sides (Duplex), select Flip on

Long Edge or Flip on Short Edge.

Windows NT 1. Select File, then select Print.

2. Click Properties.

3. On the Page Setup tab in Print On Both Sides (Duplex), select Flip

on Long Edge or Flip on Short Edge.

Mac OS 9 1. Select File, then select Print.

2. Select Layout.

3. Select Print on Both Sides.

4. Click the Binding icon that matches the edge to bind.

2-Sided Printing

Phaser® 5500 Laser Printer

2-45

Mac OS X (version

10.1 and higher)

1. Select File, then select Print.

2. Select Duplex.

3. Select Print on Both Sides.

4. Click the Binding icon that matches the edge to bind.

Setting the Printer Driver for 2-Sided Printing (Continued)

Operating System Steps
