Tripp Lite Keyspan USA-49WG User manual
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: USA-49WG
Keyspan High-Speed 4-Port Serial to USB Adapter
Highlights
Zero configuration, Plug-and-Play operation
Quickly connect and disconnect adapter without powering down
Adds four RS-232 DB9 serial ports
Detachable 6-ft. USB cable included
No external power adapter required
Mac OS and Windows-compatible
Description
Our USB 4-Port Serial Adapter allows 4 serial devices to be connected to a single USB port. It provides a simple way to add serial ports to a PC
without the hassle of installing a serial card, turning off the PC, or configuring IRQs.
Applications
This adapter is ideal for industrial and enterprise markets where there is a need to connect serial device to a PC for process control, data collection,
or point of sale applications. It is also ideal for connecting modems, fax modems, or terminals to a server.
System Requirements
Windows:
An available USB port
Compatible with Windows 98, 98 SE, Me, 2000, XP 32- and 64-bit, 2003 Server 32- and 64-bit, Vista 32- and 64-bit, and 7 32- and 64-bit
Macintosh:
An available USB port
Compatible with Mac OS 8.6 through 9.x, Mac OS X 10.2.8 through 10.5.x (both 32- and 64-bit), and Mac OS X 10.6.x (32-bit and 64-bit)
For use with all RS-232 serial devices including modems, GPS devices, cell phones, hand held scanners, networking equipment (console port),
graphics tablets, point of sale devices, touch screens, UPS devices, medical and scientific instruments, industrial process control devices, building
automation instrumentation and other serial devices.
Package Includes
USA-49WG 4-Port USB Serial Adapter
6 ft. USB device cable
CD with driver software and user guide
Features
High Speed: Supports 460 Kbps - four timesthe speed of a built-in serial port
Detachable Cable: Use adapter with any USB cable (up to 5 meters long)
LEDs: Show adapter status and data activity
Plug & Play: Appear as standard COM ports
Bus Powered: No external power adapter required
Analytic Tools: Includes Windows line monitor and data trace software
Field Upgrade: Easy to update over time with free software downloads
Easy Expansion: Supports use of multiple adapters on one PC
Specifications
PRODUCT OVERVIEW
Product Overview Keyspan-by-Tripp Lite 4-Port USB Serial Adapter
PHYSICAL
Unit Dimensions (HWD/in) 1.8 x 6 x 3
Unit Dimensions (HWD/cm) 4.57 x 15.24 x 7.62
Unit weight (lbs) 0.35
Unit weight (kg) 0.16
Color Black
CONNECTIONS
Connector A
USB A (MALE)
Connector B
(X4) DB9 (MALE)
WARRANTY
Product Warranty Period
(Worldwide)
2-year limited warranty
Related Items
Optional Products
Product Type Related Model Description Qty.
Computer Cables P520-006 6-ft. RS-232 Serial Extension Cable
(DB9 M/F)
1
USB Cables & Adapters U022-006 6-ft. USB2.0 A/B Gold Device Cable
(A Male to B Male)
1
USB Cables & Adapters U022-010 10-ft. USB2.0 A/B Gold Device Cable
(A Male to B Male)
1
USB Cables & Adapters U022-015 15-ft. USB2.0 A/B Gold Device Cable
(A Male to B Male)
1
USB Cables & Adapters U024-006 6-ft. USB A/A Gold Extension Cable for USB2.0 Cable
(USB-A M/F)
1
USB Cables & Adapters U024-010 10-ft. USB A/A Gold Extension Cable for USB2.0 Cable
(USB-A M/F)
1
USB Cables & Adapters U026-016 16-ft. USB2.0 A/A Active Extension Cable
(USB-A M/F)
1
USB Cables & Adapters U042-036 36-ft. High-Speed USB2.0 A/B Active Device Cable
(A Male to B Male)
1
USB Cables & Adapters U209-000-R USB to Serial Adapter
(USB-A Male to DB9M)
1
USB Cables & Adapters UPR-112G Mini-Port Replicator
Keyspan by Tripp Lite
1
USB Cables & Adapters USA-19HS High-Speed USB Serial Adapter
Keyspan by Tripp Lite
1
USB Cables & Adapters USA-28XG USB Twin Serial Adapter for Macs
Keyspan by Tripp Lite
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3916.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
