Whirlpool LSR6132HQ0 User manual

3950317 www.whirlpool.com

ONE SPEED

AUTOMATIC

WASHERS

Use & Care Guide

Table of Contents..............................2

TABLE OF

CONTENTS

WASHER SAFETY............................................................... 3

PARTS AND FEATURES .................................................... 4

USING YOUR WASHER...................................................... 5

Understanding Washer Cycles........................................ 5

Loading............................................................................. 6

Normal Washer Sounds................................................... 6

Starting Your Washer....................................................... 7

Selecting a Cycle and Time............................................. 8

Rinse and Spin ................................................................. 9

Drain and Spin.................................................................. 9

CARING FOR YOUR WASHER.......................................... 9

Cleaning Your Washer..................................................... 9

Self-cleaning Lint Filter.................................................... 9

Water Inlet Hoses............................................................. 9

Vacation, Storage, and Moving Care............................ 10

TROUBLESHOOTING....................................................... 11

ASSISTANCE OR SERVICE ............................................. 14

In the U.S.A..................................................................... 14

In Canada........................................................................ 14

WARRANTY....................................................................... 16

WASHER SAFETY

You will be killed or seriously injured if you don't

follow instructions.

You can be killed or seriously injured if you don't

follow instructions.

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can

happen if the instructions are not followed.

Your safety and the safety of others is very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all

safety messages.

This is the safety alert symbol.

This symbol alerts you to hazards that can kill or hurt you and others.

All safety messages will be preceded by the safety alert symbol and the word “DANGER” or

“WARNING.” These words mean:

DANGER

WARNING

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

• Read all instructions before using the washer.

• Do not wash articles that have been previously

cleaned in, washed in, soaked in, or spotted with

gasoline, dry-cleaning solvents, other flammable,

or explosive substances as they give off vapors

that could ignite or explode.

• Do not add gasoline, dry-cleaning solvents, or

other flammable, or explosive substances to the

wash water. These substances give off vapors

that could ignite or explode.

• Under certain conditions, hydrogen gas may be

produced in a hot water system that has not been

used for 2 weeks or more. HYDROGEN GAS IS

EXPLOSIVE. If the hot water system has not

been used for such a period, before using the

washing machine, turn on all hot water faucets

and let the water flow from each for several

minutes. This will release any accumulated

hydrogen gas. As the gas is flammable, do not

smoke or use an open flame during this time.

• Do not allow children to play on or in the washer. Close

supervision of children is necessary when the washer

is used near children.

• Before the washer is removed from service or

• Do not reach into the washer if the tub or agitator is

moving.

• Do not install or store the washer where it will be

exposed to the weather.

• Do not tamper with controls.

• Do not repair or replace any part of the washer or

attempt any servicing unless specifically recommended

in this Use and Care Guide or in published user-repair

instructions that you understand and have the skills to

carry out.

• See Installation Instructions for grounding

requirements.

WARNING:

To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic

precautions, including the following:

discarded,

remove the lid.

PARTS AND FEATURES

This manual covers several different models. The washer you have purchased may have some or all of the parts and

features listed below.

1. Control panel

2. Model and serial number label

3. Agitator

4. Lid

5. Basket

6. Tub

Other features your washer may have:

Liquid chlorine bleach dispenser

MAGIC CLEAN* lint filter

XTRA ROLL ACTION* agitator

Control panel

USING YOUR

WASHER

UnderstandingWasherCycles

When the Cycle Control knob is set to a number and pulled

out, the washer fills (to the selected load size) before

agitation and timing start. The washer begins agitating

immediately after filling; agitation occurs with the washer

lid up or down.

During agitation, the agitator (on some models) creates a

continuous rollover action that provides a thorough

cleaning of the wash load.

After agitation starts, the Cycle Control knob turns

clockwise until it points to an OFF area and the cycle ends.

NOTE: The washer pauses briefly throughout each cycle.

These pauses are normal for washer operation.

WASH RINSE

1. Fill 1. Fill

2. Wash

selected

time

2. Rinse

3. Drain†

No agitation 3. Drain

No agitation

4. Spin 4. Spin-Spray

rinse

5. Spin

†The Permanent Press

cycle partially drains, fills,

agitates briefly, and

drains.

6. Off

Loading suggestions

For these suggested full-sized loads, set the LOAD SIZE

selector to the highest load size setting.

NormalWasher Sounds

Your new washer may make sounds your old one didn’t.

Because the sounds might be unfamiliar, you may be

concerned about them. These sounds are normal.

During washing

When you select a smallload size setting, your washer has

a lower water level. This can cause a clicking sound from

the upper part of the agitator.

During drain

If water is drained quickly from your washer (depending on

your installation), you may hear air being pulled through

the pump during the end of draining.

After drain and before spin

When the cycle changes from draining to spinning, you

may hear gears engaging.

