Vacron VDH-NK350A User manual
VDH-NK350A
Hardware Manual
2015 JUL V1.2
VDH-NK350A Hardware Manual
i
Contents
A. CAUTION .............................................................................................................................................. 1
B. Introduction ......................................................................................................................................... 2
1. Product Overview ..................................................................................................................... 2
2. Main functions ........................................................................................................................... 2
C. Unpacking ............................................................................................................................................ 3
1. Accessories ................................................................................................................................. 3
2. Unpacking ................................................................................................................................... 3
D. Installation ............................................................................................................................................ 3
E. Product appearance ......................................................................................................................... 4
1. Front Panel .................................................................................................................................. 4
2. Rear Panel ................................................................................................................................... 4
3. Installation Illustration ............................................................................................................ 5
Video input ....................................................................................................................... 5
Connections for video outputs ................................................................................. 6
Audio Output ................................................................................................................... 6
F. Q & A and Maintenance ................................................................................................................. 7
1. Q & A............................................................................................................................................. 7
2. Maintenance ........................................................................................................................... 10
G. Appendix : Specifications ............................................................................................................ 12
1. 16CH NVR ................................................................................................................................ 12
VDH-NK350A Hardware Manual
1
A. CAUTION
To our dear customers!
Thank you for using our products. If you encounter any problems when using,
please do not hesitate to contact our resellers. We will provide excellent services to
you via our resellers.
The software/hardware improvements of this series are subject to change without
notice to you in advance. Before using, please read this user manual carefully to
ensure that you can use the device correctly and safely
Caution for this NVR series
After installation, never put anything heavy over this device. Owing to the use
of the hard drive(s) insides this device, check the cooling fan periodically to
see if it works. Never use this device when the cooling function is out of order!
Do not allow any solid object or liquid fall into or penetrate into the device.
Use cleaning tools (brushes) regularly to clean circuit boards, connectors, fans,
chassis, etc. Before cleaning, turn off the power and unplug the power.
Do not attempt to disassemble the equipment, repair, or replace parts. In case
the machine does not work properly, please contact the resellers or
manufacturers. In the shortest time, we will solve the problems you have
during using.
When not using the remote control for a long time, take out the inside battery
To prevent the control from the damage coming from battery leakage!
If this equipment connects to outdoor cameras or other external alarm devices,
ground this equipment to prevent it from electrical surges.
This NVR supports remote video monitoring via internet. Free or non-free
domain names provided by ISPs are needed for the monitoring functions.
Free domain names may sometimes have problems and nothing to do with
NVR. Non-free domain names have less problems. Choose the domain names
carefully before using the networking function.
Operating environment
Keep and use this device at places where temperature ranges 0℃~40℃. Avoid
direct sunlight or near heat sources.
Do not install this equipment in a humid environment
Do not expose this equipment in smoky, dusty environments;
Avoid strong collision, do not drop the machine
Keep the installation level, install in a stable place, avoid the product falling;
Do not block any ventilation openings. And ensure well ventilation around the
machine
Please use this equipment within rated input and output current/voltage
range.
This device is for long-time use. For safety, do not have flammable items
placed next to the device.
VDH-NK350A Hardware Manual
2
B. Introduction
1. Product Overview
This equipment is an excellent digital surveillance product designed
specifically for the security use. Using embedded LINUX operating system, it
makes the system more stable. Using standard H.264 video compression and
G.711A audio compression technology achieves audio and video functions
such as high-quality, low bit rate and single-frame playback. Using TCP / IP
and other network technologies, it provides strong network data transmission
capacity and remote control capabilities.
This equipment can be used individually or be connected to form a powerful
security monitoring network. Using professional network video surveillance
software platform, be fully experienced the powerful networking and remote
monitoring capabilities.
This equipment can be used for security in banks, telecommunications, power
stations, justice, transport, intelligence communities, factories, warehouses,
resources, water conservancy facilities and other categories.
2. Main functions
Auto detect IP camera in LAN.
