Vertiv Liebert EDGE Installation and maintenance instructions

Vertiv Liebert® EDGE

Installer/User Guide

| Liebert® EDGE Installer/User Guide

Technical Support Site

If you encounter any installation or operational issues with your product, check the pertinent

section of this manual to see if the issue can be resolved by following outlined procedures.

Visit https://www.vertiv.com/en-us/support/ for additional assistance.

The information contained in this document is subject to change

without notice and may not be suitable for all applications. While

every precaution has been taken to ensure the accuracy and

completeness of this document, Vertiv assumes no responsibility

and disclaims all liability for damages resulting from use of this

information or for any errors or omissions. Refer to other local

practices or building codes as applicable for the correct methods,

tools, and materials to be used in performing procedures not

specifically described in this document.

The products covered by this instruction manual are manufactured

and/or sold by Vertiv. This document is the property of Vertiv and

contains confidential and proprietary information owned by Vertiv.

Any copying, use or disclosure of it without the written permission

of Vertiv is strictly prohibited.

Names of companies and products are trademarks or registered

trademarks of the respective companies. Any questions regarding

usage of trademark names should be directed to the original

manufacturer.

Liebert® EDGE Installer/User Guide

TABLE OF CONTENTS

1 Important Safety Instructions 1

2 EDGE Description 3

2.1 Available Models 3

2.2 Rear Panel Views 4

2.3 Front Panel 5

3 Installation 7

3.1 What’s Included 7

3.2 Unpacking and Inspection 7

3.3 Preparation for Installation 8

3.3.1 Installation Environment 8

3.3.2 Installation Clearances 8

3.4 Installing the UPS 8

3.4.1 Installation Environment 8

3.4.2 Installing a Mini Tower (MT) Model 11

3.5 Connecting Loads 11

3.6 USB Communication Connection 11

3.7 Emergency Power-off (EPO) Connection (Optional) 11

3.8 External Battery Cabinet Connection on 2U and 3U VRLA Models (Optional) 12

3.9 Network Communication Card Connection (Optional) 13

3.9.1 Connecting AC Input 13

4 Operations 15

4.1 Modes of Operation 15

4.1.1 Off Mode 15

4.1.2 On/Normal Mode 15

4.1.3 On/Automatic Voltage Regulation (AVR)/Boost1 Mode 15

4.1.4 On/Automatic Voltage Regulation (AVR)/Boost2 Mode 15

4.1.5 On/Automatic Voltage Regulation (AVR)/Buck Mode 15

4.1.6 On/Battery Mode 15

4.1.7 Fault Mode 15

4.1.8 Battery Self-test Mode 15

4.1.9 Controls 16

4.2 Startup wizard 17

4.2.1 Default Screen and Flow Screens 17

4.2.2 Main menu Screen 19

4.2.3 Status Screen 19

4.2.4 Settings Submenu 21

4.2.5 Control Screen 29

4.2.6 Log Screen 29

Liebert® EDGE Installer/User Guide

4.2.7 About Screen 32

4.2.8 Maintenance screen 33

4.3 Editing Display and Operation Settings 35

4.3.1 Changing the Password 36

5 Maintenance and Battery Replacement 39

5.1 Precautions 39

5.2 Battery Charging 39

5.3 Replacing the UPS Batteries 39

6 Specifications 43

6.1 Battery Run Times 53

Appendices 61

Appendix A: Technical Support 61

Liebert® EDGE Installer/User Guide

1 Important Safety Instructions

IMPORTANT! This manual contains important safety instructions that must be followed during the

installation and maintenance of the UPS and batteries. Read this manual thoroughly and the safety and

regulatory information, available at https://www.vertiv.com/ComplianceRegulatoryInfo, before

attempting to install, connect to supply, or operate this UPS.

1 Important Safety Instructions 1

Liebert® EDGE Installer/User Guide

1 Important Safety Instructions

This page intentionally left blank

Liebert® EDGE Installer/User Guide

2 EDGE Description

The Liebert® EDGE is a line-interactive UPS designed for IT applications such as network closets and

small data centers. It is available in 1U, 2U, 3U and MT(mini tower) form factors. It provides reliable power

protection for servers, critical nodes, network workstations, large network peripherals, network routers,

bridges, hubs and other electronic equipment. Matching battery cabinets are available to extend the on-

battery operating time for 2U and 3U VRLA models. The optional Liebert® Network Communication Card

makes advanced monitoring and control available.

2.1 Available Models

BATTERY TYPE MODEL FROM FACTOR MODEL NUMBER NOMINAL POWER RATING (230 V INPUT)

VRLA (Valve Regulated Lead Acid)

EDGE-500IRT1U 500 VA / 450 W

EDGE-1000IRT1U 1000 VA / 900 W

EDGE-1500IRT1U 1500 VA / 1350 W

EDGE-1500IRT2UXL 1500 VA / 1350 W

EDGE-2200IRT2UXL 2200 VA / 1980 W

EDGE-3000IRT2UXL 3000 VA / 2700 W

3U EDGE-3000IRT3UXL 3000 VA /2700 W

EDGE-750IMT 750 VA / 675 W

EDGE-1000IMT 1000 VA / 900 W

EDGE-1500IMT 1500 VA / 1350 W

LI (Lithium Ion) 2U

EDGELI-1500IRT2U 1500 VA / 1350 W

EDGELI-2200IRT2U 2200 VA / 1980 W

EDGELI-3000IRT2U 3000 VA / 2700 W

Table 2.1 EDGE Models

2 EDGE Description 3

Liebert® EDGE Installer/User Guide

2.2 Rear Panel Views

Figure 2.1 Rear Panel

ITEM DESCRIPTION ITEM DESCRIPTION

1 Input circuit breaker 6 Non-programmable receptacles

2 AC input 7 Emergency Power Off (EPO) connector

3 USB communication port 8 Output circuit breakers

4 IntelliSlot port 9 Ground Screw

5 Programmable receptacles 10 External Battery Cabinet (EBC) connector

2 EDGE Description

Liebert® EDGE Installer/User Guide

2.3 Front Panel

NOTE: For detailed descriptions of the LCD display. See Controls.

Figure 2.2 Controls and Display

ITEM DESCRIPTION

1 ESC/MUTE button. SeeControls, for details.

2 DOWN/LEFT button. SeeControls, for details.

3 UP/RIGHT button. See Controls, for details.

4 ENTER/ button. See Controls, for details.

2 EDGE Description 5

Liebert® EDGE Installer/User Guide

2 EDGE Description

This page intentionally left blank
