V-tech 80-540953 Assembly Instructions

Parent's Guide

INTRODUCTION

Thank you for purchasing the Learn & Draw Activity Desk!

The Learn & Draw Activity Desk features an interactive desk top with five

interactive activity pages that introduce letters, phonics, writing, numbers,

music and more. Practise telling the time with the play clock, or use the

interactive projector to learn about the weather, parts of the body, shapes,

colours and matching. The writing pad with a light up display teaches

children how to write letters and numbers, stroke by stroke. Flip up the

desk top and create a masterpiece using the blackboard or art station while

listening to tunes on the music player.

INCLUDED IN THIS PACKAGE

• Learn & Draw Activity Desk

• 2 Double-sided activity cards

• 4 Projection reels

• 1 Stool

• 1 Quick Start Guide

WARNING:

All packing materials such as tape, plastic sheets, packaging locks,

removable tags, cable ties, cords and packaging screws are not part of this

toy and should be discarded for your child’s safety.

NOTE: Please keep this parent’s guide as it contains important information.

PRODUCT FEATURES

1Roller & Slider

2Photo Frame

3Activity Page Mode Icons

4Letter and Number Selection Buttons

5LED Display / Writing Pad

6Touch Panel

Activity Card Slot

9Stool Legs

Pretend Clock

11 Clock Button

12 Projector Reel Slot

13 Projection Focus Adjuster

14 Interactive Projector

15 Stylus

16 Projection Reels

17 Music Player Controls

19 Speaker

18 Volume Buttons

10 12 15 16

21 Help Icon

22 Reel Rack

20 Power Button

8Stool Seat

24 Desk Legs

23 Clip

FEATURES ACTION

Roller & Slider Learn about days of the week and the

weather (this part has no audio responses).

Activity Page Mode Icons Use your finger to touch any of the Mode

Icons on the activity page to play.

Pretend Clock Turn the Clock Hand or press the Clock

Button to explore and practise time concepts.

Letter and Number

Selection Buttons

LED Display / Writing Pad Watch images and simple animations appear

on the LED Display. Play with the Stylus

on the Writing Pad and learn how to write

letters and numbers with proper stroke order.

Touch Panel Listen to the game instructions and touch the

correct objects on the activity page to play.

Activity Card Slot Insert one of the activity cards into the

Activity Card Slot to play.

Projector Reel Slot Insert a Projection Reel into the Projector

Reel Slot to play interactive activities or

trace images and learn to draw.

Projection Focus Adjuster Slide to adjust the focus of the projection.

Interactive Projector Flip it up/down to open/close.

Stylus (only works with writing pad) Practise writing letters and numbers by using

the Stylus to trace the blinking lights.

Music Player Controls Press the button to play or stop the

music, and press the buttons to hear

the previous or next melody.

Volume Buttons Press the buttons to decrease or increase

the volume. There are five volume levels.

Power Button Press the Power Button to turn the unit ON.

Press the button again to turn the unit OFF.

Help Icon Touch the Help Icon to hear hints or

instructions.

Projection Reels Rack Return the Projection Reels back to the

Rack when they are not in use.

Clip Use the Clip to hold your paper on the

Touch Panel for tracing images when you

play Picture Tracing (see the details about

Picture Tracing in the later pages).

Press the buttons to select the letters

or numbers you would like to write.

ASSEMBLY INSTRUCTIONS

With the Learn & Draw Activity Desk safety comes first.

To ensure your child’s safety, adult assembly is required.

For the Desk

1. Place the base on a flat surface. Insert the touch panel into the base and

press down on the hinges until you hear a click. Flip the touch panel

down.

Caution: Do not place too much pressure directly on the touch panel.

2. Fully insert the four desk legs into the

slots on the bottom of the base.

For the Stool

Insert the four stool legs into the slots on the bottom of

the stool seat. Please make sure to fully insert the legs

into the seat to ensure the stool is stable. Always make

sure all four legs are fully inserted before your child sits

on the seat. The recommended weight limit of the stool

should not exceed 34 kilograms.

Base

Hinge

3 4

Easily Transforms from an Activity Desk to an Art

Station and Blackboard.

To use the Activity Desk as an Art Station, flip up the touch panel and use

the clip to hold paper on the blackboard surface. You can also draw directly

on the Blackboard surface by using chalk.

Use a cloth to erase the chalk and wipe away any remaining chalk dust on

the desk or activity cards.

CAUTION: Keep fingers away from the hinges or underneath the desk

before lowering the touch panel.

WARNING: Do not use any pencils, pens, colours, or other pointed objects

on the Touch Panel or Activity Pages directly as it will damage them.

Activity Card Holder

Flip up the touch panel to store your activity cards in the activity card holder.

Art Station Blackboard

INSTRUCTIONS

BATTERY REMOVAL AND INSTALLATION

• Make sure the main unit is turned OFF.

• Locate the battery cover on the back of the unit.

Use a coin or screwdriver to loosen the screw.

Then, remove the cover.

• If used batteries are present, remove these

batteries from the unit by pulling up on one end

of each battery.

• Install 4 new AA (AM-3/LR6) batteries

following the diagram inside the battery box.

(For best performance, alkaline batteries or

fully charged Ni-MH rechargeable batteries are

recommended).

• Replace the battery cover and tighten the screw to secure.

WARNING

Adult assembly required for battery installation.

Keep batteries out of reach of children.

IMPORTANT: BATTERY INFORMATION•

• Insert batteries with the correct polarity (+ and -).

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc) or rechargeable batteries.

• Only batteries of the same or equivalent type as recommended are to be

used.

• Do not short-circuit the supply terminals.

• Remove batteries during long periods of non-use.

• Remove exhausted batteries from the toy.

• Dispose of batteries safely. Do not dispose of batteries in fire.

RECHARGEABLE BATTERIES:

• Remove rechargeable batteries from the toy before charging.

• Rechargeable batteries are only to be charged under adult supervision.

• Do not charge non-rechargeable batteries.

Disposal of batteries and product

The crossed-out wheelie bin symbols on products and batteries, or on

their respective packaging, indicates they must not be disposed of in

domestic waste as they contain substances that can be damaging to the

environment and human health.

The chemical symbols Hg, Cd or Pb, where marked, indicate that the

battery contains more than the specified value of mercury (Hg), cadmium

(Cd) or lead (Pb) set out in the Batteries and Accumulators Regulation.

The solid bar indicates that the product was placed on the market after

13th August, 2005.

Help protect the environment by disposing of your product or batteries

responsibly.

VTech®cares for the planet.

Care for the environment and give your toy a second life by disposing of it at a small

electricals collection point so all its materials can be recycled.

In the UK:

Visit www.recyclenow.com to see a list of collection points near you.

In Australia & New Zealand:

Check with you local council for kerbside collections.

TO BEGIN PLAY

Press the Power Button to turn on the main unit.

Touch Panel

Touch any object on the activity page to explore. Touch any of the Activity

Page Mode icons in the upper left corner of the page to play additional

activities. Touch the Help Icon in the upper right corner of the page to hear

hints or instructions.

NOTE:

• Make sure you do not touch the Touch Panel or place other objects

(except the activity card) on the Touch Panel when turning on the main

unit.

• The Touch Panel (except the Activity Page Mode icons and the Help

icon) will not be responsive to touch while using the Writing Pad.

• The Touch Panel (except the Help icon) will not be responsive to touch

while playing the Picture Tracing activity.

• Make sure you are touching the Touch Panel with your finger and are not

using the Stylus or other objects.
