VSS Nederland VCD-5371PIX User manual
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
◆
Do NOT use power sources other than those specified.
◆
Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service person and
should conform to all local codes.
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
1
WDR Digital Sensor Color Dome Camera
2
WDR Digital Sensor Color Dome Camera
3
WDR Digital Sensor Color Dome Camera
How to Use the Camera 15
■Menu 15
■Settings 16
ㆍPRESETS 17
ㆍEXPOSURE 18
ㆍWDR 20
ㆍWHITE BALANCE 21
ㆍDAY/NIGHT 22
ㆍIMAGE ADJ. 23
ㆍSPECIAL 25
- CAMERA ID
- VIDEO OUT
- D-ZOOM
- MOTION
- PRIVACY SETUP
- SYNC
- RS485 SETUP
ㆍEXIT 29
25
26
27
27
28
29
29
Troubleshooting 30
Specifications 32
■Contents
Features
Warnings and Precautions
Names and Functions of Parts
Installation
Cable Connection
■Lens
■OSD
■VBS-EXTRA
■3 Axis Bracket
4
5
9
Dimensions 11
12
Installation (Adaptor Plate) 14
12
10
10
11
11
Components 8
4
WDR Digital Sensor Color Dome Camera
5
WDR Digital Sensor Color Dome Camera
Additional Functions
SYNC (INT/LL), SENS-UP, FREEZE, FLIP
(H/V-REV), D-ZOOM, SHARPNESS and
PRIVACY functions are provided.
Controlled by OSD Menu
The camera can be controlled by selecting
text displayed on the monitor screen.
Wide Dynamic Range (WDR)
The camera delivers clear high quality pictures,
even when backlit, by increasing exposure in
dark areas while decreasing it in bright areas;
a corrected image with clear details results.
ㆍ120dB maximum dynamic range
RS-485 Communication
Control Support (optional)
Remote OSD menu control via an RS-485
interface is supported.
■Features Warning ■
The camera requires periodic inspection.
Contact an authorised technician to carry out the inspection.
Stop using your camera when you find it malfunctioning.
If the camera emits smoke or is unusually hot for a long period,
a fire may be caused.
Do not Install the camera on a surface that can not support it.
If the camera is installed on an inappropriate surface, it may fall
and cause injury.
Do not hold plug with wet hands.
It could cause an electric shock.
Do not dis-assemble the camera.
It may result in an electric shock or other hazards.
Do not use the camera close to a gas or oil leak.
It may result in a fire or other hazards.
Motion Detection
Since the camera detects motion without any
additional external sensor, you can monitor
activity more efficient.
Programmable GAMMA Processing
3 Axis built-in 100mm Dome Housing
High Resolution Color for Crisp,
Clear Video
ㆍProgressive image capture
ㆍ690TVL Effective
Day & Night
The camera identifies whether it is day or night
and automatically switches to the appropriate
mode, depending on its environment. By day,
the camera switches to color mode in order to
maintain optimal color. At night, it switches to
B/W mode so as to obtain better picture definition.
High Sensitivity for low-light
images
The built-in high sensitivity
PIXIM SEAWOLF
Sensor enables
a clear image even at 0.1Lux
DNR (Digital Noise Reduction)
The amount of low illuminance noise has been
significantly reduced, and the signal-to-noise
ratio (S/N ratio) as well as horizontal resolution,
have been improved resulting in a clear and
sharp image image even in low light.
6
WDR Digital Sensor Color Dome Camera
7
WDR Digital Sensor Color Dome Camera
■Precautions
Do not install the camera in
extreme temperature conditions.
Do not install the camera under
unstable lighting conditions.
Do not touch the front lens of the
camera.
Only use the camera under conditions
where temperatures are between
-10˚C and +50˚C. Be especially
careful to provide ventilation when
operating under high temperatures.
It can cause the image quality to be
poor.
Severe lighting change or flicker can
cause the camera to work improperly.
This is one of the most important parts
of the camera. Be careful not to leave
fingerprints on the lens cover.
Do not install or use the camera in an
environment where the humidity is high.
It can cause malfunctions to occur.
If it gets wet, wipe it dry immediately.
Liquids can contain minerals that
corrode the electronic components.
If exposed to radioactivity the CCD
will fail.
It can damage the CCD.
Do not drop the camera or protect
it from physical shocks.
Do not expose the camera to rain
or spill beverage on it.
Do not expose the camera to
radioactivity.
Never keep the camera pointed
directly at strong light.
ㆍIf the camera is exposed to spotlight or an object reflecting strong light,
smear or blooming may occur.
