Waring BB185 User manual
Commercial Blender
Operating Manual
BB185 – Commercial Blender with
Electronic Membrane
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed including the following:
1. READ ALL INSTRUCTIONS
2. To protect against electrical hazards, do not immerse the blender base
in water or other liquid.
3. Close supervision is necessary when any appliance is used by or
near children.
4. Unplug from outlet when not in use, before putting on or taking off parts, and
before cleaning.
5. Avoid contacting moving parts.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or is dropped or damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair or
electrical or mechanical adjustment.
7. The use of attachments including canning jars not recommended by the
appliance manufacturer may cause hazards.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Keep hands and utensils out of container while blending, to prevent the
possibility of severe personal injury and /or damage to the blender.
A rubber scraper may be used, but must be used only when the blender
is not running.
11. Blades are sharp. Handle carefully.
12. Your blender utilizes a removable jar base and blade assembly; to avoid
injury,never place cutting assembly or cutting blades on base without
container properly attached.
13. Always operate blender with cover in place.
14. When blending hot liquids, remove centerpiece of two-piece cover.
See Hot Blending Instructions.
SAVE THESE INSTRUCTIONS
BLENDER
ONE QUART CAPACITY SPECIFICATIONS
•Ratings 120 VAC- 50/60 Hz- single phase
•Motors Permanently lubricated series-wound universal type
•Base Die Cast Zinc
•Container 44 oz. Polycarbonate or 32 oz. Stainless Steel
•Cord 6 foot 18 gauge three conductor grounding cord with strain relief
•UL listed 120 volt models
GROUNDING INSTRUCTIONS
•For your protection, Waring®Commercial Blenders are equipped with a
3-conductor cord set.
•120 volt units are supplied with a molded 3-prong grounding type plug and
should be used in combination with a properly connected grounding-type
outlet, as show in Figure A.
If a grounding type outlet is not available, an adapter,show in Figure B, may
be obtained to enable a 2-slot wall outlet to be used with a 3-prong plug.
Referring to Figure C, the adapter must be grounded by attaching its
grounding lug under the screw of the outlet cover plate.
CAUTION: Before using an adapter, it must be determined that the outlet
cover plate screw is properly grounded. If in doubt, consult a licensed
electrician.
Never use an adapter unless you are sure it is properly grounded.
NOTE: Use of an adapter is not permitted in Canada.
OPERATION
1. Put ingredients into container and cover it. Always add liquid ingredients
first, unless otherwise specified in recipe. Do not fill above MAX line.
2. Place container on blender. Be sure container is fully seated and that the
drive coupling is properly engaged.
3. Plug in blender cord into outlet.
4. Press ON/OFF button.
Green LED will illuminate.
5. This blender has 2 speed settings: HIGH
and LOW . Press desired button.
To crush ice, use “HIGH” speed setting.
6. This blender is equipped with a PULSE
option. Press button to engage PULSE function.
Unit will run on High speed until the button is
released.
7. When finished processing, press ON/OFF
button.
8. Allow motor to come to a complete stop before removing container
from blender.
9. Note: Containers with removable bottoms have right-handed threads.
When reassembling, be sure rubber seal is positioned between the
container and the flange of the blade assembly.
10. Safety Feature: If a power outage occurs, blender will turn “Off”. Once the
power returns, the blender will be in its “OFF” position. To turn unit back
“ON”, press the ON/OFF button, and then the desired speed.
Rubber
Seal
IMPORTANT
HOT BLENDING INSTRUCTIONS
To minimize the possibility of being scalded when blending hot materials, the
following precautions and procedures must be observed.
1. Limit the amount of materials processed to 1/2 pint.
2. Completely remove the center portion of the two-piece container lid before
starting motor. (This will allow venting of the rapidly heated and expanding
air present inside the container when blender is running.)
3. Always start blending at lowest speed setting, and then progress to
desired speed.
4. Never stand directly over blender when it is being started or while it
is running.
SERVICE
Refer to the list of Authorized Service Centers enclosed with your
Waring®Commercial Blender for the name of the nearest Service Center, or
Write to:
Waring Factory Service Center
P.O Box 3201
314 Ella T.Grasso Avenue
Torrington, CT 06790
(800) 492-7464
Ship blenders for repair to the above address or to an Authorized Service
Center. Do not ship to a Waring Sales Office.
Note: If your application involves the processing of biologically active material,
we request that any items returned for service be sterilized before being
shipped. Such items must be clearly identified as having been sterilized,
both by a tag on the item itself and by a statement in the accompanying
correspondence. Waring will not accept delivery of any return unless it is
so identified.
Replacement parts for your “Out of Warranty” repairs are obtainable at the
above address.
LIMITED TWO YEAR WARRANTY
Waring warrants every new Waring Commercial Blender to be free from defects in
material and workmanship for a period of two years from the date of purchase when
used with foodstuffs, nonabrasive liquids (other than detergents) and nonabrasive
semi-liquids, providing it has not been subject to loads in excess of the indicated
rating. In addition, the motor in this appliance has a full two year warranty.
Under this warranty, the Waring Commercial Division will repair or replace any part
which, upon our examination, is defective in materials or workmanship, provided the
product is delivered prepaid to the Waring Service Center at: 314 Ella T. Grasso Ave.
Torrington, CT 06790, or any Factory Approved Service Center.
This warranty does not: a) apply to any product which has become worn, defective,
damaged or broken due to use or due to repairs or servicing by other than the
Waring Service Center or a Factory Approved Service Center, or due to abuse,
misuse, overloading or tampering; or b) cover incidental or consequential damages
of any kind.
The two year warranty is applicable only to appliances used in the United States or
Canada; this supersedes all other express product warranty or warranty statements.
For Waring products sold outside of the U.S. and Canada, the warranty is the
responsibility of the local importer or distributor. This warranty may vary according to
local regulations.
Warning: This warranty is void if appliance is used on Direct Current (D.C.)
WARING COMMERCIAL
314 Ella T. Grasso Ave.
Torrington, CT 06790
Waring Commercial
314 Ella T. Grasso Avenue
Torrington, CT 06790
www.waringproducts.com
Part# 026290
RV01 0401 IB-4465
02WA23214
