VEVOR TC7200 User manual
Support and E-Warranty Certificate https://www.vevor.com/support
INSTRUCTIONS FOR TOOL CABINET
ASSEMBLY
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL:TC7200
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Tool Cabinet
Assembly
- 2 -
Please read instructions carefully before assembly.
Warning-To reduce the risk of injury, user must read
instructions manual carefully.
Assembly Parts List
Part
Description
Qty
1
Screw-ST4.2*10
21
2
Bolt-M6*16
14
3
Bolt-M8*25
16
4
Shelf clip
8
5
Door stop
4
6
Swivel castor 5"
2
7
Rigid castor 5"
2
8
Left back
1
- 3 -
9
Right back
1
Part
Description
Qty
10
Left side panel
1
11
Right side panel
1
12
Top cover
1
13
Bottom
1
14
Shelf
4
15
Clothes rail
1
16
Left door
1
17
Right door
1
- 4 -
ADDITIONAL TOOLS REQUIRED:
1.Phillips Head Screwdriver.
2. #12 Open-end wrench or #5 Internal hexagonal wrench.
3. Rubber Mallet (or hammer with soft covering).
SAFETY TIPS:
1. Please handle metal edges carefully.
2. Prepare a soft, level surface on ground level before commencing assembly.
3. Once assembled, maximum safe load limit per shelf is 200 lb, evenly
distributed.
4. Always fill shelves from the bottom up, to help prevent any toppling issues.
MAINTENANCE:
To clean and maintain your unit, we recommend periodic cleaning using a soft
cloth and gentle natural cleaner.
Table of Parameters
Items
Description
Name
Tool Cabinet
Model
TC7200
External Dimensions
910×456×1828 mm
36×18×72 inch
Package Size
1750×545×270 mm
G.W.
57.2 kg
- 5 -
Instructions for Installation
Body Assembly
STEP 1 Join left back(8) and right back(9) together with screw-ST4.2*10,as
shown.
STEP 2 Join left side panel(10) and right side panel(11) together with
screw-ST4.2*10, as shown.
Before assembling the side panels, remove the two U-shaped protection slots
at the bottom of the side panels
- 6 -
STEP 3 Insert the back and side panels into the limit slots on the topcover,then
use bolt-M6*16(2) to fix the top cover and side panels together.
STEP 4 Attach theand two swivel castor 5"(6) to the front of the bottom with
bolt-M6*16（3）,two rigid castor 5"(7) are mounted at the rear of the bottom,as
shown.
- 7 -
STEP 5 Insert the bottom into the side panel and back, and join bottom(8) front
and side panel together with four bolts-M6*16 (2).
- 8 -
STEP 6 Flip the body over 90°，Install the four bolts-M6*16(2) on the back as
shown.
- 9 -
Shelf Assembly
Stand the body upright with the casters on the ground，as shown in the figure, first
insert the rear ends of the shelf (14) into the side panel hanging buckle at the
appropriate height, and then install the shelf clip（4)at the corresponding position.
