Verano V255 Salou User manual

Sun awning V255 Salou
cassette
Installation manual

12908357-180528EN(3)Subject to misprints, errors and technical modifications.
Installation manual Sun awning V255 Salou
Content package
1. Sun awning *
2. Control
a. Manual control: crank handle
b. Electrical: switch + plug
c. Remote controlled: remote control + plug
* The displayed awning is an electrical version.
1
Necessary tools
• Drilling machine
• Support drill 10/14 mm
• Crosshead screwdriver
• Socket wrench 10/13/17
• Keyset
• Clack with lengthening piece, husk 10/17 mm
• Tapeline
• Plumb rule
• Pencil
In case of electrical control:
• Nippers
• Flathead screwdriver

12908357-180528EN(3)Subject to misprints, errors and technical modifications.
Installation manual Sun awning V255 Salou
2
Front view wall support, le Side view wall support, le
1
0°
0 cm
100
cm
200
cm
300
cm
20°
25°
Projection 250 cm 200 cm 300
cm
5°
Wall installation Sizes in mm
Specications
157,5
25
25
285
25
12,5
13
21,3
32,9
32,9
12
20
90°
285
260,5
60
7 11
Minimal width (W) per fabric projection
1500 1655
2000 2235
2500 2740
3000 3320
Projection [mm] Minimal awning width (W) [mm]
Width (W)
Minimal 1655 mm Maximal 6000 mm

12908357-180528EN(3)Subject to misprints, errors and technical modifications.
Installation manual Sun awning V255 Salou
Important before mounting
3
1
2
3
4
5
rollaag
min. 30 cm
Patio door
When the awning is fully open, it hangs down under the angle. Therefore we advise to keep at least 30 centimeters
between the window frame and the awning in a situation with patio doors to the outside. When possible, it is advisable to
hang the awning higher than 30 centimeters above the window frame.
General warning
Mounting the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the mounting of this
specic Verano® product. If you cannot mount the product yourself, you can always opt for professional mounting. The
mounting team of Verano® is pleased to help you.
Be careful for damages
Don’t use a knife or any other sharp object when opening the packing. This may cause damage to the content of the pac-
kage. Put the content of the package on a so surface. Be careful when drilling, falling drill cuttings can cause damages.
Check if the window frame or façade is at and smooth.
Check the mounting height
Make sure that you have enough mounting height on your façade to place the awning. Above the wall support (mounting
support) have to be 5 rows of stones to prevent to much pressure on the façade. This is not oen the case with a house-
extension. It is recommended to drill the mounting hole in the h stone (minimum) measured from the top.
Wall strips
When there are fewer than ve rows of stones above the wall support, wall strips have to be used. These strips divide the
forces over a bigger wall surface when the walls are to weak.See page 5 for extensive instructions.
Attention! Make sure there is no mounting point in the soldier course. These are oen half stones.
Soldier course

12908357-180528EN(3)Subject to misprints, errors and technical modifications.
Installation manual Sun awning V255 Salou
1.1 Marking the holes
For the installation of the awning, the two wall supports (A) need to be level horizontal and vertical. See gure 1.1
and 1.2. The wall supports need to be installation in the same line on the wall. If the wall supports are not in the same
line (with an uneven position of the arms as a result) the awning will not function correctly.
Mark the drill holes of the wall supports (A) carefully on the
wall according to size X and size Y in gure 1.2.
Make sure that the upper installation holes are in the
middle of the stone.
If necessary, use an alignment string.
g. 1.2 Placing the wall supports
4
g. 1.1 Wall support sun awning
1. Installation on the wall
W = Width of the awning
Y = Window frame height plus minimal 30 cm
A = Wall supports
A
A
1.2 Drilling the holes
Drill the installation holes. We advise to use a 14 mm stone drill if you need to drill in a cement or stone wall. Use
matching plugs and nuts of high quality. Install the awning on the wall and fasten the nuts in the wall supports (A)
tightly. Use a clack with lengthening piece.
1.3 Drilling the control hole
Do you have wall control and do you want to connect it on the inside? Measure the location of the control hole carefully.
The location depends on your personal preference and situation. Drill with a 10 mm drill to the inside. Hold a shelf on the
inside of the wall to prevent damages to the wall when drilling through.
W
AA
Y

