Volvo 31664097 User manual
5
5
Instruction No Version Part. No.
31399512 1.1 31664097, 31260698
Electric engine heater, 230V, (R
-
design)
IMG-
378302
5
5
Instruction No Version Part. No.
31399512 1.1 31664097, 31260698
Electric engine heater, 230V, (R
-
design)
IMG-
378302
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 1 / 33
Equipment
A0000162
IMG-
239664
IMG-
239980
IMG-
239660
IMG-
316183
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 2 / 33
IMG-
379391
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 3 / 33
INTRODUCTION
Read through all of the instructions before starting installation.
Notifications and warning texts are for your safety and to
minimise the risk of something breaking during installation.
Ensure that all tools stated in the instructions are available
before starting installation.
Certain steps in the instructions are only presented in the form
of images. Explanatory text is also given for more complicated
steps.
In the event of any problems with the instructions or the
accessory, contact your local Volvo dealer.
1
IMG-
363036
Color symbols
Note!
This colour chart displays (in colour print and electronic version)
the importance of the different colours used in the images of the
method steps.
Used for focused part, the part that you are to do
something with.
1.
Used as extra colors when you need to show or
differentiate additional parts.
2.
Used for attachments that are to be removed/installed.
May be screws, clips, connectors, etc.
3.
Used when the component is not fully removed from
the vehicle but only hung to the side.
4.
Used for standard tools and special tools.5.
Used as background color for vehicle components.6.
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 4 / 33
2
IMG-
351277
Removal
3
IMG-
217771
Remove the right
-hand front wheel.
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 5 / 33
4
IMG-
231547
Rotate the front wheels so that the bolts in the wheel arch liner
on the left and right side are accessible.
5
IMG-
231549
Remove the seven screws in the front edge of the wheel arch
liner on the left and right sides.
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 6 / 33
6
IMG-
231550
Remove the plastic nut holding the wheel arch liner to the body
on the left and right side.
7
IMG-
231551
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 7 / 33
8
IMG-
231309
Remove the engine splash guard.
9
IMG-
379415
Clean the marked area.
Soap solution.
Use: soap solution
Wipe dry.
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 8 / 33
10
IMG-
379417
Use the template from the installation instructions.
Cut out following the dotted lines.
Note!
Check the scale.
11
IMG-
379439
Attach the template edge to edge with front edge of the front
wing and the joint in the bumper cover as illustrated.
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 9 / 33
12
IMG-
379445
Take a sharp knife. First make a thin cut along the edges of the
inside of the template. This provides a groove to follow. Then cut
carefully out of the bumper cover.
Note!
Cut carefully. It is easy to slip with the knife and move outside
the template.
Remove the template.
Install the protective cover for the front engine block heater
socket from the kit. Check that it aligns. Adjust the hole using a
knife or file as necessary.
Smooth off the hole edges. Remove any swarf.
13
IMG-
231551
Fold the wing liner out of the way.
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
©
Volvo Car Corporation Electric engine heater, 230V, (R
-
design)
-
31399512
-
V1.1
Page 10 / 33
