V-tech Laptop Deluxe User manual

User's Manual

91-003220-000 US

Printed in China

Dear Parent,

At VTech®, we know how important the ﬁrst day  school is for your

child. To help prepare preschoolers for this important event, VTech®

has developed the Preschool Learning™ series  interactive ts.

Preschool Learning™ features fun characters and inviting school themes

that use technology to capture a child’s aention and teach important

preschool skills like spelling, counting and the alphabet. ese vital

skills are taught in a way that's bh fun and highly engaging to

maintain a child's interest. Children will also be introduced to fun

school suects such as art cla, music cla and even rece! With

Preschool Learning™, learning is fun om day one!

At VTech®, we know that a child has the ability to do great things.

at’s why all  our electronic learning products are uniquely

designed to develop a child’s mind and allow them to learn to the best

 their ability. We thank you for trusting VTech® with the important

job  helping your child learn and grow!

Sincerely,

Your iends at VTech®

To learn more about her VTech® ts, visit vtechkids.com

INTRODUCTION

Thank you for purchasing the Touch & Learn Activity DeskTM Deluxe!

The Touch & Learn Activity Desk™ Deluxe features an interactive desktop

with activity cards that introduce letters, numbers, music, colors and

more. Extend playtime with additional activity packs that each focus on a

specific curriculum (each sold separately). Flip up the desktop and create a

masterpiece using the art station or chalkboard. For more fun, play with the

toy telephone or listen to fun tunes on the music player.

INCLUDED IN THIS PACKAGE

• One Touch & Learn Activity Desk™ Deluxe (touch panel, base, four legs)

• Two Ready, Set, Learn activity cards

• One stool (seat, four legs)

• User’s manual

WARNING:

All packing materials such as tape, plastic sheets, packaging locks and tags

are not part of this toy and should be discarded for your child’s safety.

NOTE: Please keep the user’s manual as it contains important information.

ASSEMBLY INSTRUCTIONS

With the Touch & Learn Activity Desk™ Deluxe safety comes first.

To ensure your child’s safety, adult assembly is required.

For the Desk

1. Support the base by placing it on the ground. Insert the touch panel into

the base and press firmly down on the shoulders until you hear a click.

Caution: Do not place too much pressure on the touch panel itself.

Touch Panel

Shoulder Shoulder

Base

2. Fully insert the four legs into the slots on

the bottom of the base.

For the Stool

Fully insert the four legs into the slots on the bottom of

the seat until they click into place.

Easily Transforms from an Activity Desk to an Art

Station and Chalkboard

To use the Activity Desk as an Art Station, flip up the touch panel and use

the clip to hold paper on the chalkboard surface. You can also draw directly

on the Chalkboard surface using chalk.

Use a cloth to erase the chalk and wipe away any remaining chalk dust on

the desk or activity cards.

Activity Card Holder

Flip up the touch panel to store your activity cards in the ACTIVITY CARD

HOLDER.

Art Station Chalkboard

PRODUCT FEATURES

4 6 7

1POWER BUTTON 2HELP BUTTON 3MODE SWITCH

4TOY TELEPHONE

MODE BUTTONS

5TOY TELEPHONE

NUMBER BUTTONS

6LED DISPLAY

7CARTRIDGE SLOT 8MUSIC PLAYER

CONTROLS

9VOLUME

BUTTONS

10 ACTIVITY CARD

SLOT

11 ACTIVITY PAGE

MODE ICONS

12 ACTIVITY PAGE

AREA

13 DESK LEGS 14 STOOL

FEATURES ACTION

POWER BUTTON Press the POWER BUTTON to turn the unit

ON. Press the button again to turn the unit

OFF.

HELP BUTTON Press the HELP BUTTON to replay instructions,

or ask for a hint. You can also touch the Help

icon on the activity card if you need help.

MODE SWITCH Slide the SWITCH to the left to select

Activity Mode. In this mode all features will

be accessible. Slide the SWITCH to the right

to select Music Mode. In this mode the

ACTIVITY PAGE AREA will be deactivated

so you can use the desktop for reading or

listening to music.

TOY TELEPHONE MODE Press the button to learn numbers in

Learn It Mode.

Press the button to meet new friends in

Call A Friend Mode.