12908357-180528EN(3)Subject to misprints, errors and technical modifications.
Installation manual Sun awning V255 Salou
1.4 Installation using wall strips
If there are less than ve rows of stones above the installation location, wall strips need to be used. The strips divide the
power over a larger wall surface so that the wall can carry more weight. gure 1.3.
Follow the steps below to install the wall strips (see gure 1.3 and 1.4):
1. Mark the positon of the wall strips on the wall according to size X and Y in gure 1.2. The wall strips need to be, both
horizontal and vertical, levelled. Make sure that the installation holes are in the middle of the stone. If necessary, use
an alignment string.
Attention! The le wall strip is turned 180 degrees relative to the right wall strip.
Fasten the wall strips tight to the wall.
2. Install the awning as high as possible on the wall strips with two nuts per wall support.
3. Install the fastening block at the bottom of the wall strip. The block is needed to fasten the cover plate.
4. Place the closure cap over the bottom part of the wall strip. You need to customize it rst.
5. Install the cover plate to the fastening block in the bottom part of the wall strip.
6. The installation of the awning on the wall strips is now nished.
LINKS RECHTS
boorsleuf
g. 1.3 Using wall strips
5
g. 1.4 Installation of the wall strip (le)
LEFT
Drill slot
RIGHT
5321 64

12908357-180528EN(3)Subject to misprints, errors and technical modifications.
Installation manual Sun awning V255 Salou
6
2. Electrical wall control
TIP! Sealing the hole
In case of an electrical wire to the inside, we advise to seal the hole where the wire comes in. This to prevent moisture from
running inwards. Attention! Do this both on the in- and outside.
2.2 Standard factory setting
The motor control is set standardly.
See the included manual of the motor and the possible remote control.
g. 2.1 Motor le (seen from the outside) g. 2.2 Motor right (seen from the outside)
2.1 Connecting the wall control
1. Check the position of the motor (le or right), seen from the outside!
2. If you have inside control, rst guide the cable through the hole in the wall you drilled before.
3. Connect the four-wired cord of the motor and the three-wired cored with plug following the scheme below.
4. Put the plug in the power point.
5. The awning is now connected. Before you continue the installation, check if the awning rolls out correctly.
geel/groen
blauw
bruin
geel/groen
blauw zwart
bruin
bruin
geel/groen
blauw
bruin
geel/groen
blauw
zwart
bruin
bruin
geel/groen
blauw
bruin
geel/groen
blauw zwart
bruin
bruin
geel/groen
blauw
bruin
geel/groen
blauw
zwart
bruin
bruin
brown
brown
brown
brown
brown
brown
black
black
blue
blue
blue
blue
yellow/green
yellow/green
yellow/green
yellow/green

12908357-180528EN(3)Subject to misprints, errors and technical modifications.
Installation manual Sun awning V255 Salou
7
3.1 Connecting the remote control
1. If the power point is located on the inside, rst guide the wire through the hole in the wall you drilled before.
2. Install the plug according to the color scheme below:
• Brown 220V power supply
• Blue 220V power supply
• Yellow/green grounding
• Black (do not connect)
• White (do not connect)
• Orange (do not connect)
3. Put the plug in the power point.
4. The awning is now connected. Before you continue the installation, check if the awning rolls out correctly by using the
remote control.
TIP! Sealing the hole
In case of an electrical wire to the inside, we advise to seal the hole where the wire comes in. This to prevent moisture
from running inwards. Attention! Do this both on the in- and outside.
3. Remote control

12908357-180528EN(3)Subject to misprints, errors and technical modifications.
Installation manual Sun awning V255 Salou
4
1
2
4
3
1
2
3
4.1 Standard factory setting
The walk-through height of the front bar is standardly set between 1,80 and 1,90 meter at an installation height of 2,70
meter.
4.2 Setting the inclination
If you want to set the awning dierent from the standard factory setting, follow the steps below:
1. Roll out the awning. The arm connections are located le and right on the awning.
2. Twist nut #1 in one turn (wrench 17). Li the front bar during the twist so that the adjusting bolt (or allen) moves easily.
See gure 4.1.
3. Twist hexagon nut #2 (wrench 13) or allen #2 for an up and down movement. Le = down, right = up. Li the front bar
during the twist.
4. If the front bar is on the right height on one side, than:
Fasten nut #1. Li the front bar during the twist so that the allen nut #3 (allen #6) is fastened rectilinear.
The allen nut #3 can be skew is nut #1 is loosened to much.
5. Repeat the steps above on the other side until the front bar is in the same line with the top cap.
Attention! Never touch nut #4.
g. 4.1 Detail arm connection right
8
4. Inclination

12908357-180528EN(3)Subject to misprints, errors and technical modifications.
Installation manual Sun awning V255 Salou
5.1 Setting the front bar
The right position can be achieved if the front bar connects perfectly to the top- and bottom cap if the awning is closed.
See gure 5.1.
Follow the steps below if the opening between the cap and the front bar is to large:
1. Unroll the awning until the arms and the fabric are completely tension free.
2. At the end of the folding arms (on the side of the front bar), arm connections are located. See gure 5.1.
3. Twist the bolts #1 (allen 10) loose on both sides.
4. Put the front bar in the desired position.
5. Fasten the bolts #1.
6. Roll in the awning.
211
g. 5.2 Detail arm connection on front bar
g. 5.1 Position front bar
9
5. Front bar
Attention! Never touch allen #2.
Attention! The fabric should always be on the upperside.