SUPER CAPACITY WASHERS

Heavy Work Clothes

3 pair pants

3 shirts

4 pair jeans

1 coverall

1 overall

Delicates

3 camisoles

1 quilted robe

4 slips

4 panties

2 bras

2 nighties

1 baby’s dress

Towels

10 bath towels

10 hand towels 14 wash cloths

1 bath mat

Mixed Load

3 double sheets

4 pillowcases

8 T-shirts

6 pair shorts

2 shirts

2 blouses

8 handkerchiefs

EXTRA LARGE CAPACITY WASHERS

Heavy Work Clothes

2 pair pants

3 shirts

3 pair jeans

1 coverall

Delicates

3 camisoles

4 slips

4 panties

2 bras

2 nighties

Towels

8 bath towels

8 hand towels 10 wash cloths

1 bath mat

Mixed Load

2 double sheets or

1 king size sheet

4 pillowcases

6 T-shirts

6 pair shorts

2 shirts

2 blouses

6 handkerchiefs

Starting Your Washer

1. Measure detergent and pour it into the washer. If

desired, add powdered or liquid color-safe bleach.

2. Drop a sorted load of clothes loosely into your washer.

■Load evenly to maintain washer balance. Mix large

and small items.

■Items should move easily through the wash water.

Overloading can cause poor cleaning.

■To reduce wrinkling of permanent press clothes and

some synthetic knits, use a large load size to provide

more space (see step 5).

3. (OPTIONAL STEP) Pour measured liquid chlorine

bleach into the liquid chlorine bleach dispenser (on

some models). Bleach will be diluted automatically

during the wash part of the cycle.

■Never use more than 1 cup (250 mL) for a full load.

Use less with a smaller load size.

■Follow the manufacturer’s directions for safe use.

■To avoid spilling, use a cup with a pouring spout. Do

not let bleach splash, drip, or run down into the

washer basket.

■Use only liquid chlorine bleach in this dispenser.

4. Close the washer lid.

Fire Hazard

Never place items in the washer that are

dampened with gasoline or other flammable

fluids.

No washer can completely remove oil.

Do not dry anything that has ever had any type of

oil on it (including cooking oils).

Doing so can result in death, explosion, or fire.

WARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Failure to follow these instructions can result in

death, fire, or electrical shock.

Do not use an extension cord.

Do not use an adapter.

Do not remove ground prong.

5. Turn the LOAD SIZE selector to the correct setting for

your wash load and the type of fabric being washed.

■Choose a load size that allows the load to move

freely for best fabric care. See "Loading".

■You may change the load size selection after the

washer has started filling by turning the selector to a

different setting.

6. Set the TEMPERATURE selector to the correct setting

for the type of fabric and soils being washed.

■Use the warmest water safe for fabric.

■Follow garment label instructions.

HOT: 111°F (44°C) or above

– Whites and pastels

– Heavy and greasy soils

WARM: 90° to 110°F (32° to 43°C)

– Bright colors

– Moderate to light soils

COLD: 70° to 90°F (21° to 32°C)

– Colors that bleed or fade

– Light soils

7. Push in the Cycle Control knob and turn it clockwise to

the wash cycle you want. Reduce the wash time when

using a small load size setting. See “Selecting a Cycle

and Time.”

8. Pull out the Cycle Control knob to start the washer.

9. (OPTIONAL STEP) If desired, add measured liquid

fabric softener to the final rinse water. Always dilute

fabric softener with ½ to 1 cup of warm water.

Undiluted fabric softener can stain fabrics.

NOTE: To stop the washer at any time, push in the Cycle

Control knob. To restart the washer, close the lid (if open)

and pull out the Cycle Control knob.

Selecting a Cycle and Time

This section describes the available wash cycles and will

help you make the best cycle selections for your wash

loads. Each cycle is designed for different types of fabric

and soil levels.

■The washer pauses briefly throughout each cycle.

These pauses are normal. Refer to “Normal washer

sounds” to learn more about the sounds you may hear

during a wash cycle.

■Refer to “Understanding washer cycles” to learn what

happens during a wash cycle.

NOTE: This manual covers several different models.

The washer you purchased will not have all of the

cycles described.

Normal cycle

This cycle features high-speed agitation for maximum

cleaning, and high-speed spin to shorten drying time.

Select up to 14 minutes of wash time, depending on your

model, to clean large loads of sturdily constructed fabrics

that are heavily soiled.

Super Wash - Select the 18-minute Super Wash feature to

wash heavily soiled loads that need maximum soil

removal. Use two times the recommended amount of

detergent for this cycle.

Permanent Press cycle

This cycle features a cool-down rinse to minimize wrinkling

of permanent press blends and synthetic fabrics. Use this

cycle to clean lightly to moderately soiled loads.

Short cycle

This cycle features a brief wash and soak period, followed

by a shorter spin andrinse. Use this cycle to clean delicate

items and washable knits that are lightly or moderately

soiled.

Soak cycle

This cycle features brief periods of agitation and soak time

to help remove heavy soils and stains that need

pretreatment. Use warm water when soaking laundry. Hot

water can set stains. Use the amount of detergent or

presoak additive recommended by the manufacturer. After

the Soak cycle ends, add detergent and set a new wash

cycle.