Multiplex and maximize hard drive performance.
Sequence feature for easy liveview monitoring.
Motion events mark on time bar for faster event searching during
playback.
P2P functionality.
QR Code scanning for fast auto connection.
Cloud real-time monitoring.
Support SATA / SATA II hard drive up to 8TB.
VDH-NK350A Hardware Manual
3
C. Unpacking
1. Accessories
★ Power cable and adaptor AC100-240V/DC12V 4.16A x 1PCS
★ HDD screws x 4pcs
★ Operation CD x 1pcs
★ Mouse x 1pcs
2. Unpacking
When you receive the product, check first whether the packing of the
equipment has obvious damage. The protective material used for the package
during transport can cope with most of the accidental impact;
Then, take out the device, remove the protective film of the digital video
recorder and check if there is any visible damage;
Finally, open the case, check the front panel data cable, power cord, power
supply fan and motherboard to see if they are connected firmly.
Front/Rare panels
The key functions of the front panel and the interfaces of the rear panel are
described in detail in the manual.
Please carefully check the plate or foil on the rear panel of the product to see
if it is the model you ordered.
Information on the rear panel is important for our service, so keep it properly.
Before contacting us, you will need to provide your model type and serial
number.
Inside check
In addition to checking for visible signs of damage, be careful to check the
connections between the front panel data cable, power cord and
motherboard.
D. Installation
Steps and cautions:
1、Ensure room temperature below 35℃
2、Reserve space for air circulation around 15 cm (6 inches).
3、Chassis installation starts from bottom to up
4、With multiple components in the chassis, take precautions to avoid
overloading to the power outlet.
VDH-NK350A Hardware Manual
4
E. Product appearance
1. Front Panel
Power
Indicator Power Indicator
Network
Indicato
r
Network on
Recording
Indicato
r
Recording Indicator
2. Rear Panel
1 DC12 Power Input
2 USB 2.0 Mouse Port
3 USB 3.0 Mouse Port
4 HD digital output
5 Audio Output
6 LAN Port
7 VGA output
8 E-SATA(Optional)
DC12 Power Input
VDH-NK350A Hardware Manual
5
3. Installation Illustration
Video input
Input interface is RJ-45 type; input signal is IP CAM
The Video signal should comply with national standards, a higher signal to
noise ratio, low distortion, low-interference; clear images, no deformation,
nature color and appropriate brightness.
Make sure stable and reliable signals from cameras
Cameras should be installed in a suitable position to avoid backlighting,
low-light environment, or adopts the better BLC, low-light cameras.
Cameras and digital video recorders should be common ground, stably and
reliably, in order to ensure the normal operation of the cameras.
Make sure the transmission cables are stable and reliable
Adopt high-quality, well-shielded coaxial cables, and choose the right model
based on the transmission distance. If the distance is too far, use shielded
twisted pair, video compensation equipment, optical transmission and other
ways to ensure signal quality based on the specific circumstances.
Video cable should avoid strong electromagnetic interference with other
devices and circuits, in particular, should avoid the current of high voltage.
Make sure the connectors well-connected:
VDH-NK350A Hardware Manual
6
Cables and shielded cable should be well-connected firmly to avoid false,
joint welding or oxidation.
Connections for video outputs
The video outputs include VGA and HDMI interfaces.
Pay attention to the following when you select a PC display instead of a
monitor.
1. Do not remain switched on for a long time to extend the life of the
equipment;
2. Regular degaussing will help to maintain the normal operation of the
monitor.
3. Keep away from equipment with strong electromagnetic interference.
Using TV as video output device is an unreliable alternative. It is also
required to minimize the time of use and strictly control the power, the
interference caused by neighboring devices. Leakage risks of low quality TVs
may result in damage to other equipments.
Audio Output
The audio output parameters of NVR are generally greater than 200mv 1KΩ
(BNC), you can directly connect to the low impedance headphones, powered
speakers or other sound devices through a power amplifier.
