System Requirements

• /LQX[©0DF26;©RU©0LFURVRIW©:LQGRZV©

• Web Browser: Mozilla Firefox, Google Chrome, Microsoft

Edge, or Microsoft Internet Explorer 11

Installation Requirements

• Phillips screwdriver (for shelf or wall mounting)

• (Optional) 42 to 56VDC power source, such as the

EdgePower™EP-54V-150W, for stand-alone DC power or

redundant power backup.

• For indoor applications, use Category 5 (or above) UTP

cabling approved for indoor use.

• For outdoor applications, shielded Category 5 (or above)

cabling should be used for all wired Ethernet connections

and should be grounded through the AC ground of the

power supply.

We recommend that you protect your networks from

harmful outdoor environments and destructive ESD events

with industrial-grade, shielded Ethernet cable from Ubiquiti

Networks. For more details, visit www.ubnt.com/toughcable

WARNING: To reduce the risk of fire or electric shock,

do not expose the switch to rain or moisture.

Note: Although the cabling can be located outdoors,

the EdgeSwitch itself should be housed inside a

protective enclosure.

https://arttel.ru/

https://arttel.ru/shop/kommutatory/ubiquiti-edgeswitch-8-150w

https://arttel.ru/

https://arttel.ru/shop/kommutatory/ubiquiti-edgeswitch-8-150w

System LED

State Status

Steady Blue Initializing.

Flashing Blue Resetting to factory defaults.

Steady White Ready for use and working properly.

SFP LEDs

LED State Status

/LQN

6SHHG

Activity

Off No Link

Green /LQN©(VWDEOLVKHG©DW©*ESV

Flashing Indicates Activity

https://arttel.ru/

https://arttel.ru/shop/kommutatory/ubiquiti-edgeswitch-8-150w

https://arttel.ru/

https://arttel.ru/shop/kommutatory/ubiquiti-edgeswitch-8-150w

https://arttel.ru/

https://arttel.ru/shop/kommutatory/ubiquiti-edgeswitch-8-150w

Side Panels

Ventilation Holes

WARNING: FAILURE TO PROVIDE PROPER VENTILATION

MAY CAUSE FIRE HAZARD. KEEP AT LEAST 20 MM OF

&/($5$1&(©1(;7©72©7+(©9(17,/$7,21©+2/(6©)25©

ADEQUATE AIRFLOW.

WARNING: The ES-8-150W must not be stacked. Do not

place it on top of another switch. Do not place anything

on top of the ES-8-150W.