TOY TELEPHONE NUMBER Press the NUMBER BUTTONS to learn and

explore numbers.

LED DISPLAY Games, pictures or animations will be shown

here.

CARTRIDGE SLOT Each expansion pack (sold separately)

comes with a cartridge. To play an expansion

pack, insert the cartridge, then insert one of

the pack’s activity cards.

Note: The Ready, Set, Learn activity cards

that come with the desk do not require a

cartridge.

MUSIC PLAYER CONTROLS Press the button to Play/Stop the music,

and press the buttons to go to the

previous or next song.

VOLUME BUTTONS Press the buttons to decrease or

increase the volume. There are five volume

levels.

ACTIVITY CARD SLOT Insert one of the activity cards into this SLOT

to play.

ACTIVITY PAGE MODE ICONS Use your finger to touch any of the MODE

ICONS on the activity page to play.

ACTIVITY PAGE AREA Follow the game instructions and use your

finger to touch the objects on the activity

page to play.

BUTTONS

WARNING:

Please do not use a stylus, pencil or other pointed object on the ACTIVITY

PAGE AREA and activity cards.

GETTING STARTED

BATTERY INSTALLATION

• Make sure the main unit is turned OFF.

• Locate the battery cover on the back of the

touch panel. Use a coin or screwdriver to open

the battery cover.

• Remove the exhausted batteries and install four

new “AA” batteries following the diagram inside

the battery box.

• Replace the battery cover and tighten the screw

to secure.

BATTERY NOTICE

• Use new alkaline batteries for maximum performance.

• Use only batteries of the same or equivalent type as recommended.

• Do not mix different types of batteries: alkaline, standard (carbon zinc) or

rechargeable (Ni-Cd, Ni-MH), or new and used batteries.

• Do not use damaged batteries.

• Insert batteries with the correct polarity.

• Do not short-circuit the battery terminals.

• Remove exhausted batteries from the toy.

• Remove batteries during long periods of non-use.

• Do not dispose of batteries in fire.

• Do not charge non-rechargeable batteries.

• Remove rechargeable batteries from the toy before charging (if

removable).

• Rechargeable batteries are only to be charged under adult supervision.

TO BEGIN PLAY

Press the POWER BUTTON to turn on the main unit. Slide the MODE

SWITCH to choose Activity Mode or Music Mode.

Activity Mode

Touch any object on the activity page to explore. Touch any of the MODE

ICONS in the upper right area of the page to play additional activities. Voice

instructions are included for each activity.

Music Mode

There are 11 popular music and 10 classical music melodies in the MUSIC

PLAYER.

The MUSIC PLAYER will play all the songs one by one. It will stop when all

have played once. You can change the song by using the MUSIC PLAYER

CONTROLS.

The activity page features will be deactivated in Music Mode so that you can

put a book on the desktop for reading. Switch to Activity Mode when you

want to play with an activity page again.

Toy Telephone

The TOY TELEPHONE works in both Activity Mode and Music Mode.

Learn It Mode

Touch the number buttons to learn numbers, counting and number

order. Then test your knowledge by answering questions.

Call A Friend Mode

Follow the instructions and press the correct number buttons to

meet some new friends.

*Some activity cards in the expansion packs (sold separately)

will ask the player to use the TOY TELEPHONE buttons to answer

questions.

Battery Status

When the batteries are almost exhausted, the unit will show an empty

battery icon on the LED DISPLAY for a few seconds and then power

off automatically. New batteries should be inserted before further use.

Automatic Shut-Off

To preserve battery life, the main unit will automatically turn off after about

two minutes without operation.

ACTIVITY CARDS

To play an activity card, insert it into the

ACTIVITY CARD SLOT. If the card was

purchased with a separate expansion

pack, you must insert the expansion pack

cartridge before you can play.

• Please insert only one activity card at a

time. Inserting more than one activity card may damage the card or the

desk and may also result in incorrect card detection.

• Do not try to insert anything other than the activity card into the

ACTIVITY CARD SLOT. To avoid any interference, please keep the slot

area clean and free from debris.

• Keep the activity cards on a flat surface when not in use. Do not bend or

fold the activity cards.

• Please wipe away any dust or chalk residue from the activity card before

inserting into the ACTIVITY CARD SLOT.