When the external speakers and microphones can not achieve spatial
segregation, it is prone to the phenomenon of whistling.
You may adopt the following actions,
1. Using better directional microphones
2. Adjust the speaker volume to make it lower than the value of the
generated howling.
3. Using sound-absorbing materials for decoration to reduce sound
reflections and improve the acoustic environment;
4. Adjusting the layout of the microphone and speakers can reduce the
whistling.
VDH-NK350A Hardware Manual
7
F. Q & A and Maintenance
1. Q & A
Q 1.After power on, NVR doesn’t work.
A: The possible causes:
1. Wrong power input
2. bad connection of power cable
3. Power error
4. Firmware update error
5. Disk error or cable problem
6. Front panel error
7. Main PCB board error
Q 2.After power-on, NVR will restart after several minutes or the screen
freezes.
A: The possible causes:
1. Unstable or low input voltage
2. The hard drive has bad sectors or cable error
3. Low adaptor power
4. Front video signal not stable
5. High temperature, too much dust and the machine runs in a bad
condition.
6. NVR hardware error
Q 3.HDD not found after power-on
A : The possible causes:
1. No power for the Hard Drive
2. Hard Drive cable error
3. Hard Disk error
4. Main board SATA slot error
Q 4. No output: Single, multiple or all channels
A : The possible causes:
1. Wrong firmware: Update to the right firmware
2. Brightness set to 0: set it to the default value
3. No signal input or signal too weak
4. Mask used
5. NVR hardware error
Q 5.Live video problems: Such as bad colors, brightness error, image blink…
A : The possible causes:
1. Impedance mismatch between digital video recorder and monitor.
2. Video transmission distance is too far or video transmission line
attenuation is too much.
3. Wrong settings of colors, brightness in the NVR
VDH-NK350A Hardware Manual
8
Q 6.No recorded file in local side
A : The possible causes:
1. Wrong data cable or jumper error in the hard disk
2. Hard Disk error
3. Upgraded firmware cannot recognize the existing file system
4. Desired files are overwritten
5. Recording not enabled
Q 7.Bad image when playback
A : The possible causes:
1. Low recording quality
2. Once data error when reading or small bit-rate or fuzzy when playback,
please reboot machine
3. Wrong data cable or jumper error in the hard disk
4. Hard Disk error
5. NVR hardware error
Q 8.No audio sound
A : The possible causes:
1. Not powered-speaker
2. Audio cable error
3. NVR hardware error
Q 9.Live video with audio, but no sound when playback
A : The possible causes:
1. Wrong setting: audio not enabled
2. No video to the paired channels; when the screen is blue, playback will
be choppy.
Q 10. Wrong time
A : The possible causes:
1. Wrong settings
2. Bad battery connection or low voltage
3. Bad frequency oscillator
Q 11. Motion detection not function
A : The possible causes:
1. Wrong schedule setting
2. Wrong area setting
3. Low sensitivity
4. Hardware limitation for different version
Q 12. Fail to login by using client software or Web browsers
A : The possible causes:
Table of contents
Other Vacron Security System manuals
Vacron
Vacron VVH-MD657/AVM-360PV User manual
Vacron
Vacron VDH-NK380 User manual
Vacron
Vacron VDH-NK200 User manual
Vacron
Vacron VVH-MDE304 User manual
Vacron
Vacron VVH-MDE43E83 User manual
Vacron
Vacron VVH-MDE304 Installation guide
Vacron
Vacron VVH-MDE308 User manual
Vacron
Vacron SA-650CF User manual
Vacron
Vacron SA-650CF User manual
Vacron
Vacron VDH-NK900 User manual
Popular Security System manuals by other brands
EDM
EDM Solution 6+6 Wireless-AE installation manual
Highway Safety Group
Highway Safety Group EA401 user manual
Siren
Siren LED GSM operating manual
Detection Systems
Detection Systems 7090i Installation and programming manual
Se-Kure Controls
Se-Kure Controls MicroMini SK-4841 instructions
Siemens
Siemens FDM273 manual
