V-tech Sleepy Sloth Cot Light User manual
Instruction Manual
Sleepy Sloth Cot Light
Nature Sounds
Mode button
Lullaby Mode
button
Night Light Light Control
button
INTRODUCTION
Thank you for purchasing the VTech® Sleepy Sloth Cot Light.
Soothe baby into a peaceful sleep with the Sleepy Sloth Cot Light.
This adorable cot light toy projects a relaxing image onto the celling
to calm your little one as they go to sleep. Choose between two
modes to play calming melodies and lullabies or relaxing sounds.
OFF/15mins/45mins
Switch
Sound Sensor Light ProjectorStrap
Low Volume and
High Volume
buttons
3
3
3
INCLUDED IN THE PACKAGE
• One VTech® Sleepy Sloth Cot Light
• One Quick Start Guide
• One attachment strap
WARNING
All packing materials such as tape, plastic sheets, packaging locks,
removable tags, cable ties, cords and packaging screws are not part
of this toy and should be discarded for your child’s safety.
NOTE
Please save this Instruction Manual as it contains important information.
4
4
4
INSTRUCTIONS
Battery Removal and Installation
1. Make sure the unit is turned OFF.
2. Locate the battery cover on the back of
the unit. Use a screwdriver to loosen the
screw and then open the battery cover.
3. Remove old batteries by pulling up on
one end of each battery.
4. Install 3 new AA (AM-3/LR6) batteries following the diagram
inside the battery box. (For best performance, alkaline
batteries or fully charged Ni-MH rechargeable batteries are
recommended.)
5. Replace the battery cover and tighten the screw to secure.
WARNING:
Adult assembly required for battery installation.
Keep batteries out of reach of children.
IMPORTANT: BATTERY INFORMATION
• Insert batteries with the correct polarity (+ and -).
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable batteries.
• Only batteries of the same or equivalent type as recommended
are to be used.
• Do not short-circuit the supply terminals.
• Remove batteries during long periods of non-use.
• Remove exhausted batteries from the toy.
• Dispose of batteries safely. Do not dispose of batteries in fire.
5
5
5
RECHARGEABLE BATTERIES:
• Remove rechargeable batteries from the toy before charging.
• Rechargeable batteries are only to be charged under adult
supervision.
• Do not charge non-rechargeable batteries.
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and
batteries, or on their respective packaging, indicates
they must not be disposed of in domestic waste as
they contain substances that can be damaging to the
environment and human health.
The chemical symbols Hg, Cd or Pb, where marked,
indicate that the battery contains more than the specified
value of mercury (Hg), cadmium (Cd) or lead (Pb) set out
in the Batteries and Accumulators Regulation.
The solid bar indicates that the product was placed on the
market after 13th August, 2005.
Help protect the environment by disposing of your product
or batteries responsibly.
VTech®cares for the planet.
Care for the environment and give your toy a second life by
disposing of it at a small electricals collection point so all its
materials can be recycled.
In the UK:
Visit www.recyclenow.com to see a list of collection points near you.
In Australia & New Zealand:
Check with your local council for kerbside collections.
6
6
6
NOTE:
With the VTech®Sleepy Sloth Cot Light comes first.
To ensure your child’s safety, the assembly of this product is an adult
activity, not a child’s activity. Please ensure that the cot attachment
strap is securely locked into position to avoid injury. Follow the
instructions below carefully and make sure the final assembly is
correct. Attach only to cots with sturdy rails and spindles. Do not
attach to playpens with mesh walls.
Please make sure the cot attachment strap is out of reach of
children when placed in the cot. Please ensure the cot light is
positioned in the upright position with the projection light facing
directly upwards.
Please remove the cot attachment strap from the unit when the
unit is going to be used outside the cot. The cot attachment strap
should not be given to your child.
7
7
7
ASSEMBLY INSTRUCTIONS
With the VTech®Sleepy Sloth Cot Light, safety comes first.To
ensure your child’s safety, adult assembly is required.
1. Place the unit in the cot bringing the strap over the top rail. Slip
the top of the strap under the slot on the back of the strap and
secure.
2. You can adjust the hanging height by
choosing the appropriate hole on the
strap.
3. Pull slightly on the unit to make
sure the strap has been securely
fastened. The unit should be snug
against the cot rail. Please check
the unit frequently to ensure it is still
secure.
8
8
8
PRODUCT FEATURES
1. OFF/15mins/45mins Switch
To turn the unit On, slide the
OFF/15mins/45mins to the 15mins
( ) or 45mins ( ) position.
To turn the unit Off, slide the
OFF/15mins/45mins switch to the
Off ( ) position.
2. Volume Controls
To adjust the volume, press the Low
Volume button ( ) or the High
Volume button ( ).
3. Light Control Button
Press the Light Control Button to
choose between the night light and
the light projection.
4. Sound Sensor
The VTech®Sleepy Sloth Cot Light is equipped with a
special Sound Sensor. Once the set time is up, the unit will
automatically shut off. The sensor will reactivate the program
when it detects baby’s cry for approximately 2 seconds without
interruption. The unit will reactivate and play lullabies or nature
sounds.
9
9
9
5. Automatic Shut Off
To preserve battery life, the Sleepy Sloth Cot Light will
automatically shut off after the timer has expired. The unit can be
reactivated by pressing any button, or when baby cries.
NOTE:
If the unit powers down while playing, we suggest changing the batteries.
ACTIVITIES
1. Lullaby Mode Button
Press the Lullaby Mode Button to
hear sing-along songs, phrases and
soothing melodies. The projector will
light up and the night light will glow.
2. Nature Sounds Mode Button
Press the Nature Sounds Mode
Button to hear soothing sounds. The
projector will light up and the night
light will glow.
10
10
10