Ready, Set, Learn Activity Cards

The Touch and Learn Activity Desk™ Deluxe comes with five fun activity pages

that cover fundamental skills such as letters, numbers, music, colors and

more. Refer to the table below for details.

Alphabet & Letter Sounds

Touch & Learn

Touch the letters and objects to

learn the alphabet, words and letter

sounds.

Searching Fun

Listen to the clues and find the

correct letters on the page.

Letter Writing

Select a letter and the game will

show you how to write it on the

LED display.

The Alphabet Song

Play the Alphabet Song game. When

the music stops, touch the next letter

to continue the song.

Teaches: Letters, Letter Sounds, Letter Order,

Letter Stroke Order, Vocabulary

Numbers & Counting

Touch & Learn

Touch the numbers to learn counting

from 1 to 15.

Searching Fun

Listen to the clues and find the

correct number on the page.

Number Writing

Select a number and the game will

show you how to write it on the

LED display.

Counting Game

Look at the lights on the LED display

and count how many there are.

Touch a number to answer.

Teaches: Numbers (1-15), Counting, Number

Order, Number Stroke Order, Vocabulary

Fruits & Colors

Touch & Learn

Touch the page to learn about fruits

and colors.

Searching Fun

Listen to the clues and find the

correct fruit on the page.

Coloring Game

Listen to what the painter needs and

find the correct color.

Teaches: Colors, Fruits, Vocabulary

Other manuals for Laptop Deluxe

Table of contents

Other V-tech Toy manuals

V-tech

V-tech Spin & Go Helicopter Assembly Instructions

V-tech

V-tech MobiGo Disney Princess User manual

V-tech

V-tech V.Baby Infant Learning System Meet Me at the Zoo Baby Smartridge... User manual

V-tech

V-tech Tool Box Friends Assembly Instructions

V-tech

V-tech Go Go Smart Wheels - Airport Playset User manual

V-tech

V-tech Disney TALK & TRACE CLIPBOARD User manual

V-tech

V-tech MobiGo Touch Learning System Pink User manual

V-tech

V-tech Touch & Learn Activity Desk Assembly Instructions

V-tech

V-tech V.Smile Motion: Scooby Doo User manual

V-tech

V-tech My 1st Tablet User manual

V-tech

V-tech Tote & Go Laptop User manual

V-tech

V-tech V.Smile: Aladdin s Wonders of The World User manual

V-tech

V-tech Switch & Go Dinos - T-Don the Pteranodon User manual

V-tech

V-tech Magic Lights 3D User manual

V-tech

V-tech Touch & Learn Activity Desk Deluxe When I Grow Up Expansion... User manual

V-tech

V-tech Touch & Teach Sea Turtle Assembly Instructions

V-tech

V-tech Go Go Smart Wheels - Fast Track Launcher User manual

V-tech

V-tech Thomas & Friends Learn & Explore Laptop User manual

V-tech

V-tech Kidizoom camera Connect User manual

V-tech

V-tech Switch&Go Dinos Defender the Velociraptor Assembly Instructions

V-tech

V-tech Winnie the Pooh My First Words User manual

V-tech

V-tech SWITCH & GO DINOS Overseer the T-Rex Assembly Instructions

V-tech

V-tech V.Reader Interactive E-Reading System User manual

V-tech

V-tech Touch & Teach Elephant User manual

Popular Toy manuals by other brands

marklin

marklin 37321 instruction manual

Canon

Canon PAPER CRAFT Assembly instructions

GREAT PLANES

GREAT PLANES Pitts M-12S instruction manual

NOCH

NOCH 14261 manual

Hausler

Hausler 450 SE V2 quick start

Dynaflite

Dynaflite Daydream instruction manual

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Build instructions

Kenner

Kenner Batman 63651 instructions

LEGO

LEGO 8527 instructions

iKarus

iKarus ECO 8 Assembly instruction

Multiplex

Multiplex EasyStar II Building instructions

Walkera

Walkera 38 User handbook

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE manual

MD MXION SWD user manual

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway instructions

marklin

marklin 39671 user manual

Meccano

Meccano 15103 instructions

LEGO

LEGO TECHNIC 8735 instructions
