Winmate W07FA3S-PCO1AC-POE Troubleshooting guide
- 2 -
CONTENTS
INTRODUCTION - 8 -
Features - 8 -
Package Contents - 9 -
Product Overview - 11 -
INSTALLATION - 12 -
Wiring Requirements - 12 -
Connecting to Other Devices - 13 -
GETTING STARTED - 16 -
Turning On Your Device - 16 -
Turning Off Your Device - 17 -
OPERATING THE DEVICE - 18 -
Start Menu - 18 -
Linux Terminal - 19 -
System Information - 20 -
Brightness Adjustment - 21 -
Ethernet Settings - 22 -
Changing Serial Port Settings - 25 -
Exit the System - 26 -
MOUNTING - 27 -
Panel Mounting - 27 -
VESA Mounting - 28 -
SPECIFICATIONS - 32 -
APPENDIX - 35 -
Appendix A: Cleaning the Monitor - 35 -
Appendix B: Winmate Software Development Kit - 36 -
Appendix C: Ubuntu Command Code - 37 -
- 3 -
FCC Statement
This device complies with part 15 FCC rules.
Operation is subject to the following two
conditions:
This device may not cause harmful
interference.
This device must accept any interference
received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the
limits for a class "B" digital device, pursuant to part 15 of the FCC
rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at him
own expense.
- 4 -
European Union
Electromagnetic Compatibility Directive
(2014/30/EU)
EN55024: 2010/ A1: 2015
oIEC61000-4-2: 2009
oIEC61000-4-3: 2006+A1: 2007+A2: 2010
oIEC61000-4-4: 2012
oIEC61000-4-5: 2014
oIEC61000-4-6: 2014
oIEC61000-4-8: 2010
oIEC61000-4-11: 2004
EN55032: 2012/AC:2013
EN61000-3-2:2014
EN61000-3-3:2013
Low Voltage Directive (2014/35/EU)
EN 60950-1:2006/A11:2009/A1:2010/A12:2011/
A2:2013
This equipment is in conformity with the requirement of the
following EU legislations and harmonized standards. Product also
complies with the Council directions.
- 5 -
Copyright Notice
No part of this document may be reproduced, copied, translated, or
transmitted in any form or by any means, electronic or mechanical, for
any purpose, without the prior written permission of the original
manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of
their respective owners.
Disclaimer
Winmate Inc. reserve the right to make changes, without notice, to
any product, including circuits and/or software described or contained
in this manual in order to improve design and/or performance. We
assume no responsibility or liability for the use of the described
product(s) conveys no license or title under any patent, copyright, or
masks work rights to these products, and make no representations or
warranties that these products are free from patent, copyright, or
mask work right infringement, unless otherwise specified. Applications
that are described in this manual are for illustration purposes only. We
make no representation or guarantee that such application will be
suitable for the specified use without further testing or modification.
Warranty
Winmate Inc. warranty guarantees that each of its products will be
free from material and workmanship defects for a period of one year
from the invoice date. If the customer discovers a defect, we will, at
his/her option, repair or replace the defective product at no charge to
the customer, provide it is returned during the warranty period of one
year, with transportation charges prepaid. The returned product must
be properly packaged in its original packaging to obtain warranty
service. If the serial number and the product shipping data differ by
over 30 days, the in-warranty service will be made according to the
shipping date. In the serial numbers the third and fourth two digits
give the year of manufacture, and the fifth digit means the month (e.
g., with A for October, B for November and C for December).
For example, the serial number 1W16Axxxxxxxx means October of
year 2016.
- 6 -
Customer Service
We provide a service guide for any problem by the following steps:
First, visit the website of our distributor to find the update information
about the product. Second, contact with your distributor, sales
representative, or our customer service center for technical support if
you need additional assistance.
You may need the following information ready before you call:
Product serial number
Software (OS, version, application software, etc.)
Description of complete problem
The exact wording of any error messages
In addition, free technical support is available from our engineers
every business day. We are always ready to give advice on
application requirements or specific information on the installation and
operation of any of our products.
- 7 -
Safety Information
WARNING! / AVERTISSEMENT!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden
power surges. Only experienced electronics personnel
should open the PC chassis.
Toujours débrancher le cordon d’alimentation du chassis
lorsque vous travaillez sur celui-ci. Ne pas brancher de
connections lorsque l’alimentation est présente. Des
composantes électroniques sensibles peuvent être
endommagées par des sauts d’alimentation. Seulement
du personnel expérimenté devrait ouvrir ces chassis.
CAUTION/ATTENTION
Always ground yourself to remove any static charge
before touching the CPU card. Modern electronic devices
are very sensitive to static electric charges. As a safety
precaution, use a grounding wrist strap at all times. Place
all electronic components in a static-dissipative surface
or static-shielded bag when they are not in the chassis.
Toujours verifier votre mise à la terre afin d’éliminer toute
charge statique avant de toucher la carte CPU. Les
équipements électroniques moderns sont très sensibles
aux décharges d’électricité statique. Toujours utiliser un
bracelet de mise à la terre comme précaution. Placer
toutes les composantes électroniques sur une surface
conçue pour dissiper les charge, ou dans un sac anti-
statique lorsqu’elles ne sont pas dans le chassis.
- 8 -
INTRODUCTION
Congratulations on purchasing Winmate® 7” S-Series HMI.
Interactive and smart automation systems of intelligent buildings are
in a fast growing phase. Winmate® multi-touch S-Series HMI is
suitable for home automation and room management systems.
Flat surface is easy-to-clean and delivers aesthetically pleasing look
for any interior. By connecting to centralized database, it can provide
real time update for booking status and available schedule, or
perform as a synchronous display in meetings.
Winmate® 7” S-Series HMI powered by Freescale® Cortex A9 i.MX6
Dual Core processor and support Ubuntu 16.04 operating systems.
The HMI device features P-Cap touch-screen. In addition, the HMI
device model supports an exceptional feature - LED Light Bar. With
the help of red, green, blue and orange LED indicators you can see
the status of the machine or processes afar. It significantly reduces
power consumption by keeping the display turned off.
Features
Winmate® 7” S-Series HMI features:
7”, 1024 x 600 with P-CAP multi-touch
Freescale® Cortex A9 i.MX6 Dual Core 1 GHz (Optional Quad
Core)
Fanless cooling system and ultra-low power consumption
Front IP65 water and dust proof, rear IP22
Dual Gigabit Ethernet
RGB LED status light bar
Optional 2MP front camera
Stylish design for room booking, access control and room
information applications
- 9 -
Package Contents
Carefully remove the box and unpack your device. Please check if all
the items listed below are inside your package. If any of these items
are missing or damaged contact us immediately.
Standard factory shipment list:
7” HMI Device
Quick Start Guide
(Hardcopy)
Driver CD & User
Manual
Varies by product
specifications
Varies by product
specifications
9171111I103L
AC Adapter
(12V/ 50W)
Power Cord
2 Pin Terminal
Block
922D050W12VA
Varies by country
94J602G020K0
VESA Mount
Screws
VESA Plate
75 x 75 mm
External USB A
Type to Micro USB
Cable
913511101145
82W70J17Y700
9487049050K0
- 10 -
Package may include optional accessories based on your order:
VESA Desk Stand
PCVS-V1
VESA Desk Stand
LA-100
VESA Wall Mount
Bracket
LA-106
99KK00A0000E
9B0000000128
9B0000000412
