Nitro Web NotebookTM

User’s Manual

Printed in China

91-002368-003

INTRODUCTION

Thank you for purchasing the VTech®Nitro Web Notebook™.

The Nitro Web Notebook™is a high-tech notebook that is jam-packed with 50

fun learning activities onboard! Your child will have gaming fun while getting

lessons in Spanish, Language Arts, Math, Science, Creativity, and Logic. The

system has a full QWERTY keyboard and real mouse.

INCLUDED IN THIS PACKAGE

• Nitro Web Notebook™console

• Nitro Web Notebook™instruction manual

• Realmouse

WARNING:

All packing materials such as tape, plastic sheets, wire ties and tags are not

part of this toy and should be discarded for your child’s safety.

Demo

Button

8 Category

Buttons

QWERTY

Keyboard

LCD Screen

Built-in

Speaker

Progress

Report Button

Level Button

On/Off Button

Real Mouse

Volume/

Contrast Control

Cursor Pad

GETTING STARTED

POWER SOURCE

The Nitro Web Notebook™operates on 3 “AA” sized batteries (AM-3/LR6) or

aVTech®9V adaptor (sold separately). The “AA” sized batteries included in

the unit are for demo purposes only and are not long-life batteries.

If you are using a power supply adaptor, please remember to empty the

battery slot rst.

BATTERY INSTALLATION

NOTE: For best performance, remove all factory

installed batteries and use new,alkaline batteries.

1. Make sure the unit is turned OFF.

2. Locate the battery cover on the bottom of the unit

and open it.

3. Insert 3 “AA” sized batteries as illustrated.

4. Close the battery cover.

RECHARGEABLE BATTERIES ARE NOT RECOMMENDED.

BATTERY NOTICE

• Theuseofnewalkalinebatteriesisrecommendedformaximumperformance.

•Do not try to recharge non-rechargeable batteries.

• Rechargeablebatteriesaretoberemovedfromthetoybeforebeing

charged.

• Rechargeablebatteriesareonlytobechargedunderadultsupervision.

• Donotmixdifferenttypesofbatteries:alkaline,standard(carbon-zinc)or

rechargeable (nickel-cadmium).

• Donotmixnewandusedbatteries.

• Onlyusebatteriesoftherecommendedorequivalenttype.

• Installbatteriescorrectlyobservingthepolarity(+,-)signstoavoidleakage.

• Batteriesthathaverunoutofenergymustberemovedfromthetoy.

• Donotshortcircuitthesupplyterminals.

• Donotusemorebatteriesthanrecommended.

• Removebatteriesfromthetoyifitwillnotbeusedforanextendedperiodoftime.

• Donotdisposeofbatteriesinre.

GETTING STARTED

AC-DC ADAPTOR

Use a VTech®adaptor or any other standard adaptor that complies with

EN61558 DC 9V 300mA center-positive adaptor.

CONNECTING THE ADAPTOR

1. Make sure the unit is OFF.

2. Locate the adaptor jack on the right side of the unit.

3. Insert the adaptor plug into the unit’s adaptor jack.

4. Plug the adaptor into a wall outlet.

5. Turn the unit ON.

NOTE:Whenthetoyisnotgoingtobeinuseforanextendedperiodoftime,

unplug the adaptor.

ADAPTOR NOTICE

• Thetoyisnotintendedforusebychildrenunder3yearsold.

• Onlyusetherecommendedadaptorwiththetoy.

• Theadaptorisnotatoy.

• Nevercleanaplugged-intoywithliquid.

• Neverusemorethan1adaptor.

• Donotleavetoyoradaptorpluggedinforextendedperiodsoftime.

NOTICE TO PARENTS

Regularlyexaminetheadaptor,checkingfordamagetothecord,plug,transformer

or other parts. Do not use the adaptor if there is any damage to it.

USING THE MOUSE

CONNECTING THE MOUSE

Only use a mouse that is compatible with VTech®products.

1. Make sure the unit is OFF.

2. Locate the mouse jack on the right side of the unit.

3. Plug the mouse into the mouse jack.

USING THE MOUSE

1. Move the mouse in the direction you want the cursor to move.

2. Click the mouse button to make a selection.

GETTING STARTED

CLEANING THE MOUSE

1. Following the arrows, use a screwdriver to open

the cover on the bottom of the mouse.

2. Take the ball out of the mouse and use a dry

cloth to clean the mouse and the ball.

3. Place the ball back in the mouse, replace the mouse

cover and screw the cover closed.

PRODUCT FEATURES

CATEGORIES

In the Nitro Web Notebook™, you can choose from 8 different categories of

play and learning:

• ForeignLanguagePlanet

• LanguageArtsTown

• MathZone

• SocialStudiesCity

• ScienceIsland

• MotorSkillsCenter

• Logic&MemoryPlaza

• FineArtsPark

ONE/TWO PLAYER MODE

Press on the keyboard to switch between One Player and Two Player

modes. The activities that can be played with two players are:

• A23.MathMania

• A38.RobotCatcher

• A39.HoopSpree

• A41.AnimatedPairs

• A42.Watchout!

