VTech Baby Lullaby Lambs Mobile Assembly Instructions
Parent’s Guide
Lullaby Lambs Mobile
91-003494-005
3
INTRODUCTION
Thank you for purchasing the Lullaby Lambs Mobile by VTech®.
Gently soothe your baby to sleep with the soothing Lullaby Lambs
Mobile. 3 modes of play allow a selection of nature and white noise
sounds to play with 4 sing-along songs and 40 melodies. Watch the
3 soft lambs gently spin while the music plays and the colourful lights
fade in and out from the projector.
NATURE
SOUNDS
BUTTON
5/15/30 TIMER
SWITCH
ON/OFF
SWITCH
MUSIC
BUTTON
LIGHT & MOTOR
CONTROL
BUTTON
VOLUME
CONTROL
BUTTONS
4
INCLUDED IN THIS PACKAGE
• One parent’s guide
WARNING: All packing materials such as tape, plastic
sheets, packaging locks, removable tags,
cable ties and packaging screws are not part
of this toy, and should be discarded for your
child’s safety.
One remote
control
One C ring One ring
attachment
Four screws
One mobile
support post
Three soft lambsTwo plastic stars
Projector/mobile Base unit Chunky screw
5
NOTE: Please keep this parent’s guide as it contains
important information.
Unlock the packaging locks:
GETTING STARTED
BATTERY INSTALLATION
Lullaby Lambs Mobile
1. Make sure the unit is turned OFF.
2. Locate the battery cover on the bottom
of the mobile. Use a screwdriver to
loosen the screws.
3. Install 3 new AA (LR6/AM-3) batteries
following the diagram inside the
battery box. (The use of a new
alkaline battery is recommended for
maximum performance).
4. Replace the battery cover and tighten
the screws to secure.
Remote Control
1. Locate the battery cover on the bottom
of the remote control. Use a screwdriver
to loosen the screw.
2. Install 2 new AAA (LR03/AM-4)
batteries following the diagram inside
the battery box. (The use of a new
alkaline battery is recommended for
maximum performance).
3. Replace the battery cover and tighten
the screw to secure.
Turn the packaging lock
anticlockwise several times.
Pull out and discard the packaging lock.
6
BATTERY NOTICE
• Use new alkaline batteries or fully charged NI-MH (Nickel Metal-
hydride) rechargeable batteries for best performance.
• Use only batteries of the same or equivalent type as recommended.
• Do not mix different types of batteries: alkaline, standard
(carbon-zinc) or rechargeable, or new and used batteries.
• Do not use damaged batteries.
• Insert batteries with the correct polarity.
• Do not short-circuit the battery terminals.
• Remove exhausted batteries from the toy.
• Remove batteries during long periods of non-use.
• Do not dispose of batteries in fire.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the toy before charging (if
removable).
• Rechargeable batteries are only to be charged under adult
supervision.
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and
batteries, or on their respective packaging, indicates they
must not be disposed of in domestic waste as they contain
substances that can be damaging to the environment and
human health.
The chemical symbols Hg, Cd or Pb, where marked,
indicate that the battery contains more than the specified
value of mercury (Hg), cadmium (Cd) or lead (Pb) set out
in Battery Directive (2006/66/EC).
The solid bar indicates that the product was placed on the
market after 13th August, 2005.
Help protect the environment by disposing of your product
or batteries responsibly.
For more information, please visit:
www.recycle-more.co.uk
www.recyclenow.com
7
ASSEMBLY INSTRUCTIONS
With the VTech®Lullaby Lambs Mobile safety comes first. To
ensure your child’s safety, adult assembly is required.
1. Tighten the screws to secure the
base cover.
2. Attach and tighten the base to the
cot using the chunky screw. Kindly
note the spacing between the rails
of cots should be between 25mm
and 116mm wide. And the cross rail
should not be wider than 58mm.
3. Insert the mobile support post into
the base of the mobile, then insert
the mobile support pole into the back
of the mobile.You will hear a click
when the pole is inserted correctly.
4. Connect the ring attachment into the
bottom of the mobile using the C ring.
8
5. Attach the lambs to the three
branches of the ring attachment, and
the stars to the middle hole of the
ring attachment. The mobile is now
ready for use.
WARNINGS:
Adult assembly required. This package contains four screws.
For your child’s safety, do not let your child play with the toy
until it is fully assembled.
To prevent possible injury by entanglement, remove this toy
when the child starts trying to get up on its hands and knees in
a crawling position.
PRODUCT FEATURES
1. On/Off Switch
To turn the Mobile ON, slide the ON/
OFF SWITCH to the ON ( ) position.
To turn the Mobile OFF, slide the
ON/OFF SWITCH to the OFF ( )
position.
2. Automatic Shut Off
To preserve battery life, the VTech®Lullaby Lambs Mobile
will automatically shut off after approximately 12 hours without
input. The mobile can be turned on again by pressing any button.
Pressing a button on the remote will not activate the mobile after
12 hours of no input.
NOTE: If the mobile repeatedly powers down while playing, we
suggest changing the batteries.
9
ACTIVITIES
1. On/Off Switch
Slide the On/Off Switch to the ON
position ( ) to turn the unit ON. You
will hear 4 soothing songs, then 20
soft melodies with nature sounds.
The light pattern will fade in and out
slowly to the music.
2. Timer Switch
Slide the Timer Switch to select how
long the mobile will play for. When
the time is up the unit will enter sleep
mode. Timer options include 5,15 or
30 minutes.
3. Light & Motor Control Button
Press the Light & Motor Control
Button to select one of four light &
motor modes.
4. Music Button
Press the Music Button to play 4
songs and 40 melodies in a loop.
Press the Music Button again to
play songs or melodies in a loop.
The light pattern will fade in and out
slowly to the music.
5. Nature Sound Button
Press the Nature Sound Button to
hear combinations of nature sounds.
The light pattern will fade in and fade
out slowly with the sounds.
10
6. Volume Control Buttons
Press the Volume Control Buttons
() ( ) to turn the volume up or
down.
7. Sound Sensor
When the Lullaby Lambs Mobile is
in sleep mode, nature sounds or soft
melodies will play when baby’s cry is
detected.
8. Remote Control
The Remote Control can start,
pause and control the volume within
30 feet of the mobile. Be sure there
are no obstructions directly between
the Remote Control and the Remote
Receiver. The Remote Control is
disabled after 12 hours without input.
NOTE: Bright sunlight, artificial light and low battery power may
reduce the Mobile’s sensitivity to the Remote Control. To
increase the reliability, reduce ambient light near the Mobile
and make sure the batteries have power.
MELODY LIST
1. Schubert - Ave Maria
2. Blue Danube Waltz (Strauss)
3. Beautiful Dreamer
4. Cradle Song
5. Clair de Lune
6. Canon In D