ㆍPlease check the power supply satisfies the normal specification before
connecting the camera.
8
WDR Digital Sensor Color Dome Camera
9
WDR Digital Sensor Color Dome Camera
■Components Names and Functions of Parts ■
1. COLOR DOME CAMERA
2. SCREWS
3. WIRE FOR VBS-EXTRA
4. INSTRUCTION GUIDE
③
④
②①
10
WDR Digital Sensor Color Dome Camera
11
WDR Digital Sensor Color Dome Camera
■Names and Functions of Parts Names and Functions of Parts ■
②OSD PCB
●SET button : Used for the menu display. This button can be used to
confirm settings after changing the value of the selected function or
current conditions.
●UP & DOWN buttons : Used for selecting items by moving the cursor
up or down on the menu screen.
●LEFT & RIGHT buttons : Used when changing item values, by moving
the cursor to the left or right on the menu screen.
①LENS : Vari-Focal DC Auto Iris Lens
DOWNUPSETRIGHTLEFT
③VBS-EXTRA FOR CONNECTING TO LCD
Please use the supplied wire when connecting to external monitor
VBS-EXTRA
④3 AXIS BRACKET
Adjust the pan and tilt to give the correct angle of view.
(unit : mm)
100φ
73.0φ
125.79φ
105.5
55.0
Dimensions ■
12
WDR Digital Sensor Color Dome Camera
13
WDR Digital Sensor Color Dome Camera
■Installation
1. Dome Base Mounting
- Open the dome cover by loosening 3 screws using special wrench
provided.
- Mount the base of camera to a sturdy surface using 4 screws
(1.5 inch) and 4 premade holes on the base of the dome.
2. Power Connect & Monitor Impedance
- DC12V/300mA regulated power supply (DC12V only)
AC24V Class 2 power supply (AC24V/DC12V)
- To avoid fire or shock hazard, must use a UL listed power supply.
- Set the monitor impedance switch to 75Ω. Check the impedance
switch when the screen turns blurred.
3. Camera Module Adjustment
- Loosen screws for 3-axis camera bracket and adjust the direction
and angle of camera.
- Make sure to retighten the screws for camera bracket.
- Set any function you wish to activate by using the OSD buttons.
4. Dome Cover Mounting
- Replace the dome cover to the base and tighten 3 screws.
Control via RS-485 Interface (Optional)
RS-485 Control Port
485 Control Board Connection Port
485+
(+) CONNECTION TERMINAL (TRX+)
(- ) CONNECTION TERMINAL (TRX-)
485-
Item
Initial value
PET PKT
UART MODE
BAUD RATECamera ID
ENABLE
8-NONE-124001
The camera can be controlled by using an external controller equipped
with RS-485 communications.
• To control using a DVR or keyboard controller
Connect the RS-485 cable (TRX+, TRX-) to the connection port of the
485 control board in the DVR or controller.
* RS-485 communication default initial values
•
To control the camera use Pelco-D protocol.
- Set Preset 95 : Enters into OSD menu.
- Iris Open command : Set key function.
- Iris Close command : Cancel function.
Note
■Cable Connections
DOME COVER
GIMBAL A'SSY
BASE HOUSING
DECORATION RING
DC only
AC24V
DC12V AC IN
DC IN AC IN
DC IN
VIDEO
POWER
RS-485 (Optional)
14
WDR Digital Sensor Color Dome Camera
15
WDR Digital Sensor Color Dome Camera
How to Use the Camera ■
ㆍOUTDOORㆍINDOORㆍNORMAL
SETUP menu
PRESETS
EXPOSURE
WDR
WHITE BALANCE
DAY/NIGHT
IMAGE ADJ.
EXIT MENU
ㆍMIDDLE
ㆍLOW
ㆍRS485 SETUP
ㆍCAMERA ID
ㆍMOTION
ㆍATW
ㆍAWB ㆍMANUAL
ㆍFREEZE
ㆍAUTO
SPECIAL
ㆍHIGH
ㆍRESET
ㆍVIDEO OUT
ㆍPRIVACY SETUP
ㆍINDOOR ㆍOUTDOOR
ㆍFLIP ㆍSHARPNESS
ㆍCOLOR GAIN ㆍGAMMA
ㆍUSER
ㆍDZOOM
ㆍSYNC
ㆍRETURN
ㆍCOLOR ㆍBW
■
Menu
■Installation (Adaptor Plate)
* When installing on an adaptor plate bracket.
