Vivo STAND-V102G2D User manual
Pneumatic Arm Dual Monitor Desk Mount with
Docking Station
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://vivo-us.com/products/stand-v102G2D
SKU: STAND-V102G2D
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
2
PACKAGE CONTENTS
WARNING!
A (x1)
Base
B(x2)
Lower Arm
C(x2)
Gas Spring Arm
J (x1)
Clamp
S-A (x4)
M6x12mm Screw
If you do not understand these directions, or if you have any doubts about the safety of the
installation, please call a qualified technician. Check carefully to make sure there are no missing or
defective parts. Improper installation may cause damage or serious injury. Do not use this product
for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity.
We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or
inappropriate use.
NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED
M-A (x8)
M4x12mm Screw
D(x2)
VESA Plate
E(x1)
Clamp Plate
F (x1)
Grommet Plate
G(x1)
So Pad
H (x1)
Cover
I (x1)
Clamp Brace
TIPOVER WARNING
SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER:
• NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF MONITOR OR
STAND.
• USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL
USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIPOVER.
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
M-B (x8)
M5x12mm Screw
M-C (x8)
M5 Washer
T-B (x1)
4mm Allen Wrench
T-C (x1)
6mm Allen Wrench
T-A (x1)
3mm Allen Wrench
K (x1)
USB-C Cable
3
ASSEMBLY STEPS
STEP 1 (Option A)
Clamp Installation
Attach Clamp Brace (I) to Base (A) using M6x12mm Screws (S-A) and tighten with 4mm Allen Wrench
(T-B). Apply So Pad (G) to the underside of the assembly.
TOOLS NEEDED
2.2-33lbs
(1-15kg)
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
Phillips
Screwdriver
PER ARM
OR
I
A
S-A
T-B
G
J
T-B
E
T-C H
Loosen screws on the back of Clamp (J), leaving 6mm of thread exposed. For a desk thickness of 3/8”
- 2-1/2” (10 - 58mm), hang Clamp (J) into top four slots of Clamp Brace (I), or for a desk thickness of
2” - 3-3/8” (50 - 85mm), into lower four slots. Place Clamp Plate (E) on top of clamp bolts. Position the
clamp assembly on desktop
Tighten clamp bolts evenly using 6mm Allen Wrench (T-C). Attach Cover (H) to back of Clamp Brace (I).
4
STEP 1 (Option B)
Grommet Base Installation
Attach Grommet Plate (F) to Base (A) using M6x12mm Screws (S-A) and tighten with 4mm Allen Wrench
(T-B). Apply So Pad (G) to underside of of the base assembly.
F
A
S-A
T-B G
E
J1
J
T-C
E
Use Clamp Plate (E) to mark drilling locations and drill 3/8” (10mm) holes through the desk for
installation.
Remove the Clamp Bolts (J1) from Clamp (J) using 6mm Allen Wench (T-C) if needed. Insert Clamp
Bolt (J1) with Clamp Plate (E) up through the underside of the desk and tighten to the base assembly
using 6mm Allen Wrench (T-C).
J1
5
STEP 2
Loosen the set screws on the bottom of Lower Arms (B) using 3mm Allen Wrench (T-A). Attach Lower
Arms (B) to Base (A). For 180° rotation, retighten both set screws. For 360° rotation, retighten the
bottom set screw only.
STEP 3
Loosen the set screw on the top of Lower Arm (B) using 3mm Allen Wrench (T-A). Attach Gas Spring Arm
(C) to Lower Arm (B) and retighten the set screw.
B
T-A
A
B
T-A
C
6
STEP 4
Assemble VESA Plates (D) to the back of the monitors using Screws (M-A, M-B) and M5 Washers (M-C).
Tighten with a Phillips screwdriver.
STEP 5
STEP 5
Pull back and hold the release levers on Gas Spring Arms (C), then slide the monitors with VESA Plates
(D) onto the arms.
If needed, adjust Gas Spring Arms (C) to support the monitor using 6mm Allen Wrench (T-C). Turn the
screw in back clockwise to decrease support, and counter-clockwise to increase.
D
C
D
C
T-C
7
STEP 7
Remove the cable covers on Gas Spring Arms (C) using a Phillips screwdriver. Slide the cable covers on
Lower Arms (B) forward to remove. Route cables through the arms and Cover (H), then reattach the
cable covers.
C
B
H
STEP 8
Adjust the tilt using 6mm Allen Wrench (T-C). Store the Allen wrench set in Cover (H) for future
adjustments.
T-C
H
LAST UPDATED: 12/05/2022
REV1.1
Open Monday - Friday 7:00am - 7:00pm CST,
our dedicated support team can oer immediate assistance with rapid response times. If any
parts are received damaged or defective, please contact us. We are happy to replace parts to
ensure you have a fully functioning product.
FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com
Love your new VIVO setup and want to share?
Tag us in your photo! @vivo_us
- 23% within < 15m
- 38% within < 30m
- 61% within < 1hr
- 83% within < 2hr
- 92% within < 3hr
AVG. RESOLUTION TIME (within oice hrs): < 15 M
www.vivo-us.com
Chat live with an agent!
AVG. RESOLUTION TIME (within oice hrs): 5M 4S
309-278-5303
