Triarch 31916 Quick start guide

ASSEMBLY AND MOUNTING INSTRUCTION

For 31916

Please read the Assembly lnstruction sheet carefully before proceeding.Carefully unpack and e

identify all parts prior to building the unit. Each part is identified on the drawingfor reference.

DO NOT DISCARD THE ORIGINAL PACKAGING. If after careful inspection and you must returnthe item

for any reason. Please repack the unit using the original carton and inserts.

STEP 1:Unpack all the parts and

BottomCap

Nut

Glass Washer

Gl ass Shade

Threaded Ni ppl e

Uni ver s al mount i ng bar

Fi xture

Fi ni al

Classify them according to the

illustration shown at the side.

Place the parts on a scratchfree

surface;

STEP 2: Make sure the power is

turned Off at the Ceiling junction

box where the fixture is to be

installed.Secure the cross bar to

the ceiling junction using the

junction box screws;

STEP 3: Use the wire nuts to

Connect positive and negative

wires. Connect the Ground wire

to the ground port;

STEP 4: Secure the fixture to the

Ceiling Junction box using two

Brass;

STEP 5: Install the correct bulbs

(not provided);

STEP 6: Install the center rod to the fixture;

STEP 7:Install the glass to the glass shade with nut .Secure with bottom cap

and the finial.