① Place the adaptor plate bracket on a flat installation surface and fix it with
the screws provided.
② When placing the camera body onto the plate, insert the plate pin into the
corresponding holes on the camera body as shown in figure-1. Lock the
camera in place by turning the camera body clockwise.
③
When placing the camera body on the plate, make sure that the power and
video cables pass through.
④
After installation and adjustment of the camera is complete, secure the dome
cover by turning it clockwise.
Unlocking
direction
Locking
direction
Dome Cover
Unlocking
direction
Locking
direction
Camera Body
3.5x25 tapping
screw (provided)
Adaptor Plate
ㆍLENS
ㆍDNR
ㆍCOLOR ROLL ㆍSENS-UP
ㆍEXPOSURE MODE
ㆍFOCUS
ㆍHIGHLIGHT
ㆍAGC
16
WDR Digital Sensor Color Dome Camera
17
WDR Digital Sensor Color Dome Camera
■How to Use the Camera
SETUP
PRESETS
EXPOSURE..
WDR
WHITE BALANCE
DAY/NIGHT
IMAGE ADJ..
SPECIAL..
EXIT MENU.
NORMAL
MIDDLE
ATW
AUTO..
3.
Set up a selected item by using the Left and Right buttons.
4.
To finish and save the settings, select 'EXIT' and press the SET button.
Select the function using
the UP or DOWN button.
Change the status using
the LEFT or RIGHT button.
PRESETS
Note
•
An item with the .. icon also has sub-menus. To select a sub-menu,
press the SET button.
SETUP
PRESETS
EXPOSURE..
WDR
WHITE BALANCE
DAY/NIGHT
IMAGE ADJ..
SPECIAL..
EXIT MENU.
NORMAL
MIDDLE
ATW
AUTO..
●
NORMAL : Normal environment.
●
INDOOR : Indoor environment.
●
OUTDOOR : Outdoor environment.
Settings can be made using the 5 buttons located in the camera.
DOWNUPSETRIGHTLEFT
1. Press the SET button
ㆍSettings can now be made. The SETUP menu is displayed on the monitor.
2. Select a menu item from the list available by using the UP and DOWN
buttons.
ㆍFuntions are selected using up and down buttons.
ㆍThe selected position is displayed in blue.
■
Settings
SETUP
PRESETS
EXPOSURE..
WDR
WHITE BALANCE
DAY/NIGHT
IMAGE ADJ..
SPECIAL..
EXIT MENU.
NORMAL
MIDDLE
ATW
AUTO..
18
WDR Digital Sensor Color Dome Camera
19
WDR Digital Sensor Color Dome Camera
EXPOSURE
SETUP
PRESETS
EXPOSURE..
WDR
WHITE BALANCE
DAY/NIGHT
NORMAL
MIDDLE
ATW
AUTO..
● LENS : Using this function, you can control the screen brightness.
ㆍDC / Manual : Select Lens Type
LENS MENU
DC GAIN
VIDEO GAIN
AI THRESH
PREVIOUS PAGE.
0 120 255
-24
500 255
-48 60
When the SETUP menu screen is displayed, select‘EXPOSURE’by
using the Up and Down buttons so that the arrow indicates‘EXPOSURE’.
■How to Use the Camera
EXPOSURE
LENS
FOCUS..
EXPOSURE MODE
AGC
DNR
HIGHLIGHT
COLOR ROLL
SENS-UP
PREVIOUS PAGE.
DC..
60 i
MIDDLE
MIDDLE
ON
LOW
2X
● FOCUS : To adjust the DC and VIDEO lens focus
● EXPOSURE MODE : To select the number of fields and number
of exposure cycles.
- 60i / 30p selectable
● AGC (AUTO GAIN CONTROL) : In the dark situation, the higher the
gain level, the brighter the screen but the higher the noise.
- OFF / LOW / MIDDLE / HIGH selectable
● DNR (Digital Noise Reduction) : The level of background noise in low
light decreases automatically as the level of gain changes.
- OFF / LOW / MIDDLE / HIGH selectable
● HIGHLIGHT : To optimize the scene when high dynamic range lighting
is detected.
- ON : bright parts of the image are most visible.
- OFF : dark parts of the image are most visible.
FOCUS DETECTOR
FOCUS METER
SET FOCUS REGION..
PREVIOUS PAGE.
88
SET FOCUS REGION
● COLOR ROLL : To control a detector that finds color fluorescent roll.
- OFF / LOW / MIDDLE / HIGH selectable
Table of contents
Other VSS Nederland Security Camera manuals