PROGRESSIVE LEARNING FEATURE

Inmostactivities,ifthequestionsareansweredincorrectlyintherstround

ofagame,3ofthequestionswillberepeatedinalaterround.Thisfeatureis

designed to help children learn by developing memory skills.

PRODUCT FEATURES

AUTO-LEVELING FEATURE

In most activities, after entering 3 continuous rounds of correct answers and

getting80-100pointseachround,itwillauto-leveluptothenextdifcultylevel;

if the score is lower than 60 points each round, after 3 rounds continuously, it

will auto-level down.

PROGRESS REPORT

You can review your progress by pressing the Progress Report button.

TURNING THE UNIT ON AND OFF

Pressing and holding will turn the unit ON. Pressing again will turn the

unit OFF.

ACTIVITY SELECTION:

When the unit is turned on, you will see a short opening scene before entering

theCategoryMenu.Here,thecategorieswillcyclethroughautomatically.You

can choose a category in one of these ways:

1) Press the Enter key when you see a category you like.

2) Use the Arrow keys to cycle through the categories and press the Enter

key to choose.

3) Use the mouse to click the arrow icon on the screen and cycle through the

categories, and then click the screen when you see a category you like.

4) Use to click the arrow icon on the screen and cycle

through the categories, press to click the screen when you

see a category you like.

5) Press the Category key directly.

After that, you can choose an activity in the following ways:

1) Press when you see an activity you like.

2) Use to cycle through the activities manually, and press

to choose one.

3) Use the mouse to click the arrow icon on the screen and cycle through the

PRODUCT FEATURES

activities, and then click the screen when you see an activity you like.

4) Use to click the arrow icon on the screen and cycle through the

activities, press to click the screen when you see an activity you

like.

5) Type the activity number and press .

LEVEL SELECTION

Pressing willpopupamenuatrst.Use and ,

mouse, and or number keys to choose a level you like.

Level one is the default setting when starting a new activity.

ANSWER

In most activities, the answer will be provided after a certain number of tries.

SHORT BREAK MODE

Afterplayingveroundsinarowinanyactivity,youwillenjoyafunmusical

break!

FUN TIME MODE

Enjoy a fun cartoon by pressing at any time!

AUTOMATIC POWER-OFF

To save power, your Nitro Web Notebook™automatically shuts down if it does

not receive any input after several minutes. Press to wake your unit.

Werecommendthatyouturnofftheunitwhennishedplaying.Removethe

batteries and unplug the adaptor if your Nitro Web Notebook™will not be

usedforanextendedperiodoftime.

PRODUCT FEATURES

VOLUME and CONTRAST CONTROL

To adjust the volume, press and a pop-up screen will appear. Use the

mouse, or to move the cursor to the right for higher

volume and to the left for lower volume.

Press again to adjust the screen contrast by the same method.

KEYBOARD LAYOUT

Your VTech®Nitro Web Notebook™has a full QWERTY keyboard that doubles

asamusickeyboard.Youwillalsondthefollowingfunctionkeys:

FUNCTION KEYS

On/Off: Press this button to turn the unit on and off.

Demo: Press this button to see the Demo movie.

8 Category Buttons: Press one of the above buttons to jump to the sub menu

of the chosen category.

Progress Report: Press this button to review your progress.

Esc:Pressthiskeytogobacktothepreviousscreenorexitthe

current activity.

Level:Pressthiskeytoselectanactivity’slevelofdifculty.

Caps Lock: Press this key to type capital letters. Press once to

turn Caps Lock on, press it again to type lowercase letters. The

LED light on the left will light up when it is on.

PRODUCT FEATURES

Shift: Press this key together with a letter key to capitalize the

letter. You can also use this key to access the alternate letters/

symbols or functions of some keys.

Help: Press this key to see helpful instructions or hints for the

current activity.

Answer:Pressthiskeytoseethecorrectanswertoaquestion.

You will not receive points if this key is pressed.

Repeat:Pressthiskeytorepeataquestionoraninstruction.

Backspace: Press this key to erase the character to the left of the

cursor.

Player: Press this key to switch between One Player and Two

Player modes.

Player 1 / Player 2: Press to select which player will answer

thequestioninTwoPlayermode.

Delete: Press this key to delete the current character or space to

the right of the cursor or above the underscore.

Enter:Pressthiskeyafterchoosingyouranswertoconrmyour

selection.

Fun Key: Press this key to see a fun animation.

Music On/Off Key: Press this key to turn the background music

on and off.

Arrow Keys: Use these keys to cycle through choices in

activities or in the Main Menu.

PRODUCT FEATURES