Pre-Wash cycle

This cycle features a brief period of agitation to help

remove heavy soils and stains that need pretreatment. Use

the amount of detergent or presoak additive

recommended by the manufacturer. After the Pre-Wash

cycle ends, add detergent and set a new wash cycle.

Gentle Wash cycle

This cycle features a series of brief agitations and soaks,

followed by shorter spins. Use this cycle to gently clean

special-care items that are lightly or moderately soiled.

Rinse and Spin

When using extra detergent for heavily soiled clothes, or

washing special-care items, you may find an extra rinse

and spin is needed.

1. Push in the Cycle Control knob and turn it clockwise to

any of the Rinse settings.

2. Pull out the Cycle Control knob. The washer fills to the

selected load size, agitates, drains, and spins.

DrainandSpin

A drain and spin may help shorten drying times for some

heavy fabrics or special-care items by removing excess

water.

1. Push in the Cycle Control knob and turn it clockwise to

any of the Spin settings.

2. Pull out the Cycle Control knob. The washer drains,

then spins.

CARINGFORYOUR

WASHER

Cleaning Your Washer

Cleaning the exterior

Use a soft, damp cloth or sponge to wipe up any spills

such as detergent or bleach. Occasionally wipe the

outside of your washer to keep it looking new.

Cleaning the interior

Clean your washer interior by mixing 1 cup (250 mL) of

chlorine bleach and 2 cups (500 mL) of detergent. Pour

this into your washer and run it through a complete cycle

using hot water. Repeat this process if necessary.

NOTE: Remove any hard water deposits using only

cleaners labeled as washer safe.

Self-cleaningLint Filter

Your washer has a self-cleaning lint filter at the bottom of

the basket. Wash and rinse water flow over the filter during

agitation, separating the lint from the water. The lint spins

out of the system during the spin part of the cycle.

If your washer drains into a tub, remove any lint collected

in the tub or strainer.

Water Inlet Hoses

Replace inlet hoses after five years of use to reduce the

risk of hose failure. Periodically inspect and replace inlet

hoses if bulges, kinks, cuts, wear or leaks are found.

When replacing your inlet hoses, mark the date of

replacement on the label with a permanent marker.

Vacation,Storage,

andMovingCare

Install and store your washer where it will not freeze.

Because some water may stay in the hoses, freezing can

damage your washer. If storing or moving your washer

during freezing weather, winterize it.

Non-use or vacation care:

Operate your washer only when you are at home.If you will

be on vacation or not using your washer for an extended

period of time, you should:

■Unplug washer or disconnect power.

■Turn off the water supply to the washer. This helps

avoid accidental flooding (due to a water pressure

surge) while you are away.

To winterize washer:

1. Shut off both water faucets.

2. Disconnect and drain water inlet hoses.

3. Put 1 quart (1 L) of R.V.-type antifreeze in the basket.

4. Run washer on a drain and spin setting (see “Drain and

spin”) for about 30 seconds to mix the antifreeze and

water.

5. Unplug washer or disconnect power.

To use washer again:

1. Flush water pipes and hoses.

2. Reconnect water inlet hoses.

3. Turn on both water faucets.

4. Plug in washer or reconnect power.

5. Run the washer through a complete cycle with 1 cup

(250 mL) of detergent to clean out antifreeze.

Table of contents

Other Whirlpool Washer manuals

Whirlpool

Whirlpool W10175588A User manual

Whirlpool

Whirlpool CHW9050AW User manual

Whirlpool

Whirlpool AZA-HP 8681 User manual

Whirlpool

Whirlpool ONE SPEED AUTOMATIC WASHERS User manual

Whirlpool

Whirlpool WFW9400SZ - Metallic Water Drop R Duet HTR Ultra... Assembly instructions

Whirlpool

Whirlpool LC49OOXM User manual

Whirlpool

Whirlpool AWM 6120 User manual

Whirlpool

Whirlpool 7MLSR6232JT2 User manual

Whirlpool

Whirlpool WTW9500E SERIES User manual

Whirlpool

Whirlpool LA6OOOXS User manual

Whirlpool

Whirlpool FULL ELECTRONIC WASHING MACHINE User manual

Whirlpool

Whirlpool GHW9100LQ2 User manual

Whirlpool

Whirlpool Duet sport User manual

Whirlpool

Whirlpool 4GWTW4800 User manual

Whirlpool

Whirlpool Cabrio WTW6400SW1 User manual

Whirlpool

Whirlpool W10222387A User manual

Whirlpool

Whirlpool AWT 2250/1 User manual

Whirlpool

Whirlpool WTW4955HW User manual

Whirlpool

Whirlpool WTW5505S User manual

Whirlpool

Whirlpool FWF71253SB GCC User manual

Whirlpool

Whirlpool WTW8200Y Series Parts list manual

Whirlpool

Whirlpool LA5460XS User manual

Whirlpool

Whirlpool WTW4880AW User manual

Whirlpool

Whirlpool WFW9600TB00 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Beko

Beko WKB 51231 PTMA manual
